Product Features

The iScan3 flame scanner is designed to detect flame from fossil fuels such as natural gas, refinery gas,
waste gas, fuel oils, biomass and coals. The iScan3 consists of an integrated viewing head and signal
processor. No secondary signal processor or amplifier is required.

Ease of Installation

QUICK-CONNECT BURNER MOUNT:
The simple cam-and-groove mechanism allows for quick mounting, release, and rotation of the scanner.
