1.0 Important Safety Information
The instructions in this manual serve as a general guide. It is intended for use by qualified personnel with
knowledge of equipment of this type. It is not intended to cover all possible variations in equipment or to
provide for specific operating problems which may arise.
You are responsible for adhering to all warnings or cautions provided in this manual.
In addition to any general safety measures provided in this manual, you must comply with all national,
state, local, and company safety regulations.
O
BEY ALL SAFETY MESSAGES THAT FOLLOW THESE SYMBOLS TO AVOID POSSIBLE INJURY OR DEATH
RELATED DOCUMENT – MUST COMPLY WITH SCHEDULE DOCUMENT(S):
FOR A LIST OF RELEVANT PATENTS
AND TRADEMARKS PLEASE SEE
CHENTRONICS.COM/LEGAL-NOTICES
ISO 9001 CERTIFIED
DRAWN BY:
ON:
2021-MAY-14
AR
LAST REV BY:
ON:
2022-AUG-01
AR
MNL-ISCAN3
Read All Instructions Before Using Equipment
Safety Symbols used in this manual comply with ISO 3864.
T
HESE SYMBOLS INDICATE POTENTIAL PERSONAL INJURY HAZARDS
Indicates a hazard with a high level of risk, which, if not avoided,
will result in death or severe injury.
Indicates a hazard with a medium level of risk, which, if not
avoided, could result in death or severe injury.
Indicates a hazard with a low level of risk, which, if not avoided,
will result in minor or moderate injury.
