IMI+70-XF-XC-XP-XT Issue 7
2400 & 1400 Series (XP, XT, XC & XF)
Flame Proof Camera Housings
& Pan Tilt Units
IECEx/ATEX Certified
II 2 G Ex db IIC
II 2 D Ex tb IIIC
Installation & Maintenance Instructions
This manual should be read before attempting to connect or operate the equipment
This equipment shall be installed in accordance with the latest local/national codes of practice, and standards
eg :- BS EN 60079-14:2014 Explosive atmospheres – Part 14: Electrical installations design, selection and erection
(IEC 60079-14:2013)
Whilst every effort has been made to ensure that all information in this document is correct at the time of
publication, due to our policy of continuous improvement, the company reserves the right to change any
information contained herein without notice or reference.
With the exception to Annexe B which must be referred to the certification Body.
Advertisement
Table of Contents
Related Manuals for Eaton 2400 Series
Summary of Contents for Eaton 2400 Series
- Page 1 IMI+70-XF-XC-XP-XT Issue 7 2400 & 1400 Series (XP, XT, XC & XF) Flame Proof Camera Housings & Pan Tilt Units IECEx/ATEX Certified II 2 G Ex db IIC II 2 D Ex tb IIIC Installation & Maintenance Instructions This manual should be read before attempting to connect or operate the equipment This equipment shall be installed in accordance with the latest local/national codes of practice, and standards eg :- BS EN 60079-14:2014 Explosive atmospheres –...
- Page 2 Inclusion of Ex ia removal of ratings page 5 Additions to 05/04/2016 annexe E 06/04/2016 Change in Harmonised standard issues Change Cert Number, Address, authorised signatory. 01/09/2016 Addition of amendment record. Special Conditions. 13/10/2016 Change in Name and cert labels 16/11/2016 Removed DOC © 2016, Eaton Page 2 of 21...
-
Page 3: Table Of Contents
Annexe to Manual A. Ex Annexe (ATEX Controlled Document) 21-22 Before Installation of the equipment ensure that: The installation instructions are read and understood The correct tools are available for use when installing © 2016, Eaton Page 3 of 21... -
Page 4: General
A readily accessible disconnection device shall be incorporated in the electrical installation wiring, to provide all pole isolation of the supply to the equipment. Only use tools and replacement parts supplied or recommended by EATON. This unit does not contain any user serviceable parts. -
Page 5: Description
ATEX Directive 2014/34/EU and IECEX, with the ratings as detailed in: Section 6.0 Specifications, Technical data & Special conditions for safe use. Note: T class and ambient temperature, is dependent on the assembly configuration and maximum internal power dissipation. © 2016, Eaton Page 5 of 21... -
Page 6: Versions
EX Main Flange Seal Kit (117.07x3.53 O-ring + 5x M6x16 A4 socket head screws) OX10-00008 WIPPER BLADE ASSEMBLY OX10-00062 HOUSING WASHER NOZZLE ASSEMBLY OX10-00063 XP20 CONTINUOUS ROTATION WASHER NOZZLE ASSEMBLY OX10-00134 XP40 CONTINUOUS ROTATION WASHER NOZZLE ASSEMBLY © 2016, Eaton Page 6 of 21... -
Page 7: Eaton Installation & Maintenance Instructions Imi+70-Xf-Xc-Xp-Xt Issue
Due care must be taken to ensure sufficient clearance is allowed to permit full rotation of the unit with its associated equipment mounted and that the moving unit cannot make contact with personnel. It is strongly suggested that where possible the EATON range of mounting brackets are used 3.2.1 Mounting the XP & XT Series... - Page 8 EATON Installation & Maintenance Instructions IMI+70-XF-XC-XP-XT Issue 7 Fig.1 XP26VW Example XP Series unit showing base mount fixing points Fig.2 BPW6800 Wall Bracket © 2016, Eaton Page 8 of 21...
- Page 9 EATON Installation & Maintenance Instructions IMI+70-XF-XC-XP-XT Issue 7 Fig.3 XC40VW Example XC Series unit showing shaft mount fixing points Fig.4 BFW5000 Wall Bracket Fig.5 BFP0600/900/1200 Column Spacer © 2016, Eaton Page 9 of 21...
-
Page 10: Mounting The Xf Series
The type and size of these fixings to be supplied by the user/installer and must be suitable for the specific installation requirements. To gain flexibility of the cameras view direction one of the EATON is needed, these comprise of the BFP00SW Swivel joint (Fig 7), the BFW32SW (Fig 8) or a combination of the BFW5000 and BFP00SW. -
Page 11: Accessory Installation
Long and Medium sunshield have four equally sized fixings for each corner but the short sunshield has two fixing types, one for the front and shorter screws and nylon spacer at the rear. (Fig 10) Fig.9 Mid and Long Housing Sunshield Installation Fig.10 Short Housing Sunshield Installation © 2016, Eaton Page 11 of 21... -
Page 12: Washer Nozzle Installation
For non-continuous rotation P&Ts and fixed housings the washer nozzle is installed on the front window flange. (Fig. 13) Fig.11 260mm Housing washer nozzle Fig.12 400mm Housing washer nozzle Fig.13 Non-continuous Rotation P&Ts and Fixed housings washer nozzle © 2016, Eaton Page 12 of 21... -
Page 13: Electrical Installation
All glands/reducers must be ingress protected to IP67 or better, to maintain the weatherproof rating of the equipment. For maintenance purposes, consult separately supplied additional wiring drawings specific to the purchase order, for as built wiring and connection details of the unit. © 2016, Eaton Page 13 of 21... -
Page 14: Xp & Xt Common Connection Examples
N 24VAC VIDEO SIGNAL VIDEO SIGNAL PUMP SUPPLY 23VAC IP MODEL 110VAC FIBRE OPTIC MODEL EARTH EARTH 230VAC L 110VAC L VARIOUS FIBRE RJ45 INLINE 110VAC N 230VAC N BULKHEAD CONNECTORS ETHERNET CONNECTOR FIBRE © 2016, Eaton Page 14 of 21... -
Page 15: Electrical Installation Xf & Xc Series Units
Next slide out the camera mounting rail to reveal the incoming cable connection terminals. Warning : This cover must not under any circumstances be removed until at least 5 minutes after the disconnection of power source. © 2016, Eaton Page 15 of 21... -
Page 16: Xc & Xf Common Connection Examples
24VAC IP MODEL NO PUMP OUTPUT 24VAC N 24VAC N 24VAC L 24VAC L EARTH EARTH DATA B - ETHERNET DIRECTLY TO DATA A + CAMERA OR ENCODER VIDEO DIRECT TO CAMERA VIA CAT5E, RJ45 © 2016, Eaton Page 16 of 21... -
Page 17: Maintenance
In atmospheres that are high in corrosive particles the units should be cleaned every 3 to 4 months using only EATON recommended cleaning products and procedures. (contact EATON for details) EATON takes no responsibility for oxidisation due to failure in correctly following cleaning procedures. © 2016, Eaton... -
Page 18: Labelling
D - EX ratings, E - ATEX Certificate & IECEX certificate numbers, F - Serial Number, G - Notified Body Number Standard Enclosure label OP PR Enclosure label OP IS Enclosure label [Ex ia Ga] Enclosure label © 2016, Eaton Page 18 of 21... -
Page 19: Specifications, Technical Data
6. Only armoured cable or conduit is to be utilized when fitted with a fibre optic output in order to protect the fibre optic cable. 7. Precautions must be taken to avoid dust from forming layers on the equipment. © 2016, Eaton Page 19 of 21... - Page 20 -40°C to +55°C , -40C to +70C, -60C to +70C Wireless Ex ia T6: -40°C ≤ Tamb ≤ +40°C T5: -40°C ≤ Tamb ≤ +50°C or T5: -40°C ≤ Tamb ≤ +55°C © 2016, Eaton Page 20 of 21...
- Page 21 EATON Installation & Maintenance Instructions IMI+70-XF-XC-XP-XT Issue 7 A. Ex Annexe continued (b) Conditions of Manufacture, Routine tests, A routine overpressure test in accordance with IEC 60079-1:2014 Clause 16.1 shall be carried out on all enclosures, including all cemented window assemblies, at a pressure of 30.12bar for a period of between 10 and 60 seconds, details must be recorded and records maintained.
