- Page 1 OWNERS INSTRUCTION MANUAL 132CM/52” Zeta INSTALLATION OPERATION MAINTENANCE CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT A QUALIFIED ELECTRICIAN SUITABLE FOR 230V/50 CYCLE ELECTRICAL SUPPLY Enquiries on installing your fan please call our help line on 01959-564440 E-mail : technical@fantasiaceilingfans.com...
-
Page 3: Safety Precautions
Safety Precautions To ensure the success of the installation be sure to read the instructions and study the diagrams thoroughly before commencing. All electrical work should only be undertaken after disconnection of the power by removing fuses or turning off the circuit breaker to ensure all pole isolation of the electrical supply. -
Page 4: Supplied Parts
Supplied Parts One fan with DC motor assembly One round plate fitted One set of wooden blade One screw-pack One installation booklet & optical clothes One Remote Control Set One light fitter and glass ... - Page 5 Parts list for fan with G9 light kit Joist or Beam Canopy Set Screw Metal Round Washer Spring Washer Hook Wood Screw Decorative Housing Ring Fan Motor Blade Metal Round Washer Blade holder set Screw Light Fitter Socket Fitter G9 Bulb (60W included) Glass...
- Page 6 Parts list for fan with LED light kit...
-
Page 7: Installing The Fan
Installing the fan All electrical work should only be undertaken after disconnection of the power by removing fuses or turning off the circuit breaker to ensure all pole isolation of the electrical supply. Your fan can only be installed flush mount style, as following picture. The following steps will guide you to a successful installation: 1. -
Page 8: Wiring Instructions
2. Fan motor housing installation Push down the decorative housing ring, then hang the motor housing on to the “HOOK” that is on the mounting plate for wiring connection. Carefully use one of the holes, not the slots to hang the fan 3. - Page 9 Take the weight of the fan and offer the canopy up to the mounting plate. Two keyed slots in the canopy will align with the two screws that have been left in the mounting plate. Lift the fan and twist the canopy. This will now take the weight of the fan.
- Page 10 5. Attaching the G9 light fitter and glass to the Fan PIC. A PIC. B Release three screws on the bottom of switch box, put light fitter onto switch box, using three screws to fasten light fitter. (See PIC. A), Connector earth wire of light fitter to earth wire from switch box.
- Page 11 5-1 Attaching the LED light fitter and glass to the Fan Release three screws on the bottom of switch box, put light fitter onto switch box, using three screws to fasten light fitter. (See PIC. D). Release three screws on the light fitter, connector earth wire of LED light kit to earth wire from switch box., connect push plug of LED light kit to the push plug from fan.
-
Page 12: Set Up The Remote Control
6. SET UP THE REMOTE CONTROL IMPORTANT : DC MOTOR INITIAL SETUP PROCEDURE. THIS STEP MUST BE PREFORMED BEFORE YOUR FAN WILL OPERATE 1. Set the dip switches with different code which is at inside the battery compartment door of the hand set transmitter if you have more than one set fan to be operated at same room. - Page 13 HOW TO OPERATE THE HANDSET (TRANSMITTER) The wireless remote control is designed to control all commonly used features include the airflow upward and downward reversing function. Turn the ceiling fan off No. 3-- Turn on ceiling fan No. 4 ---Turn on ceiling at Third speed fan at 4 speed...
-
Page 14: Blade Balancing
Blade balancing Whilst every precaution is taken at the factory to ensure your fan is of the highest quality, imbalance may occur. This may be due to slight irregularities in the blades or blade carriers. Deviating from these instructions can cause further problems. The following procedure may help to rectify the situation. -
Page 15: Ceiling Fan Warranty
The ceiling fan itself, excluding accessories such as the Remote Control Transmitter and Receiver, is covered by a 15 year warranty. During this period, Fantasia Distribution Ltd will, at its discretion, repair or replace defective product. During this 15 years, the owner is responsible for labour costs incurred in removing and re-installing the fan, and for transport costs to Fantasia Distribution Ltd’s repair centre. - Page 16 NOTE --------------------------- -----------------------------...
- Page 17 NOTE --------------------------- -----------------------------...
- Page 18 P.14 132cm/52” Zeta FANTASIA DISTRIBUTION LTD. Unit B. The Flyers Way, Westerham, Kent, TN16 1DE Tel : (01959) 564 440 Fax : (01959) 564 829 E-MAIL: info@fantasiaceilingfans.com...
