8. TECHNICAL SPECIFICATIONS

OPERATING VOLTAGE
10 – 16Vdc. (13.8V Nominal)
Reverse polarity protected
CURRENT CONSUMPTION
Stand by (alt. flashing): 30mA typical
(+10mA for backup battery) BACKUP BATTERY
Strobe only: 165mA typical
Siren only: 245mA typical
Siren and Strobe: 440mA typical
DIMENSIONS & WEIGHT
Dimensions: 325mm x 180mm x 75mm
Weight: 1.4kg
TAMPER PROTECTION
Activation from front or back and power supply cut off
INPUT ACTUATION
Strobe and Siren, switched negative or positive
comply with PD 6662:2004 at Security Grade 3 and Environmental Class 4.
Page: 18
This product is suitable for use in systems designed to
SIREN AND STROBE OUTPUT
Maximum peak: 118dBA @ 1m (85dBA Spain)
Flash rate: 120/min typical
Tube size: 3 Watt
280mAh 7.2 V NiCad (included)
30 min continuous use (Siren and Strobe)
SIREN CUT OFF TIMER
Test: ≤ 5 seconds
Normal: ≤ 15 minutes
ENVIRONMENT
Operating Temperature:
-30˚ to 50˚C (-22˚ to 122˚F)
Storage Temperature:
-40˚ to 60˚C (-40˚ to 140˚F)
EN50131-1
Security Grade 3
Env 4
DECIBELL
RINS040-5
