3.2 Handling centre column

3.2.1 General information regarding centre column

In order to adjust the angle with the gas pressure spring, the occupant and/or the centre
column must be held using both hands while the tripping lever is actuated, since otherwise
the occupant could tilt forwards abruptly and injure themselves.
The angle may only be adjusted with telescope and clamp lever if there is no occupant in
the standing trainer.
Angle adjustment with gas pressure spring:
(1)
Telescope and clamp lever angle adjustment:
(1)
2.
2019-08-15
1.
1.
Instructions of use Boogie Drive
(2)
1.
(2)
15 of 32
