OWNERS INSTRUCTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT
SUITABLE FOR 230V/50 CYCLE ELECTRICAL SUPPLY
Enquiries on installing your fan please call our help line on
E-mail : technical@fantasiaceilingfans.com
MANUAL
112CM/44"
Orion
INSTALLATION
OPERATION
MAINTENANCE
CAUTION
A QUALIFIED ELECTRICIAN
01959-564440
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fantasia Orion
Summary of Contents for Fantasia Orion
- Page 1 OWNERS INSTRUCTION MANUAL 112CM/44” Orion INSTALLATION OPERATION MAINTENANCE CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT A QUALIFIED ELECTRICIAN SUITABLE FOR 230V/50 CYCLE ELECTRICAL SUPPLY Enquiries on installing your fan please call our help line on 01959-564440 E-mail : technical@fantasiaceilingfans.com...
-
Page 3: Safety Precautions
Safety Precautions To ensure the success of the installation be sure to read the instructions and study the diagrams thoroughly before commencing. All electrical work should only be undertaken after disconnection of the power by removing fuses or turning off the circuit breaker to ensure all pole isolation of the electrical supply. If you are in any doubt the services of a qualified electrician should be sought to ensure that all work is carried out in accordance with the I.E.E. -
Page 4: Supplied Parts
Supplied Parts One fan motor assembly One hanger bracket fitted with terminal block and top rubber washers. One 6” drop rod & top & bottom canopy Pre-fitted One set of blade One screw-pack with balancing kit One installation booklet Remote control set Tools and Materials Required hilips screwdriver Blade screwdriver... - Page 5 Parts names and their relative positions CEILING CEILING BRACKET STEEL WASHER STEEL ROUND WASHER WOOD SCREWS HANGER BALL CANOPY CANOPY SCREW DROP ROD MOTOR HOUSING BLADE WASHER BOTTOM PLATE BLADE SET SCREW...
-
Page 6: Installing The Fan
Installing the fan All electrical work should only be undertaken after disconnection of the power by removing fuses or turning off the circuit breaker to ensure all poles isolation of the electrical supply. Your fan is a drop rod style of fan (Picture A) In this situation the drop rod assembly is used to lower the fan down from it’s mounting position slightly. - Page 7 2. Drop rod assembly Your fan had been pre-assembly with drop rod and canopy. Lift the fan up to the hanger bracket, steer the ball in from the side of the bracket and lower it into there recess of the bracket.
- Page 8 Put the receiver of remote control through hanger bracket (as picture). Connect the A.C. power supply wire that come from the ceiling to the Brown and blue wire of receiver which is mark with label “L” & “N”. In most cases, RED / BLACK wire is LIVE is connected to “L”...
- Page 9 Now lift the canopy carefully up to hanger bracket, carefully push all wires into the canopy. Take care not to trap any wires. Use the canopy set screws to tighten the canopy firmly. Now, your fan installation is complete. Operating instructions Having checked that all electrical connections are securely made and insulated, turn on the power and check the operation of the fan.
-
Page 10: Blade Balancing
Ensure that periodic checks of the fixings takes place. (see Safety Precaution 9) Periodic cleaning of your new Fantasia fan is recommended particularly the blades. The plated or painted surfaces of your fan have been sealed with a lacquer to minimize any discoloration or tarnishing. - Page 11 HOW TO OPERATE THE HANDSET (TRANSMITTER) The wireless remote control is designed to control all commonly used features except the airflow upward and downward reversing function. The reverse switch is on the fan housing (a slide switch). Please change the airflow direction manually. Battery Replacement: Evereadx-A23 Duracell-MS21/MN21...
-
Page 12: Ceiling Fan Warranty
The ceiling fan itself, excluding accessories such as the Remote Control Transmitter and Receiver, is covered by a 10 year warranty. During this period, Fantasia Distribution Ltd will, at its discretion, repair or replace defective product. During this 10 years, the owner is responsible for labour costs incurred in removing and re-installing the fan, and for transport costs to Fantasia Distribution Ltd’s repair centre. - Page 13 ------NOTES------...
- Page 14 112CM/44” Orion FANTASIA DISTRIBUTION LTD. Unit B. The Flyers Way, Westerham, Kent, TN16 1DE Tel : (01959) 564 440 Fax : (01959) 564 829 E-mail : technical@fantasiaceilingfans.com CSA12022101...
- Page 16 Please cut out this warranty page and send it in an envelope to the address below. Alternatively please go to our website www.fantasiaceilingfans.com and fill in the warranty section there. FANTASIA DISTRIBUTION LTD. Unit B. The Flyers Way, Westerham, Kent, TN16 1DE Tel : (01959) 564 440 Fax : (01959) 564 829 E-MAIL: info@fantasiaceilingfans.com...
