- Page 1 CX700 2-Gigabit Fibre Channel Storage Processor Enclosure (SPE) SETUP GUIDE P/N 300-001-274 REV A05 EMC Corporation Corporate Headquarters : Hopkinton, MA 01748 9103 1000 www.EMC.com...
- Page 2 Use, copying, and distribution of any EMC software described in this publication require an applicable software license. Trademark Information , EMC, CLARiiON, Navisphere, and PowerPath are registered trademarks and Access Logix, FLARE, MirrorView, Powerlink, SAN Copy, and SnapView are trademarks of EMC Corporation. All other trademarks mentioned herein are the property of their respective owners.
- Page 3 The EMC Installation Roadmap for CX-Series, AX-Series, and FC-Series Storage Systems provides detailed checklists of installation procedures for supported storage-system environments, and lists the documents you will need to complete each task. EMC CLARiiON manuals related to the storage system are on the EMC CLARiiON Storage-System Hardware and Software Documentation CD that shipped with the storage system.
- Page 4 Step 1 Plan Your Configuration To plan your installation, refer to the EMC CLARiiON CX300, CX300i, CX500, CX500i, and CX700 Storage Systems Configuration and Planning Guide (on the EMC Powerlink website or the documentation CD). The guide includes background material, planning rules, and administrative worksheets. Use it to choose and understand RAID types, LUNs, file systems, and software options.
- Page 5 Confirm that your facility has appropriate electrical wiring in place to accommodate your cabinet’s power cords. For EMC cabinets, see the Site Preparation and Unpacking Guide for the 40U-C Cabinet (on the EMC Powerlink website or the documentation CD). To support all of the storage system’s high- availability features, you must receive power from two discrete circuits.
- Page 6 Power cords - one per power supply SPS serial (sense) cables - one per SPS; one per dc power/cooling module One or more rail kits (if your storage system is not already installed in a cabinet) EMC CLARiiON Storage-System Hardware and Software Documentation CD...
- Page 7 Step 3 Continued Verify the Parts Customers must provide the following: CAT 5 or better Ethernet LAN RJ45 cables (1 per SP) for storage-system management connections Fibre Channel optical cables (2 maximum per SP) for server/switch connections...
- Page 8 Step 4 Install the Host Agent or Server Utility ® You can use either the Navisphere Host Agent or the Navisphere Server Utility to register the server NICs or HBAs with the storage system. Depending on your application needs, you can install either the Host Agent or Server Utility on a server. You cannot install both applications on the same server;...
- Page 9 EMC CX-Series Server Support Products for HP-UX Installation Guide • EMC CX-Series Server Support Products for IRIX Installation Guide • EMC CX-Series Server Support Products for Linux and VMware Installation Guide • EMC CX-Series Server Support Products for NetWare Installation Guide •...
- Page 10 Step 5 Install the Storage System in the Cabinet If your CX700 SPE enclosure or DAEs are not already installed in a cabinet, install them using the instructions for installing a 4U device (SPE) or 3U device (DAE2 or DAE2P) in the EMC Rails and Enclosures Field Installation Guide.
- Page 11 Step 6 Verify Storage System Back-End Connections Use the information below and the diagram to verify the enclosure address settings and loop (bus) cabling for the SPE and your DAEs. Each CX700 storage processor has four back-end (BE) ports that connect to the corresponding primary (PRI) ports on the first DAE (DAE2 or DAE2P) in each loop.
- Page 12 Step 6 Continued Verify Storage System Back-End Connections EA1/Loop 3 LCC B LCC A Loop 3 Loop 3 EA1/Loop 2 Loop 2 Loop 2 EA1/Loop 1 Loop 1 Loop 1 EA1/Loop 0 Loop 0 Loop 0 EA0/Loop 3 Loop 3 Loop 3 EA0/Loop 2 Loop 2...
- Page 13 Step 7 Verify Power Settings and Connections 1. Verify that the cabinet master switches are in the off position. 2. For systems that use ac power, verify that the power switch on each SPS is off. 3. Verify that the power switch on each SPE power supply and DAE power supply/ system cooling module is off (if present).
- Page 14 Step 7 Continued Verify Power Settings and Connections • The SPSs connect to separate power distribution units (PDUs) in the cabinet. • In systems with ac power, power/cooling module A in the first DAE (EA 0, loop 0) in the system connects to SPS A, and power/cooling module B in the first DAE connects to SPS B.
- Page 15 If the amber lights on the front or back of the system remain on, make sure the system is correctly cabled and then refer to the fault code explanations in the EMC CLARiiON CX700 Storage Processor Enclosure (SPE) Hardware Reference. If you cannot...
- Page 16 Step 9 Connect the Storage System Management Ports Using CAT 5 or better Ethernet cables, connect each SP to the same subnet that is connected to the host from which you will manage the storage system (management host). Connecting to a Local Management Client Connecting to a Shared Management LAN EMC2309...
- Page 17 EMC CLARiiON CX300, CX500, and CX700 Storage Systems Initialization Guide (P/N 300-001-272), which is available on the EMC Powerlink website.
- Page 18 The completed configuration planning worksheets from the EMC CLARiiON CX300, CX300i, CX500, CX500i, and CX700 Storage Systems Configuration Planning Guide (on the EMC Powerlink website or the documentation CD) with the following information: A static IP address for each storage processor in the storage system.
- Page 19 EMC CX-Series Server Support Products for HP-UX Installation Guide • EMC CX-Series Server Support Products for IRIX Installation Guide • EMC CX-Series Server Support Products for Linux and VMware Installation Guide • EMC CX-Series Server Support Products for NetWare Installation Guide •...
- Page 20 • Linux host Open a console window and enter /opt/Navisphere/bin/naviinittoolcli • NetWare client From the toolbar, select Start > Programs > EMC > Navisphere > Navisphere Storage System Initialization • NetWare host At a DOS prompt, enter LOAD SYS:\EMC\NAVIINIT\NAVIINIT •...
- Page 21 Step 10 Continued Initialize the Storage System 4. Select the storage system to initialize: • On an HP-UX, Linux, NetWare, or Solaris host Enter the item number for the storage-system’s serial number and press Enter. • On a NetWare Client or Windows host In the Uninitialized Systems list select the storage-system’s serial number and click Next.
- Page 22 Step 11 Connect the Storage-System Data Ports You use fiber-optic cables to connect the storage-system data ports to the server’s Fibre Channel HBAs or to ports on a Fibre Channel switch that is connected to the server. 1. Remove the protective covers from each optical connector on the fiber-optic cable and on the HBA or switch port.
- Page 23 Step 11 Continued Connect the Storage-System Data Ports What Next? If you installed the Host Agent on the server, continue to Step 12, Run the Host Agent to Register the Server HBAs on page 22. If you installed the Server Utility on the server, go to Step 13, Run the Server Utility to Register the Server HBAs on page 24.
- Page 24 Step 12 Run the Host Agent to Register the Server HBAs When the Host Agent starts, it registers server HBAs with any storage systems that are connected to the HBAs either directly or through switches. It does this registration by sending the HBA initiator records to the storage systems. For certain operating systems, the Host Agent starts automatically when you boot the server.
- Page 25 Step 12 Continued Run the Host Agent to Register the Server HBAs • NetWare server To start the Host Agent: load sys:\emc\agent\navagent -f sys:\emc\agent\agent.cfg To stop the Host Agent: unload navagent • Solaris server To start the Host Agent: /etc/init.d/agent start To stop the Host Agent: /etc/init.d/agent stop...
- Page 26 • Windows server From the toolbar, select Start > Programs > EMC > Navisphere > Navisphere Server Utility 2. For an HP-UX, Linux, NetWare, or Solaris server: a. If a menu appears, select 1 (Update Server Information). The utility scans and displays a list of all storage systems connected to the server.
- Page 27 Servers that use SnapView require admsnap software and servers that use SAN Copy require the admhost software. The admsnap and admhost software is on the EMC CX-Series Server Support Products CD and the procedure for installing it is in the EMC CX-Series Server Support Products Installation Guide for your server’s operating system.
- Page 28 You are now ready to use Navisphere Manager to define your storage-system security settings and configure your storage system. Refer to the appropriate checklist for your system in the EMC Installation Roadmap for CX-Series, AX-Series, and FC-Series Storage Systems (P/N 069001166) on the EMC Powerlink website.
-
Page 29: If You Need Help
If You Need Help For questions about technical support and service, contact your service provider. If you have an EMC service contract, contact EMC Customer Service at USA (800) 782-4362, Canada (800) 543-4782, or worldwide (508) 497-7901. For questions about upgrades, contact your local sales office.
