ADC AD-81 Parts Manual page 9

Illus. No. Part No.
1 881150
881207
2 102354
170730
170731
3 881152
881208
4 150445
150443
5 153031
6 881151
881209
7 150445
150443
8 150683
150682
9 152014
10 151010
151009
11 150120
12 150683
150682
13 152014
14 881210
170333
15 102210
102360
450452 - 4
Qty. Description
1 Black Main Door Assembly Complete
(includes illus. nos. 1, 2, and 8 through 15)
1 Stainless Steel Main Door Assembly Complete
(includes illus. nos. 1, 2, and 8 through 15)
1 Door Gasket
1 Clear Glass and Gasket Adhesive (10.3 oz. cartridge)
1 Black Glass and Gasket Adhesive (10.3 oz. cartridge)
1 Black Top Hinge Block Assembly
(includes illus. nos. 3 and 4)
1 Stainless Steel Top Hinge Block Assembly
(includes illus. nos. 3 and 4)
2 1/4-20 x 7/8" Black Cap Head Setscrew
2 1/4-20 x 7/8" Stainless Steel Cap Head Setscrew
1 1/4" Nylon Washer
1 Black Bottom Hinge Block Assembly
(includes illus. nos. 5 through 7)
1 Stainless Steel Bottom Hinge Block Assembly
(includes illus. nos. 5 through 7)
2 1/4-20 x 7/8" Black Cap Head Setscrew
2 1/4-20 x 7/8" Stainless Steel Cap Head Setscrew
3 1/4-20 x 5/8" Black Carriage Bolt
3 1/4-20 x 5/8" Stainless Steel Carriage Bolt (for models with stainless steel doors)
3 1/4-20 Free Spin Wash Nut
1 #10-32 Black Hex Acorn Nut
1 #10-32 Stainless Steel Hex Acorn Nut
1 Door Latch Screw
3 1/4-20 x 5/8" Black Carriage Bolt
3 1/4-20 x 5/8" Stainless Steel Carriage Bolt (for models with stainless steel doors)
3 1/4-20 Free Spin Wash Nut
1 Black Main Door Handle ONLY
1 Stainless Steel Main Handle ONLY
1 20-7/16" Door Glass
1 Glass / Door Gasket Tape
Cold Rolled Steel Main Door Assembly
www.amdry.com 9
