Technical Specifications

Definitions

FLICKER – Flicker or Flicker Frequency refers to the modulation of flame intensity due to micro-
explosions.
FDORT – Flame Detector ON Response Time – the period of time from flame intensity rising
above the user adjustable threshold to flame relay contacts closed.
FDRT – Flame Detector Response Time –the period of time between the loss of a sensed flame
and the signal indicating the absence of flame.
MFFRT – Marginal Flame Fail Response Time – period of time from flame intensity falling below
the the user adjustable threshold to the flame relay contacts open.
ROL – Ring of Light – multi-colored LED status indication on the back of the scanner.
iScan Software – Flame Scanner Communications software used to monitor and configure the
iScan3 device.
GAIN – When a signal is amplified, GAIN is the ratio of the amplified signal relative to the
original.
DISCRIMINATION – The ability to distinguish between multiple flames. An example of good
discrimination is when the MB scanner is able to recognize a pilot flame with other burner's
main fuel flame in the background. The status of the background Flames does not affect the
ability to detect the pilot flame (ON or OFF).
