LED White192 Panel
White LED panel for use as a wash or effect
M
A
N
U
A
L
V
E
R
S
I
O
N
2
.
0
20 / 12 / 10
192 bright white LEDs
3 channel DMX512 operation
Sound-to-Light, Auto & DMX modes
Adjustable sound sensitivity
DMX512 compatible / XLR connection
Strobe type effect
Stand-alone with master/slave mode
Robust protective housing
Adjustable metal hanging bracket
Dimensions: 385 x 235 x 100mm (WxHxD)
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change.
© Copyright Lamba plc 2010. E&OE.
Advertisement
Related Manuals for KAM LED White192 Panel
Summary of Contents for KAM LED White192 Panel
- Page 1 For the latest instruction manual updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
- Page 2 Thank you for purchasing this product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. After you have read the instructions, please retain them for future reference. This unit has been tested at the factory before being shipped to you.
-
Page 3: Installation
Panel 1．Switch on/off 2．Fused IEC power socket 3．DMX in 4．DMX out 5．Sound sensitivity control 6．DMX LED 7．Dipswitches 8．Power LED Installation When mounting the unit onto a truss or overhead rigging, ensure that a suitable mounting clamp is used and also secure unit with safety chain. -
Page 4: Operation
DMX cable wiring configuration OPERATION Manual stand alone mode using the dipswitches. Ch2 shows the on position. Dipswitch Function All off Full brightness with sound to light To operate dipswitches 1-7 functions, dipswitch 9 must be switched on Dipswitches 1+9 Slow program Dipswitches 2+9 Faster program... - Page 5 DMX mode introduction The UV panel uses 3 DMX channels Setting DMX mode To activate the DMX mode dipswitch 10 must be in the on position, then use dipswitches 1-9 to set the DMX address. DMX function When DMX signal is present the Blue LED will flash. Each fixture occupies 3 DMX channels.
- Page 6 Master/ slave mode When linking the units together with no controller one unit must be set as the master unit, all others to slave units. To set master: Sound active mode All switches are Off. Auto mode Dipswitch 9 + desired effect see above chart. Slave mode Set all slave units with dipswitch 10 on only.
- Page 7 Technical specification LED colour & number 192 white LEDs Beam angle 45° Data input 3 pin XLR male socket Data output 3 pin XLR female socket Data pin configuration pin 1 shield, pin 2(-),pin3 (+) Protocols Full DMX512 DMX channels Surrounding temperature 35℃...
