Williams Sound PPA R751 Quick Start Manual

PPA R751 Monitor Receiver
FM Listening System Receiver
O
VERVIEW
The PPA R751 Monitor Receiver is designed for use with Williams Sound PERSONAL PA
(PPA) Wide-band FM Transmitters. With the R751, small groups of people can listen to the
FM broadcast in a cry room, nursery, office area, or any location where a remote speaker is
needed and wiring is difficult to run.
F
IGURE
U R751 R
SING THE ECEIVER
1: Insert the ANT 026 Antenna into the "Antenna" connection on the back of the receiver
speaker. (See figure 2.) Make sure it is fully inserted and tightly fitted.
2: Clip the antenna shaft into the plastic antenna clip.
3: Extend the antenna by grasping the tip and pulling straight upward.
4: Connect the speaker connection wires to the passive speaker.
5: Plug the AC power cord into an AC outlet and turn the power switch on.
6: Make sure your PPA Transmitter is on and has an active audio source. Adjust the volume
control on the R751 until you hear the broadcast.
1: R751 R S
ECEIVER PEAKER
Front
F
EATURES
Volume
Treble
Bass
3D On/Off
Power Switch
Power LED
Headphone
Jack
AC Power
Rear
Antenna Clip
Channel
Designation
Antenna
Connection
E
FM Monitor Receiver Model PPA R751
Antenna
This device complies with part 15 of the
FCC Rules. See instruction manual.
FCC ID: CNMR751 Tuning Coil
S/N : A0097
Date: 9909
Power: 120 VAC
60VA max
Tune
Williams Sound Corp., Minneaplis, MN
Speaker Connection Wire
