Read and follow all safety information carefully.  The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or
minor) and the occurrence of injury (definitely occurs or has the potential to occur) when the
warning is ignored:

 DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.

 WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.


 CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.


Basic safety precautions should be followed, including the following:
Ensure all Local, State, and Federal Laws and Codes including health and safety guidelines are met
when installing Waterlogic Equipment.   Only qualified service technicians should attempt
installation and service of Waterlogic Equipment.  Always read the entire operating instructions
before using the appliance and save these instructions for future use.

DANGER!  This product can cause death or severe injury if incorrectly operated, installed or
maintained. The installation, maintenance, sanitizing and any repair must be performed by
qualified persons trained by Waterlogic International or their approved distributors only.  Do not
remove any panel or cover to protect against electrical shock and exposure to UV radiation.


DANGER! ELECTRICAL SHOCK HAZARD.  Always use a dedicated and properly grounded outlet.
Unit should be protected by ground‐fault circuit interrupter (GFCI) or residual current device (RCD)
having a rated residual operating current not exceeding 30mA.  Use only Waterlogic supplied
power cord. Never use extension cords or power strips to connect unit. Do not use if the power
supply cord is damaged. Always unplug from power supply prior to servicing.


WARNING!  AUTHORIZED USE ONLY.  This appliance is to be used for its intended purpose as
described in this manual and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury.  This appliance can't be used by children and persons
with reduced physical, sensory or mental capabilities or lack of experience.

WARNING!  DO NOT OPERATE IF DAMAGED.  Unplug and isolate water supply if abnormal
conditions exist. Contact Waterlogic or authorized dealer for repair, service, and installation to
avoid hazards.

WARNING! CONNECT TO POTABLE WATER SUPPLY.  This system is to be used for water only and is
not intended for use where water is microbiologically unsafe or with water of unknown quality
without adequate disinfection before or after the system.


BLUPURA Fizz 80 Manual
SAFETY ALERT SYMBOLS

SAFETY PRECAUTIONS
                                                            Page 4 ‐ Revision: 11‐2‐2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUPURA FIZZ 80 and is the answer not in the manual?

Questions and answers

Summary of Contents for WaterLogic BLUPURA FIZZ 80

  • Page 1    DANGER!    Indicates a situation which, when not avoided, results in death or severe injury.       WARNING!    Indicates a situation which, when not avoided, has the potential to result in death or severe  injury; and/or severe property damage.         CAUTION!    Indicates a situation which, when not avoided, results or has the potential to result in minor  injury; and/or minor property damage.     SAFETY PRECAUTIONS    Basic safety precautions should be followed, including the following:  Ensure all Local, State, and Federal Laws and Codes including health and safety guidelines are met  when installing Waterlogic Equipment.   Only qualified service technicians should attempt  installation and service of Waterlogic Equipment.  Always read the entire operating instructions  before using the appliance and save these instructions for future use.    DANGER!  This product can cause death or severe injury if incorrectly operated, installed or  maintained. The installation, maintenance, sanitizing and any repair must be performed by  qualified persons trained by Waterlogic International or their approved distributors only.  Do not  remove any panel or cover to protect against electrical shock and exposure to UV radiation.        DANGER! ELECTRICAL SHOCK HAZARD.  Always use a dedicated and properly grounded outlet.   Unit should be protected by ground‐fault circuit interrupter (GFCI) or residual current device (RCD)  having a rated residual operating current not exceeding 30mA.  Use only Waterlogic supplied  power cord. Never use extension cords or power strips to connect unit. Do not use if the power  supply cord is damaged. Always unplug from power supply prior to servicing.      WARNING!  AUTHORIZED USE ONLY.  This appliance is to be used for its intended purpose as  described in this manual and untrained individuals who use this manual assume the risk of any  resulting property damage or personal injury.  This appliance can’t be used by children and persons ...
  • Page 2 WARNING!  TIP HAZARD.  Dispenser could tip or fall causing serious injury.  Always install unit on a  firm, flat, and level surface and secure unit to cabinet, wall, or floor if needed.  Never place heavy  items on top of unit and never climb, stand, or hang on unit or storage cabinet to prevent injury  and damage.    WARNING!  UNIT IS HEAVY.  TWO PERSON LIFT REQUIRED.  Transport unit empty and always use    material handling equipment or two people with proper lifting technique to reduce injury risk.             WARNING!  STORE AND TRANSPORT UNIT EMPTY.   ALWAYS SANITIZE BEFORE USE.  The unit must be completely drained before storing to avoid stagnation and reduce  microbiological contamination (potential bacterial growth).  Always sanitize before use to  eliminate any potential microbiological contaminates.      CAUTION!  INDOOR USE ONLY.   Intended for Household Use.  Never expose to direct sunlight,  heat sources, or ambient air temperature above 37°C (100°F) or below 2°C (35°F).  Install indoors  and keep unit away from excessive humidity.  Never expose to freezing temperatures.  Ensure  there is adequate clearance around the unit to allow refrigeration system condenser to dissipate  heat.  Warmer environments require more clearance around the unit.  Minimum clearance around  all surfaces of the machine is 2‐inches.  Installs where the ambient temperature exceeds 27°C  (80°F), require a minimum of 4‐inches clearance for proper heat dissipation and efficient  operation.       CAUTION!  USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or  damage caused by excessive water pressure.  Input or feed pressure must be 40 psi to 60 psi.  Be  aware of any potential pressure surges caused by building/municipal pumping stations.      CAUTION!  USE UV STABILIZED SUPPLY LINES.  Feed the unit with a potable ambient or cold  water supply only.  Feed water over 37°C (100°F) can damage the treatment components.  Water  block devices and external leak detectors are strongly recommended. Locate the unit as close to  the water supply and the electrical connections as possible.  Locate the unit as close to the water  supply and the electrical connections as possible.  Immediately isolate or close water supply valve  and contact service representative if leak is noticed.    Contact Waterlogic for assistance or help finding an Authorized Service Representative.      BLUPURA Fizz 80 Manual                                                              Page 5 ‐ Revision: 11‐2‐2018 ...
  • Page 3 BLUPURA FEATURES AND BENEFITS      Cold and Cold Sparkling Water   Cold and Cold Sparkling Water set points are programmable to meet a wide range of customer  demands with high capacity of 14 Liters (3.7 Gallons).    High Output of Cold and Sparkling Water   Highly insulated Ice Bank has a Cooling capacity of 80 Liters per hour (20 Gallons per hour) with an  output of cold and sparkling water of 45 Liters (12 Gallons) of continuous supply.      Dispense Flow Rate   Dispense flow rate is adjustable directly on the Column Tap for customer ease.    Large Dispense Area   12.6 inch dispense height with a removable drip tray.       State of the Art Technology  The  supply head brings contemporary style and state‐of‐the‐ BLUPURA FIZZ 80 Water Treatment System  art technology to commercial water dispensers combining professional performance with a modern,  sleek design.    Modern Design Using Strong Materials  A modern design using strong materials and a front plexiglass panel with elegant lighting.    No Accidental Water Leakage  The Column Tap self closes to avoid accidental water leakage in addition to a compensator to  regulate the flow of each spout.       Recyclable Materials  The  and Column Tap are made with natural  BLUPURA FIZZ 80 Water Treatment System  and recyclable materials throughout unit; stainless steel, aluminum and glass.  The  internal components are made entirely of stainless steel.   Using recyclable material  prevents potential negative consequences for the environment and for health.      Maintenance Access  Easy open for maintenance. ...
  • Page 4: Specifications

    MODEL/PART DESIGNATIONS    MODEL  DESCRIPTION  BLUPURA FIZZ 80  Carbonation Chiller with Integrated Taps  900583        SPECIFICATIONS  ITEM  SPECIFICATION  Ice Bank Capacity  14 Liters (3.7 Gallons)  Cooling Capacity  80 Liters per Hour (20 Gallons per Hour)  Adjustable ‐ 3° ‐ 10°C (37.4° - 50° F)  Cold Water Temperature  Water Connection  3/8” Inlet Water Pipe   Recommended Service  14.5 ‐51 psi (.10 MPa – 0.35 MPa) – Use Pressure Regulator Pressure  *specification label on back of machine states 51/58 psi (which one is correct?)  >0.8 Gallons per Minute   Incoming Flow Rate  Minimum of 0.8 is recommended to enhance the quality of the sparkling water  dispensed    Rated Service Flow  >0.8 Gallons per Minute   Maximum Service Pressure  100 psi (689 kPa) – Use Pressure Regulator  Environmental Temperature 16°C (32°F) to 32°C (90°F) ...
  • Page 5: Shipping Specifications

    SHIPPING SPECIFICATIONS  ITEM  UNIT  SHIPPING BOX  360 x 566 x 570 mm  420 x 590 x 720 mm  Width/Depth/Height  14.2 x 22.3 x 22.4 Inches  16.5 x 23.2 x 28.3 inches  Weight (dry)  27 kg (59 pounds)   30 kg (66 pounds)             ELECTRICAL SPECIFICATIONS  ELECTRICAL SUPPLY  120V/60Hz, 1PH  15 Amp Service  Certified to UL‐399 and  POWER (approximate)  AMP DRAW (approximate)  CSA Standard C22.2 No.  330 Watts  3.20 Amps  120        BLUPURA Fizz 80 Manual                                                              Page 8 ‐ Revision: 11‐2‐2018 ...
  • Page 6 OPERATING INSTRUCTIONS          Cold Sparkling  Cold Water     Water                                          For Cold Sparkling Water:   Pull Tap Knob forward to start dispensing.  Push Tab Knob back to stop dispensing.        For Cold Water:      Pull Tap Knob forward to start dispensing.  Push Tab Knob back to stop dispensing.       ...
  • Page 7 DAILY MAINTENANCE REQUIRED BY CUSTOMER    Keep your BLUPURA FIZZ 80 Water Treatment System in showroom condition and disinfected.      1. Clean outside of the BLUPURA FIZZ 80 Water Treatment System by hand with a disposable  towel and a rinse free anti‐citrus product.  To remove lime stains, use a stainless‐steel  cleaning product with a disposable towel.    *To remove limescale, use a slightly acidic product (e.g. citric acid) that has been heavily  diluted.  Excessive acidity may damage the surface of the steel.    2. Clean Grill and Drip Tray with non‐foaming detergent or a diluted limescale cleaner such as  citric acid and a plastic brush.  *The Drip Tray may be washed in the dishwasher.    3. Glass facing on front of unit may be cleaned using multi‐use cleaners or dedicated glass  cleaners.     NOTE: DO NOT USE THE FOLLOWING PRODUCTS! Using the following product can cause  surface pitting, oxidization and give the impression that the surface of the product is rusting.       Full strength bleach.  Only use bleach diluted 1‐ All outside  surfaces.  part bleach to 4 parts water.   Metal fibers (if a brush is needed, use plastic  brushes).  Glass    Abrasive cleaners or abrasive pads.   Water jet.  Grill     and Drip   4.
  • Page 8 WEEKLY MAINTENANCE REQUIRED BY CUSTOMER    Use a vacuum to clean out all vents.    BLUPURA Fizz 80 Manual                                                              Page 11 ‐ Revision: 11‐2‐2018 ...
  • Page 9 Return Authorization which you must obtain prior to shipping the product. You are responsible for the  cost of freight in to Waterlogic.    Waterlogic and its affiliated companies hereby limit the duration of any and all implied warranties to  a maximum period of three (3) years from the date of purchase including, but not limited to, the  implied warranties of merchantability and fitness for a particular purpose. Some states do not allow  limitations on how long an implied warranty lasts, so the above limitation may not apply to you.  Consequential and incidental damages are not recoverable under this warranty. Some states do not  allow the exclusion or limitation of incidental or consequential damages, so the above limitation or  exclusion may not apply to you.    This warranty gives you specific legal rights and you may also have other rights which may vary from  state to state.    New Warranty Policy issued by Waterlogic Commercial Products LLC, USA ‐ January 10, 2014    Waterlogic Commercials Products LLC              Tel: (800) 288‐1891  11710 Stonegate Circle                      Website:  waterlogic.us  Omaha, NE  68164 ...
