Instruction Manual
600 SERIES
SPELLMAN
HIGH VOLTAGE ELECTRONICS
CORPORATION
One Commerce Park
Valhalla, New York, 10595
+1(914) 686-3600* FAX: +1(914) 686-5424*
E-mail:
sales@spellmanhv.com
Website: www.spellmanhv.com
600 SERIES MANUAL
118117-001 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BERTAN 602C-10P and is the answer not in the manual?

Questions and answers

Related Manuals for Spellman BERTAN 602C-10P

Summary of Contents for Spellman BERTAN 602C-10P

  • Page 1 Instruction Manual 600 SERIES SPELLMAN HIGH VOLTAGE ELECTRONICS CORPORATION One Commerce Park Valhalla, New York, 10595 +1(914) 686-3600* FAX: +1(914) 686-5424* E-mail: sales@spellmanhv.com Website: www.spellmanhv.com 600 SERIES MANUAL 118117-001 Rev A...
  • Page 2 ≤0.01% per hour, after a 1/2 hour warm up nized, File E137710. Corporate Headquarters www.spellmanhv.com 128041-001 REV. H Hauppauge, New York USA Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Copyright © 2005 Spellman High Voltage Electronics Corp.
  • Page 3 115V 230V FUSE LINE NEUT Corporate Headquarters www.spellmanhv.com 128041-001 REV. H Hauppauge, New York USA Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Copyright © 2005 Spellman High Voltage Electronics Corp.
  • Page 4 File E137710. 0.01% per hour, after a 1/2 hour warm up Corporate Headquarters For locations worldwide www.spellmanhv.com Hauppauge, New York USA 128042-001 REV. H +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company...
  • Page 5 Function 115/230 Vac Input FRONT VIEW Neutral Ground REAR VIEW Corporate Headquarters For locations worldwide www.spellmanhv.com Hauppauge, New York USA 128042-001 REV. H +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company...
  • Page 6 Compliant to 2004/108/EC, the EMC Directive and 2006/95/EC, the Low Voltage Directive. Corporate Headquarters For locations worldwide www.spellmanhv.com Hauppauge, New York USA 128043-001 REV. F +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company...
  • Page 7 Internal program potentiometer wiper, 0 to 5Vdc FRONT VIEW REAR VIEW Corporate Headquarters For locations worldwide www.spellmanhv.com Hauppauge, New York USA 128043-001 REV. F +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company...
  • Page 8 Stability: 0.01% per hour, after a 1/2 hour warm up Corporate Headquarters For locations worldwide www.spellmanhv.com Hauppauge, New York USA 128044-001 REV. F +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company...
  • Page 9 Internal program potentiometer wiper, 0 to 5Vdc FRONT VIEW REAR VIEW Corporate Headquarters For locations worldwide www.spellmanhv.com Hauppauge, New York USA 128044-001 REV. F +1-631-630-3000 FAX: +1-631-435-1620 e-mail: sales@spellmanhv.com Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company...
  • Page 10 CAUTION notes in the text indicate procedures to be followed to avoid possible damage to equipment. Copyright © 2000, Spellman High Voltage Electronics Corporation. All Rights Reserved. This information contained in this publication is derived in part from proprietary and patent data. This information has...
  • Page 11 WICHTIGE SICHERHEITSHINWEISE SICHERHEIT DIESES HOCHSPANNUNGSNETZTEIL ERZEUGT LEBENSGEFÄHRLICHE HOCHSPANNUNG. SEIN SIE SEHR VORSICHTIG BEI DER ARBEIT MIT DIESEM GERÄT. Das Hochspannungsnetzteil muß immer geerdet sein. Berühren Sie die Stecker des Netzteiles nur, wenn das Gerät ausgeschaltet ist und die elektrischen Kapazitäten des Netzteiles und der angeschlossenen Last entladen sind. Die internen Kapazitäten des Hochspannungsnetzteiles benötigen ca.
  • Page 12 PRECAUTIONS IMPORTANTES POUR VOTRE SECURITE CONSIGNES DE SÉCURITÉ ETTE ALIMENTATION GÉNÈRE DES TENSIONS QUI SONT DANGEUREUSES ET PEUVENT ÊTRE FATALES OYEZ EXTRÊMENT VIGILANTS LORSQUE VOUS UTILISEZ CET ÉQUIPEMENT Les alimentations haute tension doivent toujours être mises à la masse. Ne touchez pas les connectiques sans que l’équipement soit éteint et que la capacité à la fois de la charge et de l’alimentation soient déchargées.
  • Page 13 IMPORTANTI PRECAUZIONI DI SICUREZZA SICUREZZA QUESTO ALIMENTATORE GENERA TENSIONI CHE SONO PERICOLOSE E POTREBBERO ESSERE MORTALI. PONI ESTREMA CAUTELA QUANDO OPERI CON QUESO APPARECCHIO. Gli alimentatori ad alta tensione devono sempre essere collegati ad un impianto di terra. Non toccare le connessioni a meno che l’apparecchio sia stato spento e la capacità interna del carico e dell’alimentatore stesso siano scariche.

  • Page 14: Table Of Contents

    Table of Contents INTRODUCTION Scope of Manual…………………………………………………………. 2 Purpose of Equipment……………………………………………………... 2 Description……….………………………………………………………… 2 OPERATION Installation………….……………………………………………………. 4 Input Power………….………………………………………………...…. 4 High Voltage Control………….…………………………………………. 4 2.3.1 Internal Potentiometer Control………………………..…………………..……. 4 2.3.2 External Potentiometer Control…………………………………………………. 4 2.3.3 External Voltage Control………………………………………………………..4 High Voltage Monitor……………………………………………………. 4 Output Current Monitor…………………………………………………..

  • Page 15: Scope Of Manual

    SECTION I – DESCRIPTION INTRODUCTION/SPECIFICATIONS The units are fully enclosed and designed to easily satisfy system bench SCOPE OF MANUAL operation. A wide range of stable output This manual is provided to assist the user in voltages, up to 30kV are available. The the installation and operation of the Bertan output voltage is controlled locally by a Series 602C, 603C, 605C, 606C and 612C...
  • Page 16 SERIES 612C MODEL HV OUTPUT MATING HV CONNECTOR CONNECTOR 612C-200 405787 612C-300 405787 612C-500 405786 The appropriate mating connector kit is provided with each Series 612C unit. For pre-assembled high voltage cables, please consult factory. Size and Weight SIZE WEIGHT SERIES H”...

  • Page 17: Operation

    internal potentiometer setting. SECTION II – OPERATION CAUTION: THIS UNIT STORE 2.3.3 EXTERNAL VOLTAGE CONTROL HAZARDOUS VOLTAGE! COMPLETELY See Section 2.7 for hook-up information. DISCHARGE THE HIGH VOLTAGE TO The output high voltage can be controlled GROUND BEFORE ATTEMPTING by a 0 to +5Vdc analog signal. REMOVAL OF THE HIGH VOLTAGE CABLE.

  • Page 18: Input/Control/Monitor Connections

    PIN LAYOUT INPUT/CONTROL/MONITOR 2.7 INPUT/CONTROL/MONITOR CONNECTOR (P2) CONNECTIONS INPUT POWER CONNECTIONS SERIES 602C/603C/612C ONLY TERMINAL FUNCTION 115/230Vac Input Neutral Ground Note: To obtain local control using the CONTROL AND internal potentiometer accessible at the top MONITORING CONNECTIONS of the unit, jumper P2 pin 4 to pin 9. ALL MODELS P2/PIN# FUNCTION...

  • Page 19: Standard Mode

    first three modes apply to all Series 602C, This mode is included to provide exact 603C, 605C, 606C and 612C units. The last compatibility with some previous units. It mode applies only to the Series 612C and is also provides the user with a controllable included only with Series 612C units upper limit on the programmed output for an ordered with the –5VPRO option.
  • Page 20 TABLE III-1 PCB 100 JUMPER POSITIONS STANDARD MODE: Jumper pins 1 to 3, pins 5 to 7 3.3 -5 VOLT PROGRAMMING (for 0 to 100% output voltage) MODE: Jumper pins 1 to 2, pins 3 to 4 -5 VOLT PROGRAMMING (for 0 to 103% output voltage) MODE: Jumper pins 1 to 2, pins 3 to 5, and pins 6 to 8 3.5 ERIES 612C –5 VOLT...

  • Page 21: Circuit Description

    SECTION IV – CIRCUIT DESCRIPTION equipment used to perform the calibration. All 4.1 FUNCTIONAL DESCRIPTION measurements are traceable to the National The 602C, 603C, and 612C employ a standard Institute Standards Technology step-down transformer to obtain a nominal (N.I.S.T.). Contact the factory for additional +28Vdc from the input ac power.
  • Page 22 The buyer’s sole remedy for a claimed breach of this warranty, and Spellman’s sole liability is limited, at Spellman’s discretion, to a refund of the purchase price or the repair or replacement of the power supply at Spellman’s cost. The buyer will be responsible for shipping charges to and from Spellman’s plant. The buyer will not be entitled to make claim for, or recover, any anticipatory profits, or incidental, special or consequential damages resulting from, or in any way relating to, an alleged breach of this warranty.

This manual is also suitable for:

Bertan 602c-15nBertan 602c-15pBertan 602c-10nBertan 602c-30pBertan 602c-50pBertan 602c-30n ... Show all
