STAGE IN PROGRESS COUNTDOWN
(visible while the program is running)
EVAPORATOR TEMP. PROBE
MEASUREMENT
(visible if enabled)
Ph PROBE MEASUREMENT
(visible if enabled)
HOT WATER TEMP. PROBE
MEASUREMENT
(visible if enabled)
COLD WATER TEMP. PROBE
MEASUREMENT
(visible if enabled)
EXTERNAL TEMP. PROBE
MEASUREMENT
(visible if enabled)
USER AND MAINTENANCE MANUAL
Pag. 33
This dial is only displayed while the program is running. It
indicates the name and the time remaining to the end of the
stage in progress.
This dial is only viewed if the variable "Parameters >
Defrosts > dE Evaporator probe enabled = 1" and if the
related analogue input is set.
This dial is only viewed if the variable "Parameters > pH
probe > EpH measurement enabling = 1" and if the related
analogue input is set.
This dial is only viewed if the variable "Parameters > Hot
water management > EHv Hot water management enabling
= 1" and if the related analogue input is set.
This dial is only viewed if the variable "Parameters > Cold
water management > EHv Cold water management
enabling = 1" and if the related analogue input is set.
This dial is only viewed if the variable "Parameters >
Automatic air change> EEs Energy saving enabling = 1"
and if the related analogue input is set.
