V12 DIVERTER
PRODUCT MANUAL
IMPORTANT
Installer: This Manual is the property of the
customer and must be retained with the product
for maintenance and operational purposes.
1147005-W2-B
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for rada V12

Summary of Contents for rada V12

  • Page 1 V12 DIVERTER PRODUCT MANUAL IMPORTANT Installer: This Manual is the property of the customer and must be retained with the product for maintenance and operational purposes. 1147005-W2-B...
  • Page 2 INTRODUCTION Thank you for purchasing a quality Rada product. To enjoy the full potential of your new product, please take time to read this guide thoroughly, having done so, keep it handy for future reference. The Rada Diverters are suitable for either high or low pressure systems and are available as exposed or concealed configurations.

  • Page 3: Safety Warnings

    SAFETY : WARNINGS Rada products are precision engineered and should give continued safe and controlled performance, provided: 1. They are installed, commissioned, operated and maintained in accordance with manufacturer’s recommendations. 2. Do not install the product in a position in which service access is restricted.

  • Page 4: Pack Contents

    PACK CONTENTS Tick the appropriate boxes to familiarize yourself with the part names and to confirm that the parts are included. 1 x Rada Diverter (Exposed) 1 x 'O' Seal 1 x 2 mm Hexagon Key 1 x 15 mm Olive...
  • Page 5 DIMENSIONS Rada Diverter (Exposed) Rada Diverter (Concealed) Ø130 ∅130 59 - 89 All dimensions in mm 1147005-W2-B...

  • Page 6: Specifications

    Max Static Pressure: 10 Bar. • Max Maintained Pressure: 5 Bar. Connections Exposed Diverter: • Inlet: Adapter for Rada V12 Mixer Outlet • Top Outlet: 15 mm Compression. • Right Angle Outlet (RAC) : ½" BSP Flat Face Concealed Diverter: •...

  • Page 7: Installation

    (refer to the Product Manual for the Rada V12 Mixing Valve). This is to prevent back-siphonage. 4. Install the Rada V12 mixing valve (refer to the Product Manual). 5. Remove the outlet adaptor fitted to the diverter...
  • Page 8 9. Remove the compression nut from the diverter 12. Install the shower fittings (refer to the 'Product Compression Nut Manual'). Grubscrew 13. Turn on the water supplies and check for leaks. Diverter 14. Refer to the Rada V12 Product Manual for Commissioning procedure. Hexagon Outlet Adaptor 1147005-W2-B...
  • Page 9 2. Remove the plasterboard and or brickwork to a minimum depth of 55 mm depth so that the Solid Wall or Stud Partition Fixing using outlet of the Rada V12 mixer aligns with the Securing Bracket diverter inlet. Note! The following instructions assume the...
  • Page 10 Hole 5. Install the 15 mm compression nuts and olives (supplied) to the diverter connections. 6. Connect the outlet of the Rada V12 mixer to the diverter inlet with a length of 15 mm copper Panel Fixing Hole tube and fully tighten the compression nuts.
  • Page 11 Concealing Plate Assembly 3. Install the backplate onto the diverter. Note! Ensure that the backplate is installed with the 'TOP' mark in the vertical position. 1. Align the control lever to position 1 and using the 2.5 mm hexagon key remove the grubscrew, control lever and bearing washer.

  • Page 12: Flow Regulators

    Flow Regulators Flow regulators ( 6l/min Black and 9 l/min orange) are supplied with the Rada V12 mixing valve and diverters. For the Concealed Diverter the flow regulators can be installed in the RAC (right angle connector) and the overhead shower fitting (Refer to the relevant Product manual).

  • Page 13: Maintenance

    Warning! Many household cleaners contain abrasive and chemical substances, and should not be used for cleaning plated or plastic fittings. Do not use descalents on this product. If you require a Rada trained service engineer or agent, refer to section: ‘Customer Services’. Fault Diagnosis Symptom: •...

  • Page 14: Spare Parts

    SPARE PARTS Exposed Models 1651.137 1651.129 1651.131 1651.137 1651.129 Lever Assembly 1651.130 Service Kit (identified 'A') 1651.131 Inlet Adapter 1651.137 Flow Regulators (6 & 9 l/min) 1147005-W2-B...
  • Page 15 Concealed Models 1651.126 1651.125 1651.137 1651.123 1651.124 1651.123 Concealing Plate Assembly 1651.124 Component Pack 1651.125 Detent 1651.126 Cover 1651.127 Service Kit (identified 'B') 1651.137 Flow Regulators (6 & 9 l/min) 1147005-W2-B...

  • Page 16: Customer Service

    For shower fittings or consumable items we You have the assurance of a fully trained Technician, reserve the right to supply replacement parts only. genuine Rada spare parts and a 12 month guarantee on any chargeable work done. The guarantee does not cover:...
