Telguard TG-7 Series
QUICK INSTALLATION GUIDE [BACKUP MODE]
Installation Summary
There are seven steps in installing Telguard properly. IF YOU DO NOT
PROCEED IN THE ORDER AND MANNER PRESCRIBED, YOU MAY
NOT COMPLETE THE INSTALLATION IN THE TIME ALLOCATED.
S
1: R
C
TEP
EGISTER FOR
ELLULAR
The registration form may be completed online through our 24/7 dealer portal
www.telguard.com.
S
2: L
U
M
TEP
OCATE
NIT AND
EASURE
With the unit powered up, press the LED/RSSI Mode Toggle button one time, LEDs will now
indicate signal strength. Minimum recommended is 2 (2 on solid). Position the Telguard in a
location where minimum signal strength is satisfied. Press the LED/RSSI Mode Toggle button a
second time to exit RSSI mode.
S
3: T
P
A
TEP
RANSMIT
ANEL
LARMS OVER THE
Verify the alarm panel is programmed properly by transmitting a signal over the telco connection.
This step is important to verify that the alarm panel is programmed with valid account code and
central station information before transmitting signals through the cellular network.
S
4: P
, A
& T
TEP
ROGRAM
CTIVATE
C
R
N
ELLULAR
ADIO
ETWORK
Connect the alarm panel's digital dialer output to the Telguard and verify the alarm signals can be
reliably sent through Telguard over the cellular network to the central station digital receiver. The
incoming Telco line is not connected to Telguard during this step. A minimum of two alarm
signals must be transmitted. Activation is confirmed when LED 1 becomes illuminated.
(NOTE:
THE FIRST ALARM WILL ACTIVATE THE UNIT AT THE
C
,
C
ENTER
IT WILL NOT GO TO THE
ENTRAL
C
S
)
SENT TO THE
ENTRAL
TATION
S
5: C
S
TEP
ONNECT
UPERVISORY
Wire the Telguard's supervisory trip outputs to the alarm panel and then test.
S
6: C
T
I
(
TEP
ONNECT
RIP
NPUT
Wire an external relay to the trip input lead and ground, and test.
S
7: C
I
TEP
OMPLETE THE
NSTALLATION
Attach earth ground to the Telguard, reconnect Telco, and permanently mount the unit.
S
ERVICE
S
S
(RSSI)
IGNAL
TRENGTH
T
C
ELCO
ONNECTION
P
A
RANSMIT
ANEL
LARMS OVER THE
T
C
ELGUARD
OMMUNICATION
S
,
TATION
ALL SIGNALS AFTER THE FIRST ARE
T
O
RIP
UTPUTS
)
OPTIONAL
