JZL204
Leaflet No. 463864
rev02
Read through
ALL
instructions before commencing installation.
If you have any questions about this product or issues with installation
STOP
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jzl204 for more information.
32"
CUSTOMER SERVICES HELP LINE NUMBER:
44lbs
01952 670009
81cm
20kg
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AVF Group JZL204
Summary of Contents for AVF Group JZL204
- Page 1 If you have any questions about this product or issues with installation STOP contact the customer services helpline before returning this product to the store. See jl.avfgroup.com/p/jzl204 for more information. 32" CUSTOMER SERVICES HELP LINE NUMBER: 44lbs 01952 670009 81cm 20kg AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
-
Page 2: Assembly Overview
Assembly Overview Fit the Mounting Plate Fit the Wall Bracket Attach the TV... - Page 3 Index Measure the TV fixing holes Width and Height Choose and Prepare the TV Mounting Plate Fitting the TV Mounting Plate Fitting the Wall Bracket Assemble the Bracket Fitting the Top and Bottom Covers Attach the TV Fitting the Arm Covers and Cable Management TV Levelling and Tilt Retain all packaging in case the bracket needs to be returned.
-
Page 4: Tools Recommended
Tools Recommended Stud Finder Ø7mm (17/64") Ø3mm (1/8") Masonry Wood Boxed Parts... - Page 5 NYLON TV Screws...
-
Page 6: Before You Begin
Before you begin Remove Remove bottom cover top cover Keep top and bottom covers until step 6. Measure the TV fixing holes Width and Height TV Fixing Holes 75 / 100 / 200mm 75 / 100 / 200mm If your TV holes do not line up STOP installation now and contact the customer help line You are provided with 3 M4 =... -
Page 7: Choose And Prepare The Tv Mounting Plate
Choose and Prepare the TV Mounting Plate Use the option that fits your TV OPTION 1 = 75mm / 100mm = 75mm / 100mm 75mm 100mm 75mm 100mm OPTION 2 If you choose OPTION 2 you will = 200mm need to attach adaptors &... - Page 8 OPTION 2...
-
Page 9: Fitting The Tv Mounting Plate
Fitting the TV Mounting Plate OPTION 1 Only use this option if your TV fixing holes are 75 x 75mm or 100mm x 100mm You can only use screw Q with 75 x 75mm or 100 x 100mm TV fixing holes 100 x 100mm TV fixing holes shown OPTION 2... -
Page 12: Assemble The Bracket
Assemble the bracket Before you assemble the bracket, please remove the 2 arm covers and screws from arm and keep until step 8. NYLON NYLON Use your finger and thumb to hold nyloc nut (L) steady while you tighten screw ( ) -
Page 13: Fitting The Top And Bottom Covers
Fitting the Top and Bottom Covers Fit the top cover Fit the bottom cover... -
Page 14: Attach The Tv
Attach the TV Click! Click! IMPORTANT Ensure safety plunger is down To remove TV i. Remove parts H and I ii. Lift safety plunger and pull TV away (Safety plunger can be locked open by turning anti- clockwise after lifting) -
Page 15: Fitting The Arm Covers And Cable Management
Fitting the Arm Covers and Cable Management Cable management... -
Page 16: Tv Levelling And Tilt
TV Levelling and Tilt Levelling Tilt...
