Eaton PWHR1234W2FR Instructions Manual
Internal battery for use with the eaton 9155 (8/15kva) ups, eaton 9355 (10/15kva) ups or eaton extended battery module (ebm)
Hide thumbs
Also See for PWHR1234W2FR:
- Instructions manual (16 pages) ,
- Instructions manual (20 pages)
Related Manuals for Eaton PWHR1234W2FR
Summary of Contents for Eaton PWHR1234W2FR
- Page 1 Eaton ® ® Internal Battery Instructions For use with the Eaton 9155 (8/15 kVA) UPS, Eaton 9355 (10/15 kVA) UPS or Eaton Extended Battery Module (EBM) p/n: 164201628 Revision C0...
- Page 2 National Fire Protection Association, Inc. ERIFLEX and FLEXIBAR are registered trademark of Erico International Corporation. All other trademarks are property of their respective companies. ©Copyright 2006-2019 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.
-
Page 3: Table Of Contents
I I n n s s t t a a l l l l a a t t i i o o n n ............................................................5 5 Battery Type..............................5 Installing the Internal Batteries ........................... 5 Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0... - Page 4 Table of Contents Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
-
Page 5: S S A A F F E E T T Y Y W W A A R R N N I I N N G G S S A A N N D D S S Y Y M M B B O O L L S S , , C C O O N N T T R R O O L L S S , , A A N N D D I I N N D D I I C C A A T T O O R R S
• ELECTRIC ENERGY HAZARD. Do not attempt to alter any battery wiring or connectors. Attempting to alter wiring can cause injury. Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0... -
Page 6: Consignes De Sécurité
Tout contact avec une partie d'une batterie mise à la terre peut engendrer un choc électrique. La probabilité d'un tel choc sera réduite si de telles masses sont retirées durant l'installation et la maintenance. Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0... -
Page 7: Advertencias De Seguridad
La probabilidad de una descarga de este tipo se reducirá si se eliminan dichas conexiones a tierra durante la instalación y el mantenimiento. Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0... -
Page 8: Symbols, Controls, And Indicators
Phillips and Pozidriv are registered trademarks of Phillips Screw Company. ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. -
Page 9: I I N N S S T T A A L L L L A A T T I I O O N
When purchasing UPS cabinets or extended battery modules without batteries, only the following types are recommended. Use of any other battery type inside Eaton cabinets will void the product warranty. For full battery life, keep the UPS at an ambient temperature of 25°C (77°F). - Page 10 Remove the battery trays and the bag containing the jumper wires and battery tray wiring harnesses. Insert the batteries into the battery trays. Connect seven jumper wires between the batteries in each tray (see Figure Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
- Page 11 Figure Figure 4. Connecting the Battery Tray Wiring Harness Battery Tray Wiring Harness Black Wire Red Wire Front End of Tray Tray Slots Back End of Tray Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
- Page 12 Back End of Tray Top View of Tray Front End of Tray 10. Verify that the UPS battery circuit breaker is in the OFF position (see Figure Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
- Page 13 Battery Circuit Breaker 11. Connect the cabinet wiring harness to the battery tray wiring harnesses, red connector to red connector, black connector to black connector (see Figure 7 Figure Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
- Page 14 Figure 7. Internal Battery Tray Wiring Connections Black Connector Connector Black Connector Connector Cabinet White Wire Wiring Harness Black Wire Wire Black Black White Wire Black Black Battery Tray Battery Tray Wiring Wiring Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
- Page 15 BLACK WHITE 12. Repeat these steps to connect each battery tray to the cabinet wiring harness. 13. Reinstall the battery cover panel(s). 14. Replace the front cover(s). Internal Battery Instructions for the Eaton 9155 or 9355 (10/15 kVA) 164201628—Rev C0...
