EMC CLARiiON
CX700
Storage Processor Enclosure (SPE)
HARDWARE REFERENCE
P/N 300-001-073
REV A01
EMC Corporation
Corporate Headquarters :
Hopkinton, MA 01748 -9103
1
-508 -435 -1000
www.EMC.com

Advertisement

Table of Contents
loading

Related Manuals for EMC CLARiiON CX700

Summary of Contents for EMC CLARiiON CX700

  • Page 1 EMC CLARiiON CX700 Storage Processor Enclosure (SPE) HARDWARE REFERENCE P/N 300-001-073 REV A01 EMC Corporation Corporate Headquarters : Hopkinton, MA 01748 -9103 -508 -435 -1000 www.EMC.com...
  • Page 2 Trademark Information , EMC, CLARiiON, Navisphere, and PowerPath are registered trademarks and EMC ControlCenter, EMC Enterprise Storage, The Enterprise Storage Company, The EMC Effect, FLARE, MirrorView, SnapView, and Access Logix are trademarks of EMC Corporation. All other trademarks used herein are the property of their respective owners.
  • Page 3 Regulatory Notices Product Type(s): XPE+S This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 CX700 Hardware Reference...

  • Page 5: Table Of Contents

    Contents Chapter 1 About the CX700 Overview................... 1-2 CX700 Components and Features ..........1-3 Field-Replaceable Units (FRUs)..........1-3 Storage Processor Enclosure ........... 1-4 Storage Processors (SPs) ............1-7 Power Supplies ................. 1-9 Fan Module................1-11 Chapter 2 Setting Up and Starting a CX700 System Requirements..................
  • Page 6 Contents Chapter 3 Servicing a CX700 SPE Monitoring CX700 Status..............3-2 Handling FRUs ................3-7 Power Issues and FRUs ............3-7 Avoiding Electrostatic Discharge (ESD) Damage....3-8 Emergency Procedures (Without an ESD Kit) ..... 3-9 Precautions When Removing, Installing, or Storing FRUs 3-9 Precautions When Handling Optical Cables......
  • Page 7 Contents SPS Technical Specifications ............A-8 SPS to SP Interface ..............A-8 SPS Power Specifications ............A-8 SPS Operating Limits ............. A-9 SPS Shipping and Storage Requirements ......A-9 Dimensions and Battery Information........A-9 SPS Standards Certification/Compliance ......A-11 Appendix B Customer Support Overview of Detecting and Resolving Problems .......
  • Page 8 Contents viii CX700 Hardware Reference...
  • Page 9 Figures Figure CX700 with DAE2 Enclosures in a 40U Cabinet ........1-2 CX700 Front View ..................1-4 CX700 Front View with Front Bezel Removed ........1-5 CX700 Back View ..................1-5 CX700 Status LEDs ..................1-6 CX700 Front Bezel ..................1-6 Location of the SPs ..................
  • Page 10 Figures Status Lights Visible from the Front of the CX700 SPE ......3-2 Status LEDS, Front Bezel Removed ............3-3 SP A and SP B Status LEDs ................3-4 Power Supply and SPS Status LEDs ............3-6 Removing the CX700 Front Bezel ............. 3-11 Removing a Fan Module ................
  • Page 11 Preface As part of an effort to improve and enhance the performance and capabilities of its product line, EMC from time to time releases revisions of its hardware and software. Therefore, some functions described in this guide may not be supported by all revisions of the software or hardware currently in use.
  • Page 12 Cabinet Setup Guide for the 40U Cabinet (P/N 014003099) Documentation Site Preparation and Unpacking Guide for the 40U Cabinet (P/N 014003100) EMC Rails and Enclosures Installation Guide for 19-Inch NEMA Cabinets (P/N 014003082) EMC 2-Gigabit Disk-Array Enclosure (DAE2) Setup Guide (P/N 014003104)
  • Page 13 Preface CAUTION A caution contains information essential to avoid damage to the system or equipment. The caution may apply to hardware or software. WARNING A warning contains information essential to avoid a hazard that can cause severe personal injury, death, or substantial property damage if you ignore the warning.
  • Page 14 Follow the voice menu prompts to open a service call and select the applicable product support. Sales and Customer For the list of EMC sales locations, please access the EMC home page Service Contacts http://www.EMC.com/contact/ For additional information on the EMC products and services...
  • Page 15 Warnings and Cautions The following warnings and cautions pertain throughout this guide. WARNING Trained service personnel only. Ground circuit continuity is vital for safe operation of the machine. Never operate the machine with grounding conductors disconnected. Remember to reconnect any grounding conductors removed for or during any installation procedure.
  • Page 16 Warnings and Cautions Static Precautions EMC incorporates state-of-the-art technology in its designs, including the use of LSI and VLSI components. These chips are very susceptible to damage caused by static discharge and need to be handled accordingly. CAUTION Before handling printed -circuit boards or other parts containing LSI and/or VLSI components, observe the following precautions: Store all printed-circuit boards in antistatic bags.

  • Page 17: About The Cx700

    About the CX700 ® This chapter introduces the EMC CLARiiON Model CX700 storage processor enclosure (SPE). Major topics include Overview .....................1-2 CX700 Components and Features............1-3 About the CX700...

  • Page 18: Overview

    About the CX700 Overview The CX700 is a highly available storage enclosure with redundant power and cooling. It is four U high (a U is a NEMA unit, each unit being 1.75 inches) and supports two storage processors (SPs). Each SP has four host I/O ports and four back-end disk ports.

  • Page 19: Cx700 Components And Features

    About the CX700 A CX700 can support a total of 240 disks in a single disk-array storage system. A four-loop configuration (with maximum performance and availability) supports as many as 60 disks per back-end (BE) port; a two-loop configuration can support 120 disks per back-end port. You can place the DAE2 enclosures in the same cabinet as the CX700 SPE, or in one or more separate cabinets.

  • Page 20: Storage Processor Enclosure

    About the CX700 Storage Processor The enclosure is a sheet-metal housing with a front panel, a Enclosure midplane, front bezel, two SPs, two power supplies, and three fan modules. Figures 1-2, 1-3, and 1-4 show the CX700 components. Details on each component follow the figures.

  • Page 21: Cx700 Front View

    About the CX700 Front Bezel Fan Modules EMC1953 CX700 Front View with Front Bezel Removed Figure 1-3 Power Supply B Storage Processor B Storage (SP B) Processor A Power (SP A) Supply A EMC1954 CX700 Back View Figure 1-4 CX700 Components and Features...

  • Page 22: Cx700 Status Leds

    About the CX700 Front Panel The front panel contains two CX700 status lights. These lights are visible with the front bezel installed or removed. System Fault Power OK (Amber) (Green) EMC1955 CX700 Status LEDs Figure 1-5 The CX700 status lights are described in Chapter 3. Front Bezel The front bezel has a keylock and two latch release buttons.

  • Page 23: Storage Processors (Sps)

    About the CX700 Storage Processors (SPs) The SP is the CX700 SPE’s intelligent component and acts as the control center. An SP is a printed-circuit board and an airdam with status lights and securing latches. Each SP includes Dual Pentium IV processors 4 Gbytes of DDR DIMM (double data rate, dual in-line memory module) memory Four SFF (small form factor) shielded Fibre Channel connectors...

  • Page 24: Sp A And Sp B Connectors

    About the CX700 Figure 1-8 shows the connectors on the rear of SP A and SP B. Back-end HSSDC Serial Copper Fibre Channel AUX 1/BE3 Serial Port BE 1 BE 0 AUX 0/BE2 Port Latch Latch Port 3 SP B Port 0 Port 2 Front-end...

  • Page 25: Power Supplies

    About the CX700 BE 1 BE 0 AUX 1/BE 3 AUX 0/BE 2 Link Link Link Link Link Activity Fault Power (Green) (Green) (Green) (Green) (Green) (Amber) (Amber) (Green) Port 3 Link Port 0 Link (Green) (Green) Port 1 Link Port 2 Link (Green) (Green)
  • Page 26 About the CX700 Each power supply is an auto-ranging, power-factor-corrected, multi-output, off-line converter with its own line cord and power switch. Each supply supports a fully configured SPE and shares load currents with the other supply. A FRU with power-related faults will not adversely affect the operation of any other FRU.

  • Page 27: Fan Module

    About the CX700 Fan Module The CX700 fan modules (Figure 1-12) cool the two storage processors. Separate, integrated fans cool the power supplies. There are three fan modules, each containing two fans that draw ambient room air through the front bezel. Each fan module connects directly to the midplane and is powered by the power supplies.
  • Page 28 About the CX700 1-12 CX700 Hardware Reference...

  • Page 29: Setting Up And Starting A Cx700 System

    Setting Up and Starting a CX700 System This chapter describes CX700 installation requirements and procedures. Major topics include Requirements..................2-2 Cabling a CX700 .................2-7 CX700 Powerup and Initialization ..........2-19 CX700 Powerdown ................2-20 Setting Up and Starting a CX700 System...

  • Page 30: Requirements

    How to install the universal mounting rails in the cabinet, and the 4U chassis on those rails, is explained in the EMC Rails and Enclosures Installation Guide for 19-Inch NEMA Cabinets available on the EMC Powerlink website.

  • Page 31: Site Requirements

    Setting Up and Starting a CX700 System Debido a su considerable peso, la instalación del compartimento en el bastidor deben realizarla siempre dos personas. Para evitar daños personales o en el equipo, el compartimento no debe levantarse ni instalarse en el bastidor sin la ayuda de un elevador mecánico o de otra persona.

  • Page 32: Cabling Requirements

    1-meter cables are adequate. The DAE2 does not support cables shorter than 1 meter or longer than 10 meters. EMC supports and can provide 1-, 5-, and 10-meter cables. The 5- and 10-meter cables are equalized. CX700 and DAE2 interconnections should maintain LCC consistency;...

  • Page 33: Disk Requirements

    Do not move a preloaded 0-4 module from its assigned slot to another slot. Remove it only to replace the disk. For details on DAE2 disks and their configuration, refer to the EMC 2-Gigabit Disk Enclosure (DAE2) Hardware Reference.

  • Page 34: Enclosure Address (Ea) Switch On A Dae2

    Setting Up and Starting a CX700 System Setting the Enclosure Address (EA) For details on DAE2 configuration, refer to the EMC 2-Gigabit Disk Enclosure (DAE2) Hardware Reference. Each DAE2 on a back-end loop requires a unique enclosure address (EA) to identify the enclosure and determine disk ALPA addresses.

  • Page 35: Cabling A Cx700

    Each SP’s BE 1 to a second DAE2, if present Optional third and fourth back loops to additional DAE2s Multiple DAE2s together For details on installing a CX700 and DAE2s in a cabinet, see the EMC Rails and Enclosures Installation Guide for 19-Inch NEMA Cabinets. CAUTION Be sure to maintain power and loop integrity when cabling your storage system.

  • Page 36: Connecting The Ac Line Cord To The Power Supply

    Setting Up and Starting a CX700 System Power Switch Retention Bail EMC1966 Connecting the ac Line Cord to the Power Supply Figure 2-3 Refer to Figure 2-4 as you connect the ac line cords to your SPS. Be sure to maintain all A to A and B to B connections. Failure to do so will prevent write caching from working.

  • Page 37: Connecting The Storage Processors To The Standby Power Supplies

    Setting Up and Starting a CX700 System 8. Connect each SPS ac inlet to the nearest ac outlet in the vertical power strip in the cabinet. As shown in Figure 2-4, each SPS connects to a different power strip. For high availability, you must connect each power strip to a different circuit.

  • Page 38: Connecting The Copper Cable To The Be 0 Sp Port

    Setting Up and Starting a CX700 System drives. Loops starting at the BE 1, BE 2, and BE 3 connectors are also paired and share disks in the same way. Together, loops A0/B0, A1/B1, A2/B2, and A3/B3 act as four redundant loops. When cabling the DAE2(s), you should always cable from the CX700 BE port to the primary port of the first DAE2 in the loop.
  • Page 39 Setting Up and Starting a CX700 System 4. To connect additional DAE2s on each loop, cable the LCC EXP (expansion) port on each DAE2 to the PRI port on the next LCC on that loop. Be sure to maintain the division between A and B components;...

  • Page 40: Sample Cx700 And Dae2 Cabling - One Cabinet With 2 Loops

    Setting Up and Starting a CX700 System EA4/Loop 1 LCC B LCC A EA4/Loop 0 Loop 1 Loop 1 EA3/Loop 1 Loop 0 Loop 0 EA3/Loop 0 Loop 1 Loop 1 EA2/Loop 1 Loop 0 Loop 0 EA2/Loop 0 Loop 1 Loop 1 EA1/Loop 1 Loop 0...

  • Page 41: Sample Cx700 And Dae2 Cabling - One Cabinet With 4 Loops

    Setting Up and Starting a CX700 System EA1/Loop 3 LCC B LCC A Loop 3 Loop 3 EA1/Loop 2 Loop 2 Loop 2 EA1/Loop 1 Loop 1 Loop 1 EA1/Loop 0 Loop 0 Loop 0 EA0/Loop 3 Loop 3 Loop 3 EA0/Loop 2 Loop 2 Loop 2...

  • Page 42: Sample Cx700 And Dae2 Cabling - Two Cabinets With Two Loops

    Setting Up and Starting a CX700 System LCC B LCC A DAE2 EA7/Loop 0 DAE2 EA6/Loop 0 Loop 0 Loop 0 LCC B LCC A DAE2 EA7/Loop 1 DAE2 EA5/Loop 0 Loop 0 Loop 0 Loop 1 Loop 1 DAE2 EA6/Loop 1 DAE2 EA4/Loop 0 Loop 0 Loop 0...

  • Page 43: Sample Cx700 And Dae2 Cabling - Two Cabinets With Four Loops

    Setting Up and Starting a CX700 System LCC B LCC A DAE2 EA3/Loop 2 Loop 0 Loop 0 DAE2 EA3/Loop 0 LCC B LCC A DAE2 EA3/Loop 3 DAE2 EA2/Loop 2 DAE2 EA3/Loop 1 DAE2 EA2/Loop 0 DAE2 EA2/Loop 3 DAE2 EA1/Loop 2 DAE2 EA2/Loop 1 DAE2 EA1/Loop 0...

  • Page 44: Connecting Storage Processors To The External Environment

    Setting Up and Starting a CX700 System Connecting Storage Processors to the External Environment When working with optical cables, observe the following precautions: Keep the covers on all optical cables and optical connectors until you are ready to insert the cables. The covers protect the cables and connectors and prevent foreign particles, such as dust, from entering and affecting the connection.

  • Page 45: Connecting To A 2-Gbit Switch Or Hba

    Setting Up and Starting a CX700 System 3. To connect to a 2-Gbit switch or host bus adapter (HBA) port, refer to Figure 2-12; for a 1-Gbit switch or HBA port, refer to Figure 2-13. a. Connect the external end of the Port 0-2 cables as follows: –...

  • Page 46: Connecting To A 1-Gbit Switch Port Or Hba

    Setting Up and Starting a CX700 System To 1-Gbit HBA or switch port EMC2287 Connecting to a 1-Gbit Switch Port or HBA Figure 2-13 4. Connect each SP to the external LAN from which you will manage the storage system. See Figure 2-14. EMC2309 Connecting CX700 SPs to an External (Management) LAN Figure 2-14...

  • Page 47: Cx700 Powerup And Initialization

    Setting Up and Starting a CX700 System CX700 Powerup and Initialization Before applying power to a storage system, make sure all the disk module slots in each disk-array enclosure contain either disk or filler modules, for proper cooling and normal operation. Do not power up an enclosure without at least one SP or LCC installed.

  • Page 48: Cx700 Powerdown

    ® powerup, refer to the EMC CLARiiON CX300, CX500, and CX700 Storage Systems Initialization Guide and the EMC Installation Roadmap for CX-Series and FC-Series Storage Systems. CX700 Powerdown If a CX700 powers down abnormally (for example, at a brownout or ac failure), the SPS ensures that any data in the storage-system cache is saved to the storage-system vault disks.

  • Page 49: Power Down Each Sps

    Setting Up and Starting a CX700 System Power Supply B Power Supply A SP B SPS B SPS A SP A SPS Power Switches EMC2297 Power Down Each SPS Figure 2-16 CAUTION Never shut off the power supplies to shut down a CX700. Bypassing the SPS in that manner prevents the system from saving write cache data to the vault drives, and results in data loss.
  • Page 50 Setting Up and Starting a CX700 System 2-22 CX700 Hardware Reference...
  • Page 51 Handling FRUs...................3-7 Replacing a Fan Module ..............3-11 Replacing a Power Supply..............3-13 Replacing a Storage Processor (SP) ..........3-15 To remove and replace an SPS, refer to the EMC Rails and Enclosures Installation Guide for 19-Inch Cabinets. Servicing a CX700 SPE...

  • Page 52: Monitoring Cx700 Status

    Servicing a CX700 SPE Monitoring CX700 Status Status lights made up of light emitting diodes (LEDs) on the storage system and its FRUs indicate the current status of the CX700 and its individual components. Figures 3-1 through 3-4 and Tables 3-1 through 3-3 explain the lights. System Fault Power OK...

  • Page 53: Status Leds, Front Bezel Removed

    Servicing a CX700 SPE Fan Module Fault LED (Amber) Fan Module B Fan Module C Fan Module A EMC1961 Status LEDS, Front Bezel Removed Figure 3-2 Monitoring CX700 Status...

  • Page 54: Sp A And Sp B Status Leds

    Servicing a CX700 SPE Figures 3-3 and 3-4 and Tables 3-2 and 3-3 show and explain the fault lights visible from the rear of the CX700 SPE. BE 1 BE 0 AUX 1/BE 3 AUX 0/BE 2 Link Link Link Link Link Activity...
  • Page 55 Servicing a CX700 SPE Meaning of SP A and SP B Status LEDs Table 3-2 Quantity Color Meaning BE 0— BE 3 1 per port Green On to indicate auxiliary or back-end (AUX 0, AUX 1) activity. Link LEDs LAN Link LED 1 per LAN port Green On when there is a valid Ethernet...

  • Page 56: Power Supply And Sps Status Leds

    Servicing a CX700 SPE Active Power (Green) Supply A Fault Fault (Amber) (Amber) Active (Green) Power Supply B SPS B SPS A Active (Green) Active (Green) On Battery (Amber) On Battery Replace Fault Fault Replace (Amber) Battery (Amber) Battery (Amber) (Amber) EMC2299 Power Supply and SPS Status LEDs...

  • Page 57: Handling Frus

    Servicing a CX700 SPE Handling FRUs This section describes the precautions you must take and the general procedures you must follow when removing, installing, and storing FRUs. Power Issues and FRUs The CX700 is designed to be powered up at all times and to be repaired while powered up.

  • Page 58: Avoiding Electrostatic Discharge (Esd) Damage

    Servicing a CX700 SPE Avoiding Electrostatic Discharge (ESD) Damage When you replace or install FRUs, you can inadvertently damage the sensitive electronic circuits in the equipment simply by touching them. Electrostatic charge that has accumulated on your body discharges through the circuits. If the air in the work area is very dry, running a humidifier in the work area will help decrease the risk of ESD damage.

  • Page 59: Emergency Procedures (Without An Esd Kit)

    Servicing a CX700 SPE Emergency Procedures (Without an ESD Kit) In an emergency when an ESD kit is not available, use the following procedures to reduce the possibility of an electrostatic discharge by ensuring that your body and the subassembly are at the same electrostatic potential.

  • Page 60: Precautions When Handling Optical Cables

    Servicing a CX700 SPE Store a FRU in the antistatic bag and specially designed shipping container in which you received it. Use that container if you need to return the FRU for repair. Maintain the location where you store FRUs within the limits specified in Appendix A.

  • Page 61: Replacing A Fan Module

    Servicing a CX700 SPE Replacing a Fan Module CAUTION Handle a fan module gently and use an ESD wristband. Do not remove a faulty fan module until you have a replacement available. You can remove the fan module while the CX700 is powered up. If the module is removed for more than about two minutes, the SPs power down.

  • Page 62: Installing A Replacement Fan Module

    Servicing a CX700 SPE 3. Squeeze the latches together and gently pull the fan module out. Refer to Figure 3-6. EMC1976 Removing a Fan Module Figure 3-6 Installing a Replacement Fan Module 1. At the front of the CX700 SPE, insert the replacement fan module into the enclosure, and push gently until you hear a loud click and you cannot push the module in any further.

  • Page 63: Replacing A Power Supply

    Servicing a CX700 SPE Replacing a Power Supply CAUTION Make sure the write cache has been written to disk before shutting any power down. Turn power off at the SPS, and wait for the cache dump to finish (typically less than one minute). Turn off the power supply before unplugging the ac line cord from the supply or removing the supply from the enclosure.

  • Page 64: Installing The Replacement Power Supply

    Servicing a CX700 SPE Latch Handle EMC1978 Removing the Power Supply Figure 3-9 Installing the Replacement Power Supply 1. Make sure the latch is turned fully counter-clockwise before installing the power supply. 2. Align the power supply with the enclosure slot and gently push it all the way into the slot.

  • Page 65: Replacing A Storage Processor (Sp)

    Servicing a CX700 SPE Replacing a Storage Processor (SP) CAUTION Handle a storage processor gently and use an ESD wristband. Do not remove a faulty storage processor until you have a replacement available. You can remove a storage processor while the CX700 is powered up.

  • Page 66: Installing A Replacement Storage Processor

    Servicing a CX700 SPE EMC2397 Removing a Storage Processor Figure 3-10 4. Place the storage processor on a static-free surface. WARNING Danger of explosion if the lithium battery on the storage processor board is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer.

  • Page 67: Installing A Storage Processor

    Servicing a CX700 SPE EMC2398 Installing a Storage Processor Figure 3-11 CAUTION Depending on its state and configuration, your system may take several minutes to boot and integrate the new SP. Monitor the process patiently; pay particular attention to the SP fault LED codes described in Table 3-2 on page 3-5.
  • Page 68 Servicing a CX700 SPE 3-18 CX700 Hardware Reference...

  • Page 69: Chapter 4 Standby Power Supply (Sps)

    Standby Power Supply (SPS) The 1000-watt CX700 standby power supply (SPS) provides the backup power required to protect the integrity of the storage processor write cache. This chapter gives a general overview of the SPS. Major topics are About the SPS ..................4-2 Replacing an SPS ................4-4 Standby Power Supply (SPS)

  • Page 70: About The Sps

    Standby Power Supply (SPS) About the SPS Two 1000-watt dc SPSs provide backup power for one CX700 SPE and the first (enclosure 0, loop 0) DAE2 adjacent to it. The two SPSs provide higher availability and allow write caching — which prevents data loss during a power failure —...
  • Page 71 Replace the SPS as soon as possible. Replacing an SPS is explained in the EMC Rails and Enclosures Installation Guide for 19-Inch NEMA Cabinets Two SPS units fit in a tray beneath the CX700 to which they connect.

  • Page 72: Replacing An Sps

    5 years. Battery pack lifetime is shorter in locations that have frequent ac outages. Replacing an SPS For information on removing and installing an SPS, please refer to the EMC Rails and Enclosures Installation Guide for 19-Inch NEMA Cabinets. CX700 Hardware Reference...
  • Page 73 Invisible Body Tag Technical Specifications and Operating Limits This appendix describes the CX700 technical specifications, operating limits, and shipping and storage requirements. Major sections are SPE Technical Specifications............A-2 SPE Standards Certification and Compliance.......A-5 SPE Operating Limits ...............A-6 SPS Technical Specifications ............A-8 Technical Specifications and Operating Limits...

  • Page 74: Spe Technical Specifications

    Technical Specifications and Operating Limits SPE Technical Specifications Technical specifications include power requirements, size, interface, and standards information. Power Requirements The input current, power (VA), and dissipation per CX700 SPE are based on the system requirements for the power supplies and cooling system to provide internal regulated power.

  • Page 75: Sizes And Weights

    The maximum length when using either the 62.5-µm or 50-µm cable (noted in the table above) includes two connections or splices between the source and destination. For a detailed overview of cable types, connections, and lengths, EMC CLARiiON CX300, CX500, and CX700 Storage Systems refer to the Configuration Planning Guide CAUTION µm...

  • Page 76: Sp To Dae2 Copper Cabling

    Technical Specifications and Operating Limits SP to DAE2 Copper Cabling CX700 back-end (BE) Fibre Channel uses shielded HSSDC (High Speed Serial Data Connector). The SP’s back-end port interface to each DAE2 port is copper cable that meets the following specifications: Ω...

  • Page 77: Spe Standards Certification And Compliance

    CSA 22.2 No. 950 Safety of Information Technology Equipment including Electrical EN 60950 Business Equipment UL 1950 CE Mark European EMC Directive & Low Voltage Directive Requirements EMI Standards Standard Description FCC Part 15 Class A, Radio Frequency Device Requirements...

  • Page 78: Spe Operating Limits

    Technical Specifications and Operating Limits SPE Operating Limits The ambient temperature specification is measured at the front panel inlet. The site must have air conditioning of the correct size and placement to maintain the specified ambient temperature range and offset the CX700 heat dissipation listed on page A-2. Requirement Description Ambient temperature...

  • Page 79: Spe Shipping And Storage Requirements

    Technical Specifications and Operating Limits SPE Shipping and Storage Requirements Requirement Description Ambient temperature -40°C to 65°C (-40°F to 149°F) Temperature gradient 25°C/hr (45°F/hr) Relative humidity 10% to 90% noncondensing Elevation 7625 m (25,000 ft.) SPE Operating Limits...

  • Page 80: Sps Technical Specifications

    Technical Specifications and Operating Limits SPS Technical Specifications This section lists the technical specifications and operating limits for the standby power supply (SPS). SPS to SP Interface Type: Half-duplex RS-232 Baud rate: 9600, 8-bit Parity: None SPS Power Specifications Requirement Description (All Ratings Assume a Fully-Configured System) ac line voltage 100 V ac to 240 V ac -10%/+10% single-phase,...

  • Page 81: Sps Operating Limits

    Technical Specifications and Operating Limits SPS Operating Limits Requirement Description Ambient temperature 10°C to 40°C (50°F to 104°F) Relative humidity 20% to 80% noncondensing Elevation 2439 m (8000 ft) IMPORTANT: The operating limits listed above for temperature and humidity must not be exceeded inside the closed cabinet in which the SPS is mounted.

  • Page 82: Typical Sps Self-Discharge Levels At Different Storage Temperatures

    Technical Specifications and Operating Limits Battery Tests Internal Within 60 minutes after powerup and approximately every 2 weeks thereafter, the SPS performs a light test on the batteries. This test lasts less than one second. It does not verify battery capacity but does check connectivity and functionality.

  • Page 83: Sps Standards Certification/Compliance

    EN 60950 Safety of Information Technology Equipment including Electrical UL 1950 Business Equipment. CSA 22.2 No. 950 CE Mark European EMC Directive & Low Voltage Directive Requirements EMI Standards Standard Description FCC Part 15 Class B, Radio Frequency Device Requirements...

  • Page 84: 1000-Watt Dc Sps

    Technical Specifications and Operating Limits Cable Pinout Information Figure A-2 shows the storage processor (SP) interface to the SPS. Active Interface DAE2 (Green) On Battery (Amber) Replace Power Fault Battery ac Power Switch Connector (Amber) (Amber) EMC2292 1000-Watt DC SPS Figure A-2 The interface connector pinouts are as follows: SP Interface Connector...
  • Page 85 Body Tag Customer Support This appendix reviews the EMC process for detecting and resolving software problems, and provides essential questions that you should answer before contacting the EMC Customer Support Center. This appendix covers the following topics: Overview of Detecting and Resolving Problems ......B-2 Troubleshooting the Problem ............

  • Page 86: Customer Support

    Customer Support Overview of Detecting and Resolving Problems EMC software products are supported directly by the EMC Customer Support Center in the United States. EMC uses the following process to resolve customer problems with its software products (Figure B-1). Problem...

  • Page 87: Troubleshooting The Problem

    3. Run some test cases to reproduce the problem. If you encounter a problem that requires technical programming or analysis, call the nearest EMC office or contact the EMC Customer Support Center at one of the following numbers: United States: (800) 782-4362 (SVC-4EMC)

  • Page 88: Before Calling The Customer Support Center

    Customer Support Before Calling the Customer Support Center Have the following information available before calling the Customer Support Center or your support representative (if one has been assigned to you): Your company name Your name Your phone number For an existing problem, the problem tracking system ID, if one was previously assigned to the problem by a support representative For an MVS problem, the JESLOG, SYSPRINT, all STDOUT DD...

  • Page 89: Documenting The Problem

    Customer Support Documenting the Problem If the EMC Customer Support Center requests information regarding the problem, please document it completely, making sure to include the following information: Your company name and address Your name Your telephone number The importance of the problem, so that it can be assigned a...

  • Page 90: Reporting A New Problem

    Customer Support Reporting a New Problem For a new problem, please provide the following information: Release level of the software that you are running Software installation parameters Host type on which you are running Operating system you are running and its release number Functions of the software that you are running Whether you can reproduce the problem Previous occurrences of the problem...

  • Page 91: Sending Problem Documentation

    Customer Support Sending Problem Documentation Use one of the following methods to send documentation of the problem to the EMC Customer Support Center: E-mail U.S. mail to the following address: EMC Customer Support Center 45 South Street Hopkinton, MA 01748-9103...
  • Page 92 Customer Support CX700 Hardware Reference...

  • Page 93: Glossary

    Glossary The terms defined here are important to installing and maintaining a storage system. ALPA (arbitrated loop An 8-bit address that uniquely identifies an SP (or other device) on an physical address) FC-AL loop. bind In the context of a disk-array storage system, the procedure by which you hardware-format one or more disk modules into one LUN (logical unit) —...
  • Page 94 SP. Unassisted failover requires properly configured paths between a host and each SP, and ® failover/multipath software such as EMC PowerPath FC-AL (Fibre Channel An arrangement of Fibre Channel stations such that messages pass Arbitrated Loop) from one to the next in a ring.
  • Page 95 Glossary A hardware assembly that can be replaced by trained personnel on (field-replaceable site, instead of at the point of manufacture. unit) GBIC Gigabyte Interface Card. A device for converting Fibre channel signals from copper electrical to optical, and vice versa. HBA (host bus Another name for Fibre Channel host bus adapter.

  • Page 96: Power Supply

    Glossary and integrated hardware and software. A file system is located and managed on the NAS device and data is transferred to clients over industry-standard network protocols (TCP/IP or IPX), using industry-standard file-sharing protocols. node Any device with a Fibre Channel interface (such as an HBA in a server or a storage system’s SP) that connects to a Fibre Channel loop.
  • Page 97 Glossary SPE (storage A storage device that includes an enclosure, SPs with host I/O ports, processor back-end disk ports, and power supplies. enclosure) SPS (standby power A unit that provides temporary backup power in case of a power supply) outage. An SPS is required for storage-system write caching. If power fails, the SPS allows the SP to write the data from its cache to disk.
  • Page 98 Glossary CX700 Hardware Reference...
  • Page 99 Index ac line cord 2-7 DAE2 (2-gigabit disk-array enclosure) removing from power supply 3-13 cabling specifications A-4 ALPA (Arbitrated Loop Physical Address) connecting 2-9 defined g-1 defined g-1 discharge times, SPS A-10 disk module, defined g-2 binding disk modules, defined g-1 EA (enclosure address), defined g-2 electromagnetic interference (EMI), see EMI cabinet, installing SPE in 2-2...
  • Page 100 Index fan pack, see fan module FC-AL (Fibre Channel Arbitrated Loop) PDU (power distribution unit, defined g-4 cabling, SPE to DAE2 2-10 port, serial, SP 1-7 defined g-2 power Fibre Channel adapter (FC adapter), defined g-2 consumption front panel SPS A-8 status lights 3-2 cord FRUs (field-replaceable units)
  • Page 101 Index fan module self-discharge times A-10 description 1-10 service clearance A-9 front bezel 1-6 shipping requirements A-9 high-availability features 1-3 standards certification/compliance A-11 midplane description 1-6 status lights 3-6, 4-3 power supply 1-9 storage requirements A-9 specifications A-2 technical specifications A-8 status lights 3-2 tests A-10 specifications...
  • Page 102 Index CX700 Hardware Reference...
