Installation
3
Installation
3.1
Installation Overview
Prerequisites
The following items are required for installation and basic configuration:
•
Ethernet cable
•
USB cable
•
Anybus Configuration Manager - X-gateway (1.5.1.1 or later)
•
Anybus Configuration Manager - IIoT
•
IPconfig (3.2.1.1 or later)
The Anybus Configuration Manager and IPconfig applications can be
downloaded from www.anybus.com/support.
Basic installation steps
1.
Connect the Anybus X-gateway IIoT Interface to the Ethernet network.
2.
Connect a computer to the USB connector on the X-gateway.
3.
Power on the X-gateway.
4.
Use IPconfig to configure the TCP/IP settings for the IIoT interface.
5.
Use Anybus Configuration Manager - X-gateway to configure the data
exchange options for the two interfaces in the Anybus X-gateway.
6.
Use Anybus Configuration Manager - IIoT to create a tag configuration and
transfer it to the IIoT interface.
7.
Connect to the web interface of the IIoT interface and configure MQTT/OPC
UA communication.
IIoT Startup Guide
6 (8)
SP2443 1.0 en-US
