LRS CurbAlert Install Manual

Paging system transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CurbAlert
Paging System Transmitter
I N S TA L L M A N U A L
Long Range Systems UK Ltd | Link House | Leek Road | Milton | Stoke on Trent | Staffordshire | ST2 7AH | 01782 537000
www.lrspagers.co.uk | www.pagers.co | www.hospitalpagers.co.uk
I I n n s s t t a a l l l l a a t t i i o o n n , , W W a a r r r r a a n n t t y y a a n n d d S S e e r r v v i i c c e e I I n n f f o o r r m m a a t t i i o o n n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CurbAlert and is the answer not in the manual?

Questions and answers

Related Manuals for LRS CurbAlert

Summary of Contents for LRS CurbAlert

  • Page 1 CurbAlert Paging System Transmitter I N S TA L L M A N U A L I I n n s s t t a a l l l l a a t t i i o o n n , , W W a a r r r r a a n n t t y y a a n n d d S S e e r r v v i i c c e e I I n n f f o o r r m m a a t t i i o o n n Long Range Systems UK Ltd | Link House | Leek Road | Milton | Stoke on Trent | Staffordshire | ST2 7AH | 01782 537000 www.lrspagers.co.uk | www.pagers.co | www.hospitalpagers.co.uk...

  • Page 2: Table Of Contents

    Warranty ............ong Range Systems CurbAlert User Manual...

  • Page 3: System Installation

    If possible a survey of the site prior to installation will assure the proper equipment is on site. • Laptop running Windows 2000 or XP and LRS camera adjustment software. • Crossover cable (connected to camera) • CAT 5 cable on a reel (enough to do a 100-ft installation) •...

  • Page 4: Camera Installation

    Example: A is 30 feet. The camera can be mounted at any of the heights in the table (higher the bet- ter) and zoomed to adjust for the target area. TABLE GENIE ong Range Systems CurbAlert User Manual...

  • Page 5: Basic Power Connections

    Power Supplies NOTICES: • The Surge protector must be mounted near the MONITOR and all items shown are connected to it! • This is a touch screen monitor it must be accessible to the users. ong Range Systems CurbAlert User Manual...

  • Page 6: Camera Signal Connections (Preferred Connection)

    Camera Parking Spaces Cat 5 Network Cable Supplie by Installer Cat 5 Network Cable Supplie in Kit Monitor Surge Protector NOTICE: • Any junction boxes or cable routing must be sealed and weather protected. ong Range Systems CurbAlert User Manual...

  • Page 7: Using A Laptop To Adjust The Curbside Camera

    6. If the Active X warning appears, click on the warning to install Active X (password and user name = admin). Note: Check pop up bar if pop up blocker is active. 7. Install the Active X program. ong Range Systems CurbAlert User Manual...
  • Page 8 Use Live Video to adjust camera. 8. When finished with camera adjustment, return Laptop to normal network mode and connect cam- era to system for final setup. ong Range Systems CurbAlert User Manual...

  • Page 9: Laptop Manual Network Setup

    5. Set the manual properties as shown. • IP Address 192.168. 0 .254 • Subnet mask 255.255.255. 0 • Default Gateway 192.168. 0 .254 Optional Preferred DNS server 192.168. 0 .254 6. Select Okay until returned to normal display screen. ong Range Systems CurbAlert User Manual...
  • Page 10 This procedure may vary slightly de- pending upon the version of Win- dows being used. 2. From Settings Menu, select Local Area Con- nection. 3. Select Properties. 4. Highlight Internet Protocol (TCP/IP) then se- lect Properties. ong Range Systems CurbAlert User Manual...
  • Page 11 5. Select “Use the Following IP address” 6. Either select: • Obtain an IP Address automatically or • Reset the manual properties noted in step 3 of the above procedure. 7. Select Okay until returned to normal display screen. ong Range Systems CurbAlert User Manual...

  • Page 12: Network Signal Connections

    Parking Spaces Surge Protector Cat 5 Network Cable Supplie by Installer Cat 5 Network Cable From Router Kit LAN1 Cat 5 Cable From Basic Kit Router LAN2 LAN Cable to Network Supplied by Use ong Range Systems CurbAlert User Manual...

  • Page 13: Configure System

    2. Paging sets up server manager and duty pagers. 3. Schedule sets intervals for periodic paging. • Zones is used to define the detection zones. • Tune video sets the detection threshold. • Location defines the installation site. ong Range Systems CurbAlert User Manual...

  • Page 14: Setup System Screen

    Resolution The resolution buttons are not used with this camera. Software Upgrade This function should only be used at the direction of LRS. If a software upgrade is required the system must be connected to the Internet. ong Range Systems...

  • Page 15: Setup Paging Screen

    • System ID – distinguishes pages to particular systems to prevent interference in the event more than one LRS paging system is in the area. • Manager Pager – this number is the pager assigned to the manager. It will receive pages when greet and delivery times are exceeded and periodic updates of system status.

  • Page 16: Setup Schedule Screen

    Enables, sets the interval, and time period for sending the manager updates of average greet times and serv- ing times. Duty Paging Enables, sets the interval, and time period for sending the duty person a reminder message to perform a pe- riodic duty. ong Range Systems CurbAlert User Manual...

  • Page 17: Zones Screen

    This is the zone where arriving traffic will alert staff. 1. Select the zone desired (Z1 – Z6). 2. Press the Assign button. 3. Touch to select the zone outline. 4. Press the Save button. 5. The zone outline will be shown. ong Range Systems CurbAlert User Manual...

  • Page 18: Greet Zone Setup

    Greet detection. • Several zones can be stacked to detect if greeters walk through a selected area (if multi cars have arrived this will show all Alert zones as greeted). ong Range Systems CurbAlert User Manual...

  • Page 19: Tuning Screen

    Tuning Screen The tuning Screen is used to adjust light and contrast levels for the best event detection. The default detec- tion is optimal for most installations. This screen should only be used at the direction of LRS. For best results, 1.

  • Page 20: Location Setting Screen

    Backup sends the data to LRS for identification. A High Speed Internet connection is required. Restore is used to contact LRS database to restore system settings. A High Speed Internet connection is re- quired.

  • Page 21: Oem Tx Setup

    OEM TX SETUP The OEM Transmitter is required to link the Monitor to the LRS pagers. To setup: 1. Remove the kit from packaging. The kit should include: • 1 OEM Transmitter • 1 Serial Cable • 1 BNC Antenna •...

  • Page 22: Service Questions And Answers

    (800) 437-4996 Monday through Friday 8:30 am to 5:00 pm Central Time. For weekend or night emergencies: • Long Range Systems has 24/7 live technical support available • Please keep in mind that options are limited over the weekend. ong Range Systems CurbAlert User Manual...

  • Page 23: Warranty

    If this product should become defective within the war- ranty period, we will repair or replace it with an equivalent product, free of charge. LRS will return your product via UPS ground shipping. All warranty claims must be initiated through our customer service department.
