Instructions of use Boogie Drive
1 Chest pad
2 Therapy table
3 Crank for posterior truss pad with
swivel bracket
4 Drum brake hub
5 Driving wheel
7
6 Handrim
7 Belt for chest trust pad
8
8 Star grip lock for the
pelvic truss pad with crank and
swivel bracket
9
9 Cushion for posterior truss pad
10 Axle plate
11 Knee truss pad
12 Footrest
10
13 Locking lever for swivel caster
11
14 Rear swivel caster
12
13
14
15
16
15 Side chest pad
17
16 Cushion for posterior truss pad
18
17 Swivel bracket
18 Side posterior truss pad
19 Centre column
19
20 Gas pressure spring
21 Front swivel caster
22 Release pedal for
gas pressure spring
