TECP-90-717
Rev C, August 2019
commscope.com
Install the module on the rear of the universal chassis. Follow the numbered steps within the illustrations
below.
M
N
O
P
Q
R
T
U
V
ACCESS
TRAY
W
HANDLE
X
M
END OF
N
ARM
O
GUIDE
P
Q
R
P
T
U
INNER TRAY
CABLE GUIDE
V
W
X
NOTE: DO NOT INSTALL ADDITIONAL LABELS TO TOP OF MODULE.
INTERFERENCE MAY RESULT WITH ADJACENT TRAYS.
TECP-90-717 Rev C
NG4access ODF Platform Cabled Module (CMOD)
1. Pull out access tray handle.
2. Snap module down in five locations shown.
3
5
1
2
3. Route fiber cable through inner tray cable
CROSS
FRAME
guide and end of arm guide.
TROUGH
R
R
4
25208-B
4. Close the access tray.
Q
R
P
T
U
V
T
T
Danger:
!
© 2019 CommScope, Inc.
Installation
Instructions
25209-A
Infrared radiation is
invisible and can seriously
damage the retina of the
eye. Do not look into the
ends of any optical fiber.
Do not look directly into
the optical adapters
of the adapter packs.
Page 1 of 4
