DECIBELL

2.5 Strobe Connector

This is where the strobe for the DECIBELL connects; the strobe is powered by a 200V+ signal.
DO NOT TOUCH THE STROBE AS THERE IS A DANGER OF AN ELECTRIC SHOCK.
W H E N W O R K I N G I N C L O S E P R O X I M I T Y I N S U B D U E D L I G H T O R D A R K N E S S
T H E S T R O N G L I G H T E M I T T E D M A Y C A U S E T E M P O R A R Y V I S I O N F A I L U R E .

2.6 Case Tamper

The DECIBELL is fitted with a case tamper switch, operated by removing the case holder screw. The
tamper switch can be adjusted by carefully bending the metal spring.
RINS040-5
200 VOLTS
DO NOT
TOUCH!
W A R N I N G :
T A K E P R E C A U T I O N S !
TAMP TAMP
FEED RET
(BT)
TAMP TAMP
FEED RET
(BT)
