Operating instructions
GK36TIS | GK37TIMS | GK46TIS | GK46TIXS
| GK47TIMS | GK47TIMXS
Induction hob

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GK37TIMSF and is the answer not in the manual?

Questions and answers

Related Manuals for V-ZUG GK37TIMSF

Summary of Contents for V-ZUG GK37TIMSF

  • Page 1 Operating instructions GK36TIS | GK37TIMS | GK46TIS | GK46TIXS | GK47TIMS | GK47TIMXS Induction hob...
  • Page 2 These operating instructions apply to: Type Product family GK37TIMS/C/F 31041 GK47TIMS/U, GK47TIMSC/O, GK47TIMSF/O 31040 GK47TIMXSC/F 31039 GK36TIS/C/F/.1F 008, 31013 GK46TIS/C/F/U/.1F 027, 31016 GK46TIXS/C/F/.1F 009, 31015 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2017...

  • Page 3: Table Of Contents

    Contents 1 Safety precautions  5 Symbols used ...................... 5 General safety precautions .................  6 Appliance-specific safety precautions...............  6 Instructions for use .................... 7 2 Disposal  10 3 Using for the first time  11 4 Your appliance  12 Appliance overview..................... 12 Operating and display elements .............. 14 How induction hobs function ................ 15 Pan detection....................... 15 Cookware ...................... 16...
  • Page 4 8 Technical data  36 Product fiche...................... 36 9 Index  38 10 Notes  40 11 Service & Support  43...

  • Page 5: Safety Precautions

    Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in damage to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ▸...

  • Page 6: General Safety Precautions

    1 Safety precautions General safety precautions ▪ Read the operating instructions before using the appliance for the first time! ▪ This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved.

  • Page 7: Instructions For Use

    1 Safety precautions ▪ Under no circumstances use a steam cleaner to clean the ap- pliance. ▪ Do not place metal objects such as knives, forks, spoons, lids or aluminium foil on the hob as they can get hot. ▪ After use, switch the hob off using the controls and do not rely on the pan detector.
  • Page 8 1 Safety precautions ▪ Use original spare parts only. ▪ Retain these operating instructions for future reference. If you sell the appli- ance or pass it on to a third party, please ensure these operating instruc- tions accompany the appliance, together with the installation instructions. ▪...
  • Page 9 1 Safety precautions ▪ Take particular care that sugary foods or juices do not get onto the hot cooking zones as it can damage them. If sugary foods or juices do get on to the hot cooking zones clean away immediately (while still hot) with a scraper.

  • Page 10: Disposal

    Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should be collected for recycling and disposed of in an en- vironmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪...

  • Page 11: Using For The First Time

    Using for the first time The appliance must be installed and connected to the electricity sup- ply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. During the first few hours of use, a cooking zone can give off an un- pleasant smell.

  • Page 12: Your Appliance

    Your appliance Appliance overview GK37TIMS, GK37TIMSC, GK37TIMSF ▪ 2 cooking zones Ø 210 mm (back) ▪ 1 cooking zone Ø 180 mm (front) GK47TIMS, GK47TIMSC/O, GK47TIMSU, GK47TIMSF/O, GK47TIMXSC, GK47TIMXSF ▪ 2 cooking zones Ø 210 mm (back) ▪ 2 cooking zones Ø 180 mm (front)
  • Page 13 4 Your appliance GK36TIS, GK36TISC, GK36TISF, GK36TIS.1F ▪ 1 cooking zone Ø 250 mm ▪ 1 cooking zone Ø 210 mm ▪ 1 cooking zone Ø 145 mm GK46TIS, GK46TISC, GK46TISF, GK46TISU, GK46TIS.1F GK46TIXS, GK46TIXSC, GK46TIXSF, GK46TIXS.1F ▪ 1 cooking zone Ø 210 mm ▪...

  • Page 14: Operating And Display Elements

    4 Your appliance Operating and display elements Buttons Appliance ON/OFF Slider (for setting the power level) PowerPlus Pause cooking ON/OFF and restore function Wipe protection ON/OFF Select cooking zone Operating time / timer Displays 1 Cooking zone power level 2 Selection indicator: Cooking zone selected 3 Operating time activated 4 Cooking zone indicator light for the operating time 5 Operating time / timer...

  • Page 15: How Induction Hobs Function

    4 Your appliance How induction hobs function Induction hobs work very differently from conventional hobs or hot plates. The induction coils under the glass ceramic plate produce a rapidly changing mag- netic field which directly heats up the magnetic base of the cookware. The glass ceramic plate is only warmed by the hot cookware.

  • Page 16: Cookware

    4 Your appliance Cookware Suitable cookware Only cookware with a full magnetic base is suitable for use with the induction hob. This can be checked in the follow ways: ▪ A magnet sticks anywhere on the base of the cookware. ▪...

  • Page 17: Flexible Cooking

    4 Your appliance Flexible cooking Only applicable for GK37TIMS, GK47TIMS and GK47TIMXS. In flexible cooking, there are no marked cooking zones. Pans with different diameters can be placed on any cooking zone. must, however, be covered for pan detection. For even frying, the pan must be centred on .

  • Page 18: Operating The Appliance

    Operating the appliance Switching the appliance on and off All the appliances are operated in the same way. ▸ To switch the appliance on: Depress the button for 1 second. – flashes in all the power level displays. – If no other entry is made, the appliance switches off again after about 10 seconds for safety reasons.

  • Page 19: Overview Of Power Levels

    5 Operating the appliance Overview of power levels Power level Cooking method Keeping warm Sauces, keeps food ready for serving at around 65 °C Melting, gentle warming Butter, chocolate, gelatine, sauces Swelling Rice Continued cooking, Vegetables, potatoes, sauces, fruit, reducing, stewing fish Continued cooking, Pasta, soup, braised meat...

  • Page 20: Melting Function

    5 Operating the appliance Melting function With the melting function, butter, chocolate or honey, for instance, can be gently melted at 40 °C. Switching the melting function on ▸ Hold power level on the slider depressed for 2 seconds. – Two horizontal bars illuminate in the power level display.
  • Page 21 – Touch the required power level on the slider. Power management GK37TIMS, GK37TIMSC, GK37TIMSF PowerPlus cannot be used at the same time as the cooking zones 1 and 2. If PowerPlus is activated with both cooking zones, then the power output is re- duced for the cooking zone that was first selected.
  • Page 22 5 Operating the appliance GK47TIMS, GK47TIMSC/O, GK47TIMSF/O, GK47TIMSU, GK47TIMXSC, GK47TIMXSF PowerPlus cannot be used with both cooking zones of a group (A or B) at the same time. If PowerPlus is activated with both cooking zones of a group, then the power output is reduced for the cooking zone that was first selected. PowerPlus with Group A * cooking zone...
  • Page 23 5 Operating the appliance GK36TIS, GK36TISC, GK36TISF, GK36TIS.1F PowerPlus cannot be used at the same time as the cooking zones 1 and 2. If PowerPlus is activated with both cooking zones, then the power output is re- duced for the cooking zone that was first selected. Cooking zone 3 can be operated with PowerPlus independently of cooking zones 1 and 2.
  • Page 24 5 Operating the appliance GK46TIS, GK46TISC, GK46TISF, GK46TISU, GK46TIS.1F GK46TIXS, GK46TIXSC, GK46TIXSF, GK46TIXS.1F PowerPlus cannot be used with both cooking zones of a group (A or B) at the same time. If PowerPlus is activated with both cooking zones of a group, then the power output is reduced for the cooking zone that was first selected.

  • Page 25: Automatic Boost

    5 Operating the appliance 5.10 Automatic boost Do not leave the hob unattended when using the automatic boost. Risk of boiling over, burning on and igniting! All the cooking zones are equipped with a selectable automatic boost. With this function, a cooking zone heats at power level for a certain length of time (see table).

  • Page 26: Operating Time

    5 Operating the appliance 5.11 Operating time Do not leave the hob unattended during use. Risk of boiling over, burning on and igniting! With the operating time function, a Cooking zone switches off automatically after a set time 1–99 min.. Setting the operating time ▸...
  • Page 27 5 Operating the appliance Switching the operating time off before time ▸ Press the button of the required cooking zone. ▸ Press the button. ▸ Set the second digit of the operating time to using the slider. ▸ Press the button.

  • Page 28: Timer

    5 Operating the appliance 5.12 Timer The timer functions like an egg timer (1–99 min.). It can only be set when a cooking zone is in operation. A cooking zone can be put into operation when the timer is running. However, no operating time can be set.

  • Page 29: Childproof Lock

    5 Operating the appliance 5.13 Childproof lock The childproof lock is to prevent the appliance from being accidentally switched on. Switching the childproof lock on ▸ Switch the appliance on. Ensure all cooking zones are switched off. ▸ Touch the buttons at the same time.

  • Page 30: Restore Function

    5 Operating the appliance 5.14 Restore function If the appliance has been inadvertently switched off with the button, the set- tings can be restored within 6 seconds. ▸ Switch the appliance on. – The indicator light for the button flashes. ▸ Touch the button.

  • Page 31: Care And Maintenance

    Care and maintenance Clean the appliance only when it has completely cooled down. Risk of burns! Always clean the hob after use. This prevents food residue from burning on. Dried-on or burned-on food residue is harder to clean off. Use of improper cleaning techniques can result in damage to the markings or surface.
  • Page 32 6 Care and maintenance Cleaning For good results, follow these cleaning instructions. ▸ To clean thoroughly, remove most of the soiling using a hob scraper or a special cleaning sponge for glass ceramic hobs. ▸ Add a few drops of a suitable cleaning fluid to the cold hob surface and rub over the surface using kitchen towel or a clean cloth.

  • Page 33: Trouble-Shooting

    Trouble-shooting What to do if … … the appliance is not working and all the displays are dark? Possible cause Solution ▪ The fuse or circuit breaker for ▸ Change the fuse. electrical installations in the ▸ Reset the circuit breaker. home is defective.
  • Page 34 7 Trouble-shooting flash alternately in the display? Possible cause Solution ▪ The automatic safety shut-off ▸ Switch the cooking zone back on again if was triggered. required. If a cooking zone has been running for longer without any settings be- ing changed, the appliance switches the cooking zone off automatic- ally, after how much time depends on the power level set.
  • Page 35 7 Trouble-shooting … are illuminated in the display? Possible cause Solution ▪ An object (e.g. paper) ▸ Remove any objects in the drawer underneath the hob is underneath the hob. obstructing the air intake. ▸ Touch any button to cancel the error. ▸...

  • Page 36: Technical Data

    Technical data Product fiche In accordance with EU Regulation No. 66/2014 Model number GK 31039 Type designation GK G47TIMXSC/F Number of cooking zones Heating technology Induction cooking zone Diameter of round cooking zones Energy consumption per Wh/kg 184.9 173.8 199.1 cooking zone Energy consumption of Wh/kg...
  • Page 37 8 Technical data Model number GK 31041 Type designation GK GK37TIMS/C/F Number of cooking zones Heating technology Induction cooking zone Diameter of round cooking zones Energy consumption per Wh/kg 178.1 198.6 cooking zone Energy consumption of Wh/kg 190.5 the entire hob EC...

  • Page 38: Service &

    Index Setting .......... 26 Several operating times .... 27 Appliance OptiGlass............17 Switching on and off ...... 18 Illumination..........  17 Appliance overview ........12 Overview of power levels ......19 Appliance-specific safety precautions ..........6 Automatic boost ..........25 Packaging ............10 Cancelling before time .....
  • Page 39 9 Index Using for the first time........11 Validity............... 2 Warranty extensions ........43 Where is the identification plate?....11 Wipe protection ..........30...

  • Page 40: Notes

    Notes...

  • Page 43: Service & Support

    V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive ser- vice agreements.
  • Page 44 ▸ Touch the slider or swipe it to set the power level. Switching the cooking zone off ▸ Press the button of the required cooking zone. ▸ Touch on the slider. Switching the appliance off ▸ Press the button. J008352-R04 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug info@vzug.com, www.vzug.com...
