- Page 1 Operating instructions CookTop V4000 A604 | A604B | A704 Toptronic hob...
- Page 2 Validity These operating instructions apply to: Model designation Type CookTop V4000 A604 CT4T-31151 CookTop V4000 A604B CT4T-31149 CookTop V4000 A704 CT4T-31152 Variations depending on the model are noted in the text. © V-ZUG AG, CH-6302 Zug, 2021...
-
Page 3: Table Of Contents
Contents 2 Notes 21 Safety precautions 4 Service & Support 23 Symbols used............ 4 General safety precautions........ 4 Appliance-specific safety precautions .... 4 Instructions for use.......... 5 Using for the first time 7 Your appliance 7 Appliance overview .......... 7 Operating and display elements...... -
Page 4: Symbols Used
Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that... -
Page 5: Instructions For Use
1 Safety precautions ▪ WARNING: The appliance Instructions for use and its accessible parts get Before using for the first time hot during use. Be careful not ▪ The appliance must be installed and to touch the heating ele- connected to the electricity supply in accordance with the separate installa- ments. - Page 6 1 Safety precautions ▪ Pots with pure copper or aluminium Note on use bases should not be used for cooking ▪ Tests have shown that under normal cir- as they can leave behind traces that cumstances there is no risk to cardiac can be difficult to clean.
-
Page 7: Using For The First Time
During the first few hours of use, a cooking zone can give off an unpleasant smell. This is normal for brand new appliances. Ensure that the room is well ventilated. Your appliance Appliance overview CookTop V4000 A604 ▪ 1 dual ring cooking zone ø175/210 mm ▪ 1 cooking zone ø180 mm ▪ 2 cooking zones ø140 mm CookTop V4000 A604B ▪... -
Page 8: Operating And Display Elements
3 Your appliance CookTop V4000 A704 ▪ 1 dual ring cooking zone ø140/210 mm ▪ 2 cooking zones ø180 mm ▪ 1 cooking zone ø140 mm Operating and display elements Buttons Appliance ON/OFF Slider (for setting the power level) Dual ring cooking zone ON/OFF, frying zone ON/OFF Pause cooking ON/OFF and restore function... -
Page 9: Optiglass
4 Operating the appliance ▪ Match the diameter of the cookware to the quantity of food to be cooked. OptiGlass Applies to CookTop V4000 A604 (CT4T64ESOC6/CT4T64ESOD6) and A704 (CT4T74ESOD4) Hobs with OptiGlass have an additional coating on the glass surface. -
Page 10: Overview Of Power Levels
4 Operating the appliance Overview of power levels Power level Cooking method Melting, gentle warming Butter, chocolate, gelatine, sauces Swelling Rice Continue cooking, reducing, Vegetables, potatoes, sauces, fruit, fish stewing, steaming Continue cooking, braising Pasta, soup, braised meat Gentle frying Rösti, omelettes, breaded fried foods, sausages Frying, deep frying... -
Page 11: Automatic Boost
4 Operating the appliance Automatic boost Do not leave the hob unattended when using the automatic boost. Risk of food boiling over, burning on and igniting! All the cooking zones are equipped with a selectable automatic boost. With this function, a cooking zone heats at power level «9»... -
Page 12: Timer
4 Operating the appliance Changing the operating time ▸ Touch the button for the required cooking zone. – The remaining operating time for the cooking zone selected is displayed. ▸ Touch the button. ▸ Use the slider to set the operating time. –... -
Page 13: Childproof Lock
4 Operating the appliance Changing the timer ▸ Switch the appliance on. ▸ Touch the button. – The time left on the timer is displayed. ▸ Touch the button. ▸ Use the slider to set the duration of the timer. –... -
Page 14: Restore Function
4 Operating the appliance 4.11 Restore function If the appliance has been inadvertently switched off with the button, the settings can be restored within 6 seconds. ▸ Switch the appliance on. – The indicator light for the button flashes. ▸ Touch the button. -
Page 15: Care And Maintenance
5 Care and maintenance ▸ Touch the buttons at the same time. If a hotplate is touched while setting the acoustic signal, the settings will be lost. To change the acoustic signal, the appliance has to be switched off and then back on again. -
Page 16: Cleaning Agent
6 Trouble-shooting ▸ Wipe off with a wet cloth and then polish with a dry cloth or the soft side of a suitable cleaning sponge. Cleaning agent Glass ceramic with OptiGlass Unsuitable cleaning agents may attack and damage the coating. ▸... - Page 17 6 Trouble-shooting Display Possible cause Solution A continuous acoustic ▪ A button or a slider was ▸ Remove object or food signal is emitted, touched for longer than that has boiled over. flashes and the appli- 10 seconds. ▸ The appliance can be ance switches off ▪...
-
Page 18: Other Possible Problems
7 Technical data Power level Safety shut-off after hrs.:mins. 8:30 6:30 5:30 4:30 3:30 3:00 2:30 2:00 1:30 Other possible problems Problem Possible cause Solution The appliance is not ▪ The fuse or circuit breaker for ▸ Change the fuse. working and all the dis- electrical installations in the ▸... -
Page 19: Disposal
8 Disposal Model number GK 31152 Type designation GK CT4T-31152 Number of cooking zones Heating technology Radiant cooking zone Dimensions of cooking zone ø18 ø18 ø14/21 ø14 Energy consumption per cooking Wh/kg 190.1 188.9 186.2 188.5 zone Energy consumption of the entire Wh/kg 188.4 hob EC... -
Page 20: Index
Index Appliance Problems ............16 Product fiche............. 18 Switching on and off ........ 9 Appliance disposal .......... 19 Appliance overview ..........7 Appliance-specific safety precautions Queries .............. 23 ................ 4 Quick instructions ..........24 Automatic boost ..........11 Cancelling before time ....... 11 Residual heat indicator ........ -
Page 21: 10 Notes
Notes... - Page 23 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
- Page 24 ▸ Touch on the slider. To switch appliance off ▸ Touch the button. 1097863-01 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
