SolidRF SOHO Manual page 5

Installation - Step By Step
c. Mount the booster outside unit
c. Set the outside antenna cable into the
building
• Carefully arrange the cable along the outside
of the building and ensure that there are no
folds or kinks
• Fix the cable at each corner
Step 2: Arrange the inside unit
a. Choose right position
• 20 cm away from any other metallic objects
• 50 cm away from any windows
• Be sure to be far from any heat source
should be from -20 ℃ to +50 ℃
• In a ventilated dry place, temperature range
• The inside antenna should be facing the
location of the signal dead zone/weak signal
area inside the building
b. Screw the outside cable's connector to the
"ANT2" port of the booster
c. Screw the inside antenna to the "ANT1" port
Step 3: Power on the booster
• Plug the power adapter into the power port
on the booster.
• Then plug into a surge protector power strip.
OUTSIDE
antenna
WARNING:
• Do NOT cover the booster body with
anything. This prevents if from cooling
down. If the product becomes overheated,
it will automatically shut off or cause
permanent damage.
• Use only the power supply provided by
SolidRF. Any other non-approved products
by SolidRF of self-made power cables may
damage the booster.
• Connecting the booster directly to the cell
phone with use of an adapter will damage
the cell phone.
• The booster is designed for use in indoor
ONLY.
• Ensure that neither you nor the pole comes
near any power lines during installation.
• The outside antenna must be installed no
higher than 10 meters (32'9") above ground.
Power
Switch
