JZL4704
Leaflet No. 463450
rev01
Read through
ALL
instructions before commencing installation.
If you have any questions about this product or issues with installation
STOP
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jzl4704 for more information.
47"
CUSTOMER SERVICES HELP LINE NUMBER:
66lbs
01952 670009
119cm
30kg
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Related Manuals for AVF Group JZL4704
Summary of Contents for AVF Group JZL4704
- Page 1 If you have any questions about this product or issues with installation STOP contact the customer services helpline before returning this product to the store. See jl.avfgroup.com/p/jzl4704 for more information. 47" CUSTOMER SERVICES HELP LINE NUMBER: 66lbs 01952 670009 119cm 30kg AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
-
Page 2: Assembly Overview
Assembly Overview Fit the Mounting Plate Fit the Wall Bracket Connect the TV... - Page 3 Index Measure the TV fixing holes Width and Height Preparing the Wall Bracket Choose the TV Mounting Plate Fitting the TV Mounting Plate Fitting the Wall Bracket Attach the TV TV Locking, Levelling and Cable Management Retain all packaging in case the bracket needs to be returned. Contents may vary from photography/ Illustrations.
-
Page 4: Tools Recommended
Tools Recommended Stud Finder Ø12mm (15/32") Ø3mm (1/8") Masonry Wood Boxed Parts... -
Page 5: Before You Begin
TV Screws, Reducers and Spacers Before you begin Remove Mounting Plate from Arm... - Page 6 Measure the TV fixing holes Width and Height TV Fixing Holes 100 - 400mm 100 - 400mm If your TV holes do not line up STOP installation now and contact the customer help line You are provided with 4 diameters of TV fixing screws, M4, M5, M6 and M8.
- Page 7 Choose the TV Mounting Plate Use the option that fits your TV = 100mm - 200mm OPTION 1 = 100mm - 200mm 200mm MAX 200mm MAX = 200mm - 400mm OPTION 2 = 200mm - 400mm 400mm MAX 400mm MAX...
- Page 8 Fitting the TV Mounting Plate Spacers No Spacers For Tvs with flat/unobstructed back For Tvs with irregular/obstructed back WARNING After completing step 4 you will have fittings left over, please keep for future reference...
- Page 9 Screw diameter dependant If required Fixings shown are valid for options 1 & 2 If required Attach the brackets to the back of your TV using suitable screw, reducer and spacer combinations.
- Page 12 Attach the TV Check all fittings are tight TV Locking, Levelling and Optional Cable Management Lock Tilt...
