- Page 1 GRUNDFOS INSTRUCTIONS CRN MAGdrive without motor Supplement to installation and operating instructions for CRN...
-
Page 2: Limited Warranty
Grundfos or an authorized service station for instructions. Any defective product to be returned to Grundfos or a service station must be sent freight prepaid; documentation supporting the warranty claim and/or a Return Material Authorization must be included if so instructed. - Page 3 1. Fitting the magnetic drive, motor stool and motor See also installation and operating instructions for CR, CRI, CRN – Grundfos literature number L-CR-TL-001. Also refer to the CRN MAGdrive installation and operating instructions, L-CRN-TL-01. These instructions must be followed when removing the motor stool and when fitting the magnetic drive, motor stool and motor.
- Page 4 CRN 1s, 1, 3, 5, 10, 15, 20: 1/2 to 3 Hp Step Illustration Step Illustration Pos 3/6 Pos 2 Pos 3 Pos 1 ½ Pos 4...
- Page 5 Overview of hardware Pos. Quantity and dimension Fixing parts Torque 2 x M6 4.4 ft.-lbs. 4 x 3/8" 17 ft.-lbs. 4 x 1/2" 30 ft.-lbs. 4 x M12 44 ft.-lbs. 4 x M4 x 8 1.5 ft.-lbs. *Bolt size and flange thread will vary with the motor size.
- Page 6 CRN 1s, 1, 3, 5: 5 to 7.5 Hp CRN 10, 15, 20: 5 to 25 Hp CRN 32, 45, 64, 90: 5 to 30 Hp Step Illustration Step Illustration 0 mm Pos 1 Pos 2* Pos 4 Pos 5*...
- Page 7 Overview of hardware Pos. Quantity and dimension Fixing parts Torque 2 x M6 4.4 ft.-lbs. 4 x 3/8" 17 ft.-lbs. 4 x 1/2" 30 ft.-lbs. 4 x M12 44 ft.-lbs. 4 x M4 x 8 1.5 ft.-lbs. * Bolt size and flange thread will vary with the motor size.
- Page 8 New 0609 96834919 0908 U.S.A. Canada México GRUNDFOS Pumps Corporation GRUNDFOS Canada Inc. Bombas GRUNDFOS de México S.A. de C.V. 17100 West 118th Terrace 2941 Brighton Road Boulevard TLC No. 15 Olathe, Kansas 66061 Oakville, Ontario Parque Industrial Stiva Phone: +1-913-227-3400...
