  • Page 1 Quick reference guide 3D sensor O3D3XX...
  • Page 2: Table Of Contents

    Contents 1 Preliminary note ���������������������������������������������������������������������������������������������������3 1�1 Symbols used ������������������������������������������������������������������������������������������������3 1�2 Warnings used �����������������������������������������������������������������������������������������������3 1�3 Copyright and trademarks �����������������������������������������������������������������������������3 1�4 Open source information �������������������������������������������������������������������������������4 2 Safety instructions �����������������������������������������������������������������������������������������������5 2�1 Safety note ����������������������������������������������������������������������������������������������������6 3 Functions and features ����������������������������������������������������������������������������������������6 4 Items supplied������������������������������������������������������������������������������������������������������7 5 Installation������������������������������������������������������������������������������������������������������������8 5�1 Mounting accessories ������������������������������������������������������������������������������������9 6 Electrical connection ��������������������������������������������������������������������������������������������9 6�1 Wiring example ��������������������������������������������������������������������������������������������10...
  • Page 3: Preliminary Note

    ► Measures to take� 1.3 Copyright and trademarks © All rights reserved by ifm electronic gmbh� No part of these instructions may be reproduced and used without the consent of ifm electronic gmbh. All product names, pictures, companies or other brands used on our pages are the...
  • Page 4: 1�4 Open Source Information

    The price of the ifm products has then to be paid for the respective device itself (hardware) and not for the firmware. For the latest information on the license agreement for your product please visit www.ifm.com...
  • Page 5: Safety Instructions

    We charge €30 for each request. Please write “source for product Y” in the memo line of your payment. Your request should include (i) the name of the covered binary, (ii) the name and the version number of the ifm product, (iii) your name and (iv) your return address�...
  • Page 6: 2�1 Safety Note

    2.1 Safety note NOTICE IR light emitted from this product� Classification acc� to IEC 62471:2006 Exempt group 3 Functions and features The O3D3xx 3D sensor is a photoelectric sensor measuring the distance between the sensor and the nearest surface point by point using the time-of-flight principle� The sensor illuminates the scene with an infrared light source and calculates the distance by means of the light reflected from the surface�...
  • Page 7: Items Supplied

    4 Items supplied • O3D3xx 3D sensor • Spring washers (only O3D30x) • Quick reference guide ► Only use accessories from ifm electronic� Available accessories: www.ifm.com The optimum function is not ensured when using components from other manufacturers� The device is supplied without installation and connection accessories.
  • Page 8: Installation

    5 Installation During installation note the following: ► Use cables with strain relief. ① ► Keep areas clear of objects. ② ③ ► Within area position the object to be detected closer to the device than any other objects. ► Mount the device so that the focus adjustment screw is freely accessible with a screw driver.
  • Page 9: 5�1 Mounting Accessories

    E3D352 Smart Camera heat conductor E3D353 2x Smart Camera cooling element E3D354 Available accessories: www.ifm.com 6 Electrical connection ATTENTION! Depending on the operating mode, the device may heat up� The difference between the camera's surface temperature and the ambient temperature must not exceed 25 degrees� Take one or several of the following measures: ►...
  • Page 10: 6�1 Wiring Example

    For the scope of validity cULus: • Minimum temperature rating of the cable to be connected to the field wiring terminals: 70 °C. • The IP class was not assessed by UL. Moisture can penetrate into the device if the connected cables and protective caps are not fully tightened�...
  • Page 11: 6�2 Wiring

    TD - RD - Shield (2) Power supply M12 connector, A-coded, 8 poles trigger input switching output 1 (digital or analogue) switching output 3 ready switching output 2 (digital) switching input 1 switching input 2 Fig 3: Wiring Available accessories: www.ifm.com...
  • Page 12: Maintenance, Repair And Disposal

    ► Use glass cleaner as cleaning agent. > Cleaning agents containing solvents can damage the front glass� ► Do not open the device� > Only the manufacturer is allowed to open the device. 8 Approvals/standards The EU Declaration of Conformity is available at www.ifm.com.
