Summary of Contents for Spellman XLG60P400/X2364
- Page 1 XLG60P400/X2364 High Voltage Power Supply MODEL : SERIAL# : DATE : SPELLMAN HIGH VOLTAGE ELECTRONICS CORPORATION 475 Wireless Blvd. Hauppauge, New York, 11788 +1(631) 630-3000*FAX: +1(631) 435-1620* E-mail: sales@spellmanhv.com Website: www.spellmanhv.com X2364 MANUAL 118045-001 Rev C...
- Page 2 CAUTION notes in the text indicate procedures to be followed to avoid possible damage to equipment. Copyright © 2000, Spellman High Voltage Electronics Corporation. All Rights Reserved. This information contained in this publication is derived in part from proprietary and patent data. This information has...
- Page 3 WICHTIGE SICHERHEITSHINWEISE SICHERHEIT DIESES HOCHSPANNUNGSNETZTEIL ERZEUGT LEBENSGEFÄHRLICHE HOCHSPANNUNG. SEIN SIE SEHR VORSICHTIG BEI DER ARBEIT MIT DIESEM GERÄT. Das Hochspannungsnetzteil muß immer geerdet sein. Berühren Sie die Stecker des Netzteiles nur, wenn das Gerät ausgeschaltet ist und die elektrischen Kapazitäten des Netzteiles und der angeschlossenen Last entladen sind. Die internen Kapazitäten des Hochspannungsnetzteiles benötigen ca.
- Page 4 PRECAUTIONS IMPORTANTES POUR VOTRE SECURITE CONSIGNES DE SÉCURITÉ ETTE ALIMENTATION GÉNÈRE DES TENSIONS QUI SONT DANGEUREUSES ET PEUVENT ÊTRE FATALES OYEZ EXTRÊMENT VIGILANTS LORSQUE VOUS UTILISEZ CET ÉQUIPEMENT Les alimentations haute tension doivent toujours être mises à la masse. Ne touchez pas les connectiques sans que l’équipement soit éteint et que la capacité à la fois de la charge et de l’alimentation soient déchargées.
- Page 5 IMPORTANTI PRECAUZIONI DI SICUREZZA SICUREZZA QUESTO ALIMENTATORE GENERA TENSIONI CHE SONO PERICOLOSE E POTREBBERO ESSERE MORTALI. PONI ESTREMA CAUTELA QUANDO OPERI CON QUESO APPARECCHIO. Gli alimentatori ad alta tensione devono sempre essere collegati ad un impianto di terra. Non toccare le connessioni a meno che l’apparecchio sia stato spento e la capacità interna del carico e dell’alimentatore stesso siano scariche.
-
Page 6: Table Of Contents
Table of Contents PAGE 1. INTRODUCTION Description of the X2364..................1 X2364 Specifications ...................1 Standard Features....................1 1.3.1 Remote Control via RS232 Interface............1 1.3.2 System Status and Fault Diagnostic Display ..........2 2. INSPECTION & INSTALLATION Initial Inspection ....................3 Mechanical Installation..................3 3. OPERATING INSTRUCTIONS Operation......................5 Standard Features....................6 4. - Page 7 8.2.2 QUERY COMMAND ................20 8.2.3 RESPONSE PACKET ................20 8.2.4 SOFTWARE VERSION REQUEST (“V”) COMMAND AND RESPONSE (“B”) ................21 LOCAL/REMOTE COMMUNICATION MODE ..........21 ERROR RESPONSE (“E”) AND ILLEGAL COMMANDS ......22 COMMAND SUMMARY...................23 APPENDIX Specification Controls LIST OF FIGURES Figure 2.1 Dimensions X2364..................4 Figure 3.1 Typical Operating Setup X2364 ..............7 Figure 3.2...
-
Page 8: Introduction
HIGH VOLTAGE ON indicators. applications where the high voltage is a positive polarity, OUTPUT CABLE: A Spellman Delrin HV receptacle is and the filament circuits are referenced to cathode ground designed to mate with an Anden P5 Series high voltage potential, (grounded filament). -
Page 9: System Status And Fault Diagnostic Display
1.3.2 System Status and Fault OVER VOLT: Indicates the overvoltage protection Diagnostic Display circuitry has caused the power supply to turn off. Overvoltage protection is internally set to 110% of rated “Dead Front” type indicators are provided to give the user output voltage. -
Page 10: Inspection & Installation
EIA rack mounting. The rack must allow rear damage due to handling in transit. Notify the access for cable connections. Units are fully carrier and Spellman immediately if damage is enclosed and are suitable for bench or tabletop evident. Do not destroy or remove any of the operation. -
Page 11: Figure 2.1 Dimensions X2364
Figure 2.1 X2364 DIMENSIONS X2364 MANUAL 118044-001 REV E... -
Page 12: Operating Instructions
Spellman X3145 operates from approximately 6 seconds after the HIGH VOLTAGE ON 187Vac to 264Vac, 50 to 60Hz, single phase. -
Page 13: Standard Features
The standard feature is programmed to trip the Spellman application engineers are available to assist in power supply if 8 arcs occur within a twenty second interface circuitry design. All interface cables should be period. -
Page 14: Figure 3.1 Typical Operating Setup X2364
Figure 3.1 Typical Operating Setup X2364 Rear Panel X2364 MANUAL 118044-001 REV E... -
Page 15: Figure 3.2 Rear Panel I/O Interface
It is recommended to use isolated contacts / switches or relays for both interlocks. They should be located as close as possible to the power supply Signals are ~ 15Vdc, 25mA max and are only to be used for contact closure. Install jumper Cooling FAULT if COOLING FAULT... -
Page 16: Principles Of Operation
CONTROL/POWER PWB. The load side of CB1 is blocks that comprise the X2364 power supply. For details also connected to T1 and, via. the HV ON/OFF relay to on a specific circuit, consult Spellman’s Engineering the Remote Cooling Control socket. T1 is a step-down Department. -
Page 17: Inverter
X2364 ASSEMBLY TITLE ASSEMBLY NO. System Interconnect Top Assy 404551-001 Power/Cont Bd 404560-001 Multiplier Assy 403932-062 Filament Board 404241-004 Front Panel Bd 403895-005 Table 4.1 List of Main Assemblies Voltage feedback from the high voltage divider is sent to 4.3 Inverter U9. -
Page 18: Front Panel Assembly
4.7 Front Panel Assembly 4.8 Filament Supply PWB Front Panel control meters, and status indications are The power for the X-ray tube is provided by the filament connected to the FRONT PANEL PWB. The FRONT inverter. The filament inverter is a high frequency, series PANEL interfaces directly... -
Page 19: Maintenance
Spellman Customer Service Department. Test equipment, including an oscilloscope, a high impedance voltmeter, WARNING and a high voltage divider such as the Spellman HVD-100 or HVD-200, is needed for performance tests. All test components must be rated for operating voltage. -
Page 20: Replacement Parts
Spellman Customer Service Department for parts lists for specific models. Each Spellman power supply has an identification label on the rear of the chassis that bears its model and serial Spellman provides parts and subassemblies for its high number. -
Page 21: Factory Service
Spellman personnel. See the Warranty received at the Spellman Repair Center. In the event that in the rear of this manual for more information. Follow repair work is extensive, Spellman will call to seek the return procedures described in Section 7.2. -
Page 22: Rs232C Overview
Spellman – Customer RS-232C Serial Data jacks mounted of the DCE (the power supply) equipment. Interface. This interface is an add-on to the Spellman However, since none of the RD-232C handshaking lines XLG Power Supply. Its purpose is to provide remote... -
Page 23: Table 8.1 Db-9 Pin-Out, I/O
SIGNAL NAME DB-9 DB-25 COMMENTS PINOUT EQUIV (pins refer to DB-9) Data Carrier Detect (DCD) Shorted to pins 4 & 6 Receive Data (RxD) Power supply transmit line Transmit Data (TxD) Power supply receive line Data Terminal Ready (DTR) Shorted to pins 1 & 6 Signal Ground (GND) Signal ground Data Set Ready (DSR) -
Page 24: Signal Summary
CHARACTER ASCII COMMENTS packets between the Customer computer and the SENT CODE Spellman power supply that represent the analog and Start of Header digital signals defined below: <CR> Carriage Return Analog Control Signals sent from Customer Computer to Spellman Power Supply: 1. -
Page 25: Command Structure
Digital Monitor Signals sent from Spellman Power 8.2.1 Set Command (“S”) and Supply to Customer Computer: Acknowledge (“A”) Response 1. Cooling Fault (1 = fault) Prior to sending a Set Command that performs any function other than a Power Supply Reset, the computer 2. - Page 26 The protocol for the Set Command is as follows: Byte 6 through 8 represents the current. 3.75 milliamperes is 25% of full scale. Full scale (15mA) with The power supply receives the “S” command and 12 bit resolution is FFF hex. 3.75mA is therefore performs a checksum comparison and other error represented as 3FF hex (within an error of 1 lsb).
-
Page 27: Query Command
Since modulo 256 decimal is modulo 100 hex, we can In ASCII coded hexadecimal: 41 0D divide 321 hex by 100 hex. The remainder is 21 hex. Therefore 21 hex will be sent in bytes 16 and 17 in ASCII 8.2.2 Query Command representation as 32 hex and 31 hex. -
Page 28: Software Version Request ("V") Command And Response ("B")
Note that the analog monitors have 10 bit resolution, Version Response (B) packet back to the computer. If therefore, full scale is represented in hexadecimal as 3FF. errors are detected in the V command, the power supply The checksum is calculated of bytes 2 through 13. will return an appropriate error message. -
Page 29: Error Response ("E") And Illegal Commands
In Remote Mode, the power supply will respond to S and Characters sent: Q or V commands. In this mode, controlled parameters <CR> can be changed only via the S command from the computer. The front panel pots will be inoperative, Sent in ASCII coded hexadecimal: although the front panel indicators and switches will continue to function. -
Page 30: Command Summary
The fault signals that are checked are: S - Set Power Supply (contains desired power supply settings) – 18 bytes. Cooling Fault Q - Query Power Supply (requests that the power Overcurrent Fault supply returns to the computer a Response Packet) – 5 bytes. - Page 31 To obtain information on Spellman’s product warranty please visit our website at: http://www.spellmanhv.com/en/About/Warranty.aspx...
