- Page 1 NovaScale 9006 Server VGA Kit Service Sheet September 2009 REFERENCE 86 A7 82FB 00...
-
Page 2: Trademarks And Acknowledgements
Quoting of brand and product names is for information purposes only and does not represent trademark misuse. The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material. - Page 3 Servicing the VGA Kit The VGA Kit is located on the Dummy CSI Interconnect Board (DSIB) (E) inside the server drawer. This kit allows the connection of a VGA Cable to the DSIB board. Figure 1. Locating the VGA kit WARNING This component is NOT hot-swappable.
- Page 4 Procedure 1. Unpack the new component on a clean ESD-protected work surface. 2. Open the cabinet front door. 3. Power down the server drawer. 4. Open the cabinet rear door. 5. Disconnect the related cables (rear). 6. Place the Server Drawer in the Servicing Position. 1.
- Page 5 3. From the front of the cabinet, release the two captive screws securing the server drawer to the cabinet rack (A). Figure 3. Server drawer rack fixture screws 4. Slowly pull the server drawer forward until the rails are fully extended and locked, taking care not to snag or loosen connected cables.
- Page 6 7. Unlock/Open the Front Cover. 1. Press the 2 locking studs (A) on each side of the server drawer to unlock the front cover. 2. Raise the front cover to an angle of 45°. Figure 5. Front cover raised 8. Remove the Front Cover. Slide the raised front cover upward and remove it.
- Page 7 9. Remove the Rear Cover. 1. Slide the rear cover backwards. Figure 7. Removing the rear cover 2. Lift up and away from the server drawer to remove it. Servicing the VGA Kit...
- Page 8 10. Disconnect the Rear Right Cable Bundle. mportant Check that all cables are correctly labeled before disconnecting. The rear right cable bundle comprises the following cables: • ILB-PDB 3.3V STBY Cable • ILB-HDX Signal Cable • PDB_ILB 12V Cable • PDB_MTB 12V Cable 1.
- Page 9 2. Disconnect the cables from the boards: PDB_ILB 12V Cable (A) from the ILB ILB-PDB 3.3V STBY Cable (B) from the ILB ILB-HDX Signal Cable (C) from the ILB PDB_MTB 12V Cable (D) from the MTB Figure 9. Disconnecting the rear right cables 3.
- Page 10 11. Disconnect the Rear Left Cable Bundle. mportant Check that all cables are correctly labeled before disconnecting. The rear left cable bundle comprises the following cables: • PDB_MTB 12V Cable • ILB-PDB 3.3V STBY Cable • LCP-ILB Mixed Cable • ILB-HDX Signal Cable •...
- Page 11 2. Disconnect the cables from the boards: PDB_MTB 12V Cable (A) from the MTB ILB-HDX Signal Cable (B) from the ILB LCP-ILB Mixed Cable (C) from the ILB ILB-PDB 3.3V STBY Cable (D) from the ILB Figure 11. Disconnecting the rear left cables 3.
- Page 12 12. Disconnect the VGA Cable Disconnect the VGA Cable (A) from the ILB board (B). Figure 12. Disconnecting the VGA Cable 13. Remove the DSIB. 1. Loosen the two large screws(A) securing the DSIB to the rear of the server drawer alternatively, beginning with the screwdriver and ending manually.
- Page 13 2. Carefully pull the board out of the server drawer. mportant The DSIB board is secured to the rear of the server drawer by a tenon-mor tise device. Take care not to damage connectors when removing the board. 14. Servicing the VGA Kit With the T10 TORX screwdriver, unscrew the 4 M3 screws (A) to remove the VGA bracket from the DSIB board.
- Page 14 16. Install the DSIB. 1. Align the board with the rear of the server drawer. The locking flap(A) on the rear panel of the server drawer enters the dedicated opening in the DSIB board(B). Figure 16. Aligning the DSIB board 2.
- Page 15 3. Tighten the two large screws(A) alternatively, beginning manually and ending with the screwdriver, until all the connectors are plugged in and the board is locked into place. Figure 18. Locking the DSIB board 17. Connect the VGA Cable Connect the VGA Cable (A) to the ILB board (B). A foolproofing device prevents cabling errors.
- Page 16 18. Connect the Rear Left Cable Bundle. The rear left cable bundle comprises the following cables: • PDB_MTB 12V Cable • ILB-PDB 3.3V STBY Cable • LCP-ILB Mixed Cable • ILB-HDX Signal Cable • 2 x ILB-HDX SATA Cable 1. Route the cables as shown in the following figure. mportant Comply with the cable placement shown in the figure.
- Page 17 3. Connect the cables to their related boards, as shown in the following figures: a. Step 1: . PDB_MTB 12V Cable(A) to the MTB . ILB-HDX Signal Cable(B) to the ILB . LCP-ILB Mixed Cable(C) to the ILB b. Step 2: ILB-PDB 3.3V STBY Cable(D) to the ILB Figure 21.
- Page 18 c. Step 3: ILB-HDX SATA Cables . Instructions for SATA disks: Connect cables(E) and (F) to the SATA 0 and 1 connectors on the ILB board. To facilitate cable placement, release the second ILB-HDX SATA Cable from the second cable strap. Figure 23.
- Page 19 4. Add the PCIe separator, if required. Figure 25. Adding the PCI separator 19. Connect the Rear Right Cable Bundle. The rear right cable bundle comprises the following cables: ILB-PDB 3.3V STBY Cable ILB-HDX Signal Cable PDB_ILB 12V Cable PDB_MTB 12V Cable 1.
- Page 20 2. Close the cable straps to secure the cables into place. Figure 27. Mounting of a cable clip 3. Connect the cables to their related boards: PDB_ILB 12V Cable (A) to the ILB ILB-PDB 3.3V STBY Cable (B) to the ILB ILB-HDX Signal Cable (C) to the ILB PDB_MTB 12V Cable (D) to the MTB Figure 28.
- Page 21 4. Add the PCIe separator, if required. Figure 29. Adding the PCIe separator 20. Install/Lock the Rear Cover. 1. Lower the rear cover onto the server drawer, taking care to place the locking tabs in the slots located on each side of the drawer. 2.
- Page 22 21. Install the Front Cover. 1. Place the front cover at an angle of 45° and slide into position, taking care to insert the locking tabs on the rear cover into the slots on the front cover. Figure 31. Installing the front cover 2.
- Page 23 22. Return the Server Drawer to the Operating Position. 1. From the front of the cabinet, raise the two thumb levers on the rail assemblies. 2. Push the server drawer fully backward until it is flush with the cabinet rack. 3.
- Page 24 4. From the rear of the cabinet, unlock the two red cable hanger stop pins by turning them 90°. Figure 34. Unlocking cable hanger stop pins 23. Connect the related cables (rear). 24. Close the cabinet rear door. 25. Power up the server drawer. 26.
- Page 25 28. From the server hardware console, check correct hardware operation as explained in Steps 29, 30 and 31. 29. Viewing Monitoring Sensors 1. From the Monitoring tab, click System Health > Sensors to display the Sensor Status page. 2. Click Refresh and check that all component icons are green. mportant The Sensor Status page is not automatically updated, therefore the display may not reflect current sensor status.
- Page 26 Sensor Status Page - Icons, Values and Readings Icon Type Name Status Reading • No reading System ACPI • S0/G0: working ACPI Pwr State Power State • S4/S5: soft off • No reading • Device Present • Device Absent Power Supply PS_X •...
- Page 27 Use the Clear button to empty the log. Entries are deleted and cannot be retrieved. Note SEL messages and associated operation to recover are explained in the NovaScale 9006 Service Guide in the Troubleshooting the NovaScale 9006 Server Drawer chapter. 31. Viewing Board and Security Messages 1.
