TOLERANCE NOTES
FABRICATED TOLERANCES
≥ 2 ft (610 mm) ± 0.250 in (6.4 mm)
< 2ft (610 mm) ± 0.125 in (3.2 mm)
MACHINED TOLERANCES
± 0.050 DECIMAL DIM (1 PLACE)
± 0.010 DECIMAL DIM (2 PLACES)
± 0.005 DECIMAL DIM (3 PLACES)

IMPORTANT SAFETY INFORMATION

The instructions provided in this manual have been prepared to serve as a general guide. It is
intended for use by qualified personnel with knowledge of equipment of this type. It is not
intended to cover all possible variations in equipment or to provide for specific operating
problems which may arise.
You are responsible for adhering to all warnings or cautions provided in this Manual.
In addition to any general safety measures provided in this Manual, you must comply with all
current national, state, local and company safety regulations at all times.
O
BEY ALL SAFETY MESSAGES THAT FOLLOW THESE SYMBOLS TO AVOID POSSIBLE INJURY OR DEATH
RELATED DOCUMENT – MUST COMPLY WITH SCHEDULE DOCUMENT(S):
FOR A LIST OF RELEVANT PATENTS
AND TRADEMARKS PLEASE SEE
CHENTRONICS.COM/LEGAL-NOTICES
ISO 9001 CERTIFIED
DRAWN BY:
ON:
AR
7/8/19
LAST REV BY:
ON:
MNL-ISCAN3
Read All Instructions before Using Equipment
Safety Symbols used in this manual comply with ISO 3864.
T
HESE SYMBOLS ARE USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY HAZARDS
Indicates a hazard with a high level of risk which, if not avoided
will result in death or serious injury.
Indicates a hazard with a medium level of risk which, if not
avoided could result in death or serious injury.
Indicates a hazard with a low level of risk which, if not avoided
will result in minor or moderate injury.
ISCAN3 MANUAL
DCO No
.
12804
DWG. No.
MNL-ISCAN3
THIS
DRAWING
OWNED
BY
CHENTRONICS.
CONDITIONALLY LOANED AND IS TO BE RETURNED UPON
REQUEST. THE BORROWER BY RECEIVING IT HAS AGREED
NOT TO REPRODUCE NOR COPY IT IN WHOLE OR IN PART
NOR TO FURNISH INFORMATION FROM IT TO OTHERS NOR
TO MAKE ANY USE OF IT THAT IS OR MAY BE INJURIOUS TO
CHENTRONICS. FOR MORE INFORMATION PLEASE CONTACT
CHENTRONICS
AT +1.607.334.5531.
.
.
CERT-iS3 MNL
PAGE 3 OF 28
C
REV.
IT
IS
