Page 1: Operating Instructions
Operating instructions GK25TE Toptronic hob... - Page 2 The product family (model number) corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Type Product family GK25TE/F 005, 31023 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2017...
-
Page 3: Table Of Contents
Contents 1 Safety precautions 4 Symbols used ...................... 4 General safety precautions ................. 5 Appliance-specific safety precautions............... 6 Instructions for use .................... 7 2 Disposal 9 3 Using for the first time 10 4 Your appliance 11 Appliance overview..................... 11 Operating and display elements .............. 11 Cookware ...................... 12 5 Operating the appliance 13... -
Page 4: Safety Precautions
Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in damage to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ▸... -
Page 5: General Safety Precautions
1 Safety precautions General safety precautions ▪ Read the operating instructions before using the appliance for the first time! ▪ This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved. -
Page 6: Appliance-Specific Safety Precautions
1 Safety precautions Appliance-specific safety precautions ▪ WARNING: If the surface has a crack running through the thickness of the material, switch the appliance off and discon- nect it from the mains to avoid possible electric shock. ▪ WARNING: The appliance and its accessible parts get hot during use. -
Page 7: Instructions For Use
1 Safety precautions Instructions for use Before using for the first time ▪ The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/ electrician carry out the necessary work. Correct use ▪... - Page 8 1 Safety precautions Caution: Risk to life ▪ Packaging materials, e.g. plastic film and polystyrene, can be dangerous for children. Danger of suffocation! Keep packaging material away from chil- dren. How to avoid damaging the appliance ▪ In case of overheating, switch the hotplate off and allow it to cool down completely.
-
Page 9: Disposal
Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪... -
Page 10: Using For The First Time
Using for the first time The appliance must be installed and connected to the electricity sup- ply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. During the first few hours of use, a cooking zone can give off an un- pleasant smell. -
Page 11: Your Appliance
Your appliance Appliance overview GK25TE, GK25TEF ▪ 1 dual ring cooking zone Ø 180/120 mm ▪ 1 cooking zone Ø 140 mm Operating and display elements Buttons Appliance ON/OFF Increase power level / operating time Reduce power level / operating time Dual ring cooking zone ON/OFF Operating time / timer Displays... -
Page 12: Cookware
4 Your appliance Cookware Suitable cookware Cookware should have a stable bottom. When heated, the base of the cook- ware must lie flat on the surface of the cooking zone. Cookware made of metal is more suitable than that made of glass or ceramic as with metal the heat is distributed evenly quicker. -
Page 13: Operating The Appliance
Operating the appliance Switching the appliance on and off All the appliances are operated in the same way. ▸ To switch the appliance on: Depress the button for 1 second. – flashes in all the power level displays. – If no other entry is made, the appliance switches off again after about 10 seconds for safety reasons. -
Page 14: Overview Of Power Levels
5 Operating the appliance Overview of power levels Power level Cooking method Melting, gentle Butter, chocolate, gelatine, sauces warming Swelling Rice Continued cooking, Vegetables, potatoes, sauces, fruit, reducing, stewing fish Continued cooking, Pasta, soup, braised meat braising Gentle frying Rösti (hash browns), omelettes, breaded fried foods, sausages Frying, deep frying Meat, chips... -
Page 15: Switching The Dual Ring Cooking Zone On And Off
5 Operating the appliance Switching the dual ring cooking zone on and off When the dual ring cooking zone is switched on, the inner cooking zone A and the outer cooking zone B come on. The outer cooking ring B can be switched off if required. Switching the outer cooking ring off ▸... -
Page 16: Operating Time
5 Operating the appliance Operating time Do not leave the hob unattended during use. Risk of boiling over, burning on and igniting! With the operating time function, a Cooking zone switches off automatically after a set time 1–99 min.. Setting the operating time ▸... -
Page 17: Timer
5 Operating the appliance Changing the operating time ▸ Press the button for the required cooking zone. – The remaining operating time is displayed. – The indicator light for the button flashes. ▸ Use the button to change the operating time. Switching the operating time off before time ▸... -
Page 18: Childproof Lock
5 Operating the appliance Changing the timer ▸ Press the button next to the active timer. ▸ Use the button to change the duration of the timer. – flashes in the display. Switching the timer off before time ▸ Press the button next to the active timer. -
Page 19: Acoustic Signal
5 Operating the appliance – flashes in all the power level displays for 10 seconds. 5.10 Acoustic signal An acoustic signal is emitted as confirmation when a button is pressed (fact- ory setting). This acoustic signal can be switched off. When the appliance is switched off, the last acoustic signal setting is retained. -
Page 20: Care And Maintenance
Care and maintenance Clean the appliance only when it has completely cooled down. Burns hazard! Always clean the hob after use. This prevents food residue from burning on. Dried-on or burned-on food residue is harder to clean off. Use of improper cleaning techniques can result in damage to the markings or surface. -
Page 21: Trouble-Shooting
Trouble-shooting What to do if … … the appliance is not working and all the displays are dark? Possible cause Solution ▪ The fuse or circuit breaker ▸ Change the fuse. for electrical installations ▸ Reset the circuit breaker. in the home is defective. ▪... - Page 22 7 Trouble-shooting flash alternately in the display? Possible cause Solution ▪ The automatic safety shut-off ▸ Switch the cooking zone back on was triggered. again if required. If a cooking zone has been running for longer without any settings be- ing changed, the appliance switches the cooking zone off automatic- ally, after how much time depends on the power level set.
-
Page 23: Technical Data
Technical data Product fiche In accordance with EU Regulation No. 66/2014 Model number GK 005, 31023 Type designation GK GK25TE, GK25TEF Number of cooking zones Heating technology Radiant cooking zone Diameter of round cooking zones 12.5/18.5 Energy consumption per cooking zone Wh/kg 193.5 192.4... -
Page 24: Index
Index Acoustic signal ..........19 Operating and display elements....11 Switching off........ 19 Operating time..........16 Changing .......... 17 Switching on........ 19 Appliance End............ 17 Setting .......... 16 Switching on and off ...... 13 Switching off before time .... 17 Appliance overview ........ -
Page 25: Notes
Notes... -
Page 27: Service & Support
V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive ser- vice agreements. -
Page 28: Quick Instructions
To switch cooking zone off ▸ Press the buttons for the required cooking zone at the same time un- illuminates in the corresponding display. To switch appliance off Press the button. J005352-R02 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug info@vzug.com, www.vzug.com...
