- Page 1 User’s Manual Model STED (Style S) mV,Temperature and Potentiometer /Voltage Converters IM 01B04J01-02E 11th Edition Y okogawa Electric Corporation...
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction Inspection ..........................1-2 Documentation Conventions ....................1-3 Notice ..........................1-4 Compatibility with Previous Models ..................1-5 Chapter 2 General Standard Specifications ......................2-2 Model and Suffix Codes ......................2-3 Chapter 3 Installation External Wiring ........................3-2 Chapter 4 Principles of Operation mV DC Input Type (STED-1 and STED-7 Types) ............... 4-1 Thermocouple Input Type (STED-2 and STED-7 Types) ............ - Page 4 Blank...
-
Page 5: Chapter 1 Introduction
Chapter 1 Introduction Introduction This manual describes the functions and operations of the STED mV,Temperature, and Potentiometer/Voltage Converters. ● Intended Readers This manual is intended for personnel in charge: • Installation and wiring • Instrumentation and setup of the function • Operation and monitoring of the controller •... -
Page 6: Inspection
Check the package contents against the list below. If anything is missing or damaged, immediately contact the sales office from which you purchased the product or your nearest Yokogawa representative. • STED mV, Temperature, and Potentiometer/Voltage Converters ......1 • Precautions on the Use of the YS80 Series ............1... -
Page 7: Documentation Conventions
The product has a QR Code pasted for efficient plant maintenance work and asset information management. It enables confirming the specifications of purchased products and user’s manuals. For more details, please refer to the following URL. https://www.yokogawa.com/qr-code QR Code is a registered trademark of DENSO WAVE INCORPORATED. IM 01B04J01-02E... -
Page 8: Notice
• Yokogawa does not make any warranties regarding the product except those mentioned in the WARRANTY that is provided separately. • Yokogawa assumes no liability to any party for any loss or damage, direct or indirect, caused by the use or any unpredictable defect of the product. -
Page 9: Compatibility With Previous Models
Compatibility with Previous Models Compatibility with styles A and B ● Operation and settings differ from previous models (styles A and B). Please read this document carefully before operating the product. ● Before installing this product in a system or plant, you must check the jumper settings and parameters described in chapter 5, “Settings.”... - Page 10 Blank...
-
Page 11: Chapter 2 General
Chapter 2 General General The STED mV,Temperature and Potentiometer/Voltage Converters are used to convert mV DC, thermocouple, RTD (resistance temperature detector) or potentiometer input signals to isolated two 1 to 5 V DC signals and 4 to 20 mA DC signal. Both thermocouple input type STED-210 and RTD input type STED-310 have built-in input linearizers as standard equipment. -
Page 12: Standard Specifications
Standard Specifications Please see the General Specifications (GS 01B04J01-02E) at the end of this manual. IM 01B04J01-02E... -
Page 13: App
Model and Suffix Codes Model Suffix Codes Option Codes Description STED mV, Temperature and Potentiometer/Voltage Converters Input mV DC input signal Thermocouple input RTD input Potentiometer input Universal input (mV, TC, RTD input) Number of 1 input inputs Suffix Code Always 0 Suffix Codes mV DC input... - Page 14 Blank...
-
Page 15: Installation
Chapter 3 Installation Installation For details of the installation procedure and wiring precautions, refer to the instruction manual “Installation of Rack-Mounted Instruments” (IM 1B4F2-01E). IM 01B04J01-02E... -
Page 16: External Wiring
External Wiring (a) To prepare cables for connection to each terminal, install crimp-on solderless lugs for 4 mm screw on the end of each cable. (b) Draw the internal unit out from the rack case. (c) Connect the cables to the correct terminals by referring to Table 3-1. (d) Replace the internal unit into the rack case after completing the wiring. -
Page 17: Chapter 4 Principles Of Operation
Chapter 4 Principles of Operation mV DC Input Type (STED-1 and STED-7 Types) The mV DC input signals are converted into digital data in A/D conversion circuit. The digital data has signal processing (range conversion) in micro-processor to be Pulse Width Modulation (PWM). -
Page 18: Thermocouple Input Type (Sted-2 And Sted-7 Types)
Thermocouple Input Type (STED-2 and STED-7 Types) The Thermocouple input signals are converted into digital data in A/D conversion circuit. The digital data has signal processing (linearizing computation, RJC computation, and range conversion) in micro-processor to be Pulse Width Modulation (PWM). The Pulse Width Modulation (PWM) is converted into 1 to 5 V DC or 4 to 20 mA DC signals in output circuit after passing through optical insulation circuit. -
Page 19: Rtd Input Type (Sted-3 And Sted-7 Types)
RTD Input Type (STED-3 and STED-7 Types) The RTD input signals are converted into digital data in A/D conversion circuit. The digital data has signal processing (linearizing computation and range conversion) in micro- processor to be Pulse Width Modulation (PWM). The Pulse Width Modulation (PWM) is converted into 1 to 5 V DC or 4 to 20 mA DC signals in output circuit after passing through optical insulation circuit. -
Page 20: Potentiometer Input Type (Sted-4 Type)
Potentiometer Input Type (STED-4 Type) The Potentiometer input signals are converted into digital data in A/D conversion circuit. The digital data has signal processing (range conversion) in micro-processor to be Pulse Width Modulation (PWM). The Pulse Width Modulation (PWM) is converted into 1 to 5 V DC or 4 to 20 mA DC signals in output circuit after passing through optical insulation circuit. -
Page 21: Chapter 5 Setting
Chapter 5 Setting Setting Items to Confirm before Start of Operation Before you start operation, inspect and confirm the following items: (1) Draw out the internal unit from the rack case, and make sure that the specified fuses are properly mounted in the fuse holders at the rear of the internal unit. -
Page 22: Names Of Components
Names of Components Tag plate BRAIN connector Span adjustment push switch Zero adjustment push switch (No switch for STED-7 type) Name plate Reference junction block (RJC) (provided for STED-2 or STED-7 type) Output terminal block Main board Terminal cover and handle for drawing out the internal unit Rack case Input terminal block... -
Page 23: Setting Jumper
Setting Jumper This instrument has the following setting jumpers: • Reference junction compensation(JP1): ON/OFF (only for STED-2 type) • Parameter Write Protect (JP2): ON/OFF • Burnout (JP3, JP4): UP/DOWN/OFF (except for STED-7 type) 5.2.1 Check of Setting Jumper For STED-2 and STED-7 types, first remove the reference junction block (RJC) from the terminal block, then draw the internal unit. -
Page 24: Position Of Setting Jumper
5.2 Setting Jumper 5.2.2 Position of Setting Jumper The setting jumper is on the main board of the internal unit. Setting jumper (factory-set default) For STED-1,-3, & -4 types For STED-2 type For STED-7 type JP1 2 3 4 JP1 2 3 4 JP1 2 3 4 Note: The configuration of setting jumper is different according to the type. -
Page 25: Setting Of Parameters
Connect JHT200 Handy Terminal (Note1) to the instrument to display or set parameters. Note 1: BT200 BRAIN Terminal of Yokogawa Electric Corporation can also be used. When connecting the JHT200 Handy Terminal, the adapter for modular-jack (model E9786WH) is required. When using the BT200 BRAIN Terminal of YOKOGAWA Electric Corporation, the communication cable of 5-pin connector type (model F9182EE) and the adapter for modularjack (model E9786WH) are required. -
Page 26: Description Of Parameters
5.3 Setting of Parameters 5.3.2 Description of Parameters The description of main parameters is as follows. ● Setting-related parameters D07: SENSOR TYPE1 Sets the input type for STED-7 type. The following parameters are initialized if the SENSOR TYPE1 is changed. D08: TC TYPE1 D09: RTD TYPE1 D27: INPUT1 L_RNG... - Page 27 5.3 Setting of Parameters (8) D31: BURN OUT1 Sets the burnout scale for STED-7 type. The following parameter is initialized if the BURN OUT1 is changed. P01: WIRING R 1 (9) D33: OUT1 DR and D34: OUT2 DR Sets the action direction for output 1 and output 2. If you set REVERSE, outputs 5 V (or 20 mA) for 0% and 1 V (or 4 mA) for 100%.
-
Page 28: Parameter List
Parameter List BRAIN communication parameters for STED are as follows. Symbol Parameter Name Setting Range Unit Factory-set Setting Type Value MODEL Model Name Display –––– Display TAG NO Tag Number Display –––– Display SELF CHK Self Check GOOD/ERROR –––– Display <Display Parameters>... - Page 29 5.4 Parameter List Note 1: The condition of the instrument is displayed. Note 2: Displayed only for STED-7 type. Note 3: Displayed only for STED-4 type. Note 4: Not displayed for STED-1, -4 types, and mV input for STED-7 type. Note 5: Not displayed only for STED-4 type.
- Page 30 Blank...
-
Page 31: Chapter 6 Maintenance
Chapter 6 Maintenance Maintenance This chapter describes the calibration procedures that can be done in the instrument room or service shop. IM 01B04J01-02E... -
Page 32: Test Equipment
For efficient maintenance of this converter, it is recommended that the user have the following test equipment manufactured by Yokogawa or their equivalent. ● DC Voltage/Current Standard, Yokogawa GS200 or the equivalent……..1 set (Required for mV DC and thermocouple input type equipment) ●... -
Page 33: Reference Table Of Thermocouple And Rtd
Reference Table of Thermocouple and RTD This instrument has been adjusted in accordance with the JIS thermoelectromotive force table and the resistance ratio table. For the input signals used to adjust the instruments, refer to JIS C1602, IEC 60584-1 (ITS- 90) for the thermocouple input type and to JIS C 1604, IEC 60751 (ITS-90), DIN (IPTS-68) for the platinum resistance temperature detector (RTD) input type. -
Page 34: Adjustment
Adjustment 6.3.1 Adjustment for STED-1 to -4 Types (One Input-only Type) The inputs of STED-1 to -4 types are different, but the way for adjustment is the same. (a) Connect the test equipment corresponding to each input referring to Figure 6-1 through Figure 6-4. - Page 35 6.3 Adjustment Yokogawa DM7560 or the equivalent Yokogawa DM7560 or the equivalent – – B D H Digtal Voltmeter Digital Voltmeter A C F – – Digital Voltmeter Digital Voltmeter 250 Ω ± 0.05% 250 Ω ± 0.05% Note: The broken line shows...
-
Page 36: Adjustment For Sted-7 Type (Universal Type)
6.3 Adjustment 6.3.2 Adjustment for STED-7 Type (Universal Type) The adjustment for STED-7 type without Zero/Span adjustment push-switches on the front panel is to be performed using JHT200 Handy Terminal. (a) Connect the test equipment corresponding to each input referring to Figure 6-1 through Figure 6-3. -
Page 37: Calibrating The Input Wiring Resistance
6.3 Adjustment 6.3.3 Calibrating the Input Wiring Resistance When an error occurs due to the input wiring resistance in the input signal (DC potential differences (mV DC), thermocouple, or RTD), you can calibrate parameters by using the JHT200 Handy Terminal. •... -
Page 38: Check Of Reference Junction Temperature Compensation Action
The figure of connection is shown in Figure 6-6. When using the cold junction bottle, install the reference junction block (RJC), then replace the terminal cover and warm up the instrument for about 15 minutes. Yokogawa DM7560 or the equivalent – Digital Voltmeter –... -
Page 39: List Of Replaceble Parts
List of Replaceble Parts Contact YOKOGAWA’s sales office or sales representative when replacing the spare parts. Part Name Part Number Recommended Reference replacement period Fuse S9510VK Approx. 3 years If the fuse breaks or if the replacement period elapses, please have the item replaced. - Page 40 Blank...
-
Page 41: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting Troubleshooting If any fault occurs in the instrument, note the symptoms and follow Section 7.1. IM 01B04J01-02E... -
Page 42: Action In Fault Condition
Operation while the burnout setting is OFF results in undefined. *3: If errors continue even when the input is within the range, the input circuit is broken. Contact YOKOGAWA's sales office or sales representative. IM 01B04J01-02E... -
Page 43: Chapter 8 Power Supply Terminal Connections (Options /Tb, /A2Tb, And /Rek)
Chapter 8 Power Supply Terminal Connections (Options /TB, /A2TB, and /REK) Power Supply Terminal Connections (Options /TB, /A2TB, and /REK) If you specify the terminal block to which the power source is directly connected (option codes: /TB, /A2TB, and /REK), the external wiring to the terminal block is necessary; therefore, drawing out the internal unit requires previous turning off of the power source and disconnection of the wiring from the terminal block. -
Page 44: External View And Names Of Components
External View and Names of Components Output Terminal Block Output Terminal Cover Power Fuse Power Terminal Cover Input Terminal Block Power Terminal Power and Ground Terminal connection (Connection screw: M4) Symbol Description Input Terminal Cover + Power supply Ground Figure 8-1 External View and Names of Components IM 01B04J01-02E... -
Page 45: Power Supply And Ground Wiring
Power Supply and Ground Wiring (1) All cable ends must be furnished with crimp-on type solderless lugs (for 4 mm screw). (2) Examples of applicable cables: Cross-sectional area of the cable conductor: 2.0 mm Applicable cable: 600 V vinyle insulated cable (IV) stranded wires, conforming to JIS C3307. - Page 46 Blank...
-
Page 47: General Specifications
When used with BARD-300 or BARD-700, the minimum span is 30°C (60°C for Pt50). The minimum span for Pt50 is 20°C. (BARD-300 and BARD-700 are safety barriers of YOKOGAWA.) When used with BARD-200 or BARD-600, the internal resistance of BARD (235 Ω ± 15 Ω) is not included. - Page 48 1500 V AC for 1 minute (220 V version) External Dimensions: (Height x Width x Depth from the mounting face) 180 x 48 x 300 (mm) Weight: 1.7 kg (including rack-mounting case) All Rights Reserved. Copyright © 2001, Yokogawa Electric Corporation GS 01B04J01-02E Dec.25, 2019-00...
- Page 49 DC input or thermo- couple input CENTER (RJC block installation terminal) 100% Potentiometer input input For STED-7 type, select one input from mV DC, thermocouple or RTD. All Rights Reserved. Copyright © 2001, Yokogawa Electric Corporation GS 01B04J01-02E Dec.25, 2019-00...
- Page 50 (Connection screw: M4) Symbol Description + Power supply Ground Trigonometry Unit: mm General tolerance = ±(value of tolerance class IT18 based on JIS B 0401-2016) / 2 F02.ai All Rights Reserved. Copyright © 2001, Yokogawa Electric Corporation GS 01B04J01-02E Dec.25, 2019-00...
- Page 51 (Connection screw: M4) Symbol Description + Power supply Ground Trigonometry Unit: mm General tolerance = ±(value of tolerance class IT18 based on JIS B 0401-2016) / 2 F03.ai All Rights Reserved. Copyright © 2001, Yokogawa Electric Corporation GS 01B04J01-02E Dec.25, 2019-00...
- Page 52 Measuring range and unit e.g. 0 to 100 °C 3. Burnout selection: Optional specification Select from UP, DOWN or OFF. If not specified: OFF All Rights Reserved. Copyright © 2001, Yokogawa Electric Corporation GS 01B04J01-02E Dec.25, 2019-00 Subject to change without notice.
- Page 53 9th Edition/May 2004 Change of the company name. 10th Edition/Oct. 2019 Change of the style number. 11th Edition/Dec. 2019 Revision of the General Specifications. Written by Yokogawa Electric Corporation Published by Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN...
- Page 54 3F Tower D Cartelo Crocodile Building, No.568 West Tianshan Road, Shanghai 200335, CHINA Phone : 86-21-62396262 Fax : 86-21-62387866 YOKOGAWA ELECTRIC KOREA CO., LTD. (Yokogawa B/D, Yangpyeong-dong 4-Ga), 21, Seonyu-ro 45-gil, Yeongdeungpo-gu, Seoul, 07209, KOREA Phone : 82-2-2628-6000 Fax : 82-2-2628-6400 YOKOGAWA ENGINEERING ASIA PTE. LTD.
