ADC AD-81 Parts Manual

Adc dryer parts manual
Hide thumbs Also See for AD-81:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
AD-81 Parts Manual
Phase 5 24 VAC
2001-2002
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 450452-4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-81 and is the answer not in the manual?

Questions and answers

Related Manuals for ADC AD-81

Summary of Contents for ADC AD-81

  • Page 1 AD-81 Parts Manual Phase 5 24 VAC 2001-2002 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450452-4...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

  • Page 3: Table Of Contents

    Table of Contents Hingeless Control Door Assembly for Models Mfd. as of July 20, 2002 ... 4 Control Door Assembly for Models Mfd. prior to July 20, 2002 ... 5 Phase 5 OPL Microprocessor Control Panel Assembly ... 6 Phase 5 OPL Microprocessor Control Box Assembly ... 7 Cold Rolled Steel Main Door Assembly ...

  • Page 4: Hingeless Control Door Assembly For Models Mfd. As Of July 20, 2002

    Control Door Rod Catch 102502 Control Door Support Rod 102601 Control Door Rod Retainer Clip 881053 ADC Logo ONLY (with double adhesive tape) 870011 Logo Double Adhesive Tape Kit ONLY * Specify color when ordering. ® BTN Type 1 Screw...

  • Page 5: Control Door Assembly For Models Mfd. Prior To July 20, 2002

    Illus. No. Part No. Qty. Description 882052 ADC Metal Logo ONLY (with double adhesive tape) 870011 Logo Double Adhesive Tape Kit ONLY 881045* Control Door (includes illus. nos. 2 and 3) 881046 Stainless Steel Control Door (includes illus. nos. 2 and 3)

  • Page 6: Phase 5 Opl Microprocessor Control Panel Assembly

    Phase 5 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 OPL English Keypad Label Assembly 881032 Microprocessor Control Panel ONLY 881033 Microprocessor Control Panel ONLY with Battery Bracket 881034 Phase 5 OPL Reversing Microprocessor Control Panel Assembly Complete (includes illus.

  • Page 7: Phase 5 Opl Microprocessor Control Box Assembly

    Illus. No. Part No. Qty. Description 141403 24 VAC Transformer 150300 #10-16 x 1/2” Hex Washer TEK Screw 120715 30-Position Terminal Block 150002 #6-32 x 1” Phillips Round Head Machine Screw 151000 #6-32 Pal Nut 136057 1/2-Amp (Slo-Blo) Fuse 150301 #8-18 x 7/16”...

  • Page 8: Cold Rolled Steel Main Door Assembly

    Cold Rolled Steel Main Door Assembly American Dryer Corporation 450452 - 4...
  • Page 9 Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 881207 Stainless Steel Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170730 Clear Glass and Gasket Adhesive (10.3 oz.

  • Page 10: Cold Rolled Steel Door Front Panel Assembly

    Cold Rolled Steel Door Front Panel Assembly Illus. No. Part No. Qty. Description 881994 Right Hand Front Panel Complete (includes illus. nos. 1, 3, 5, and 6) 150313 #10-16 x 1/2” TORX PLUS 121405 Rubber Grommet –––––– Lint Drawer Switch (refer to Lint Drawer with Stainless Steel Lint Screen / Lint Drawer Switch Assemblies on page 13) 881987...

  • Page 11: Main Door Switch Assembly Cold Rolled Steel Door

    Illus. No. Part No. Qty. Description 153566 #6-32 x 7/8” Clinch Stud 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single-Pole Door Switch 122636 Flag Terminal 881211 Main Door Switch Housing 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 450452 - 4 Main Door Switch Assembly Cold Rolled Steel Door www.amdry.com...

  • Page 12: Lint Drawer With Cloth Lint Screen / Lint Drawer Switch Assemblies

    Lint Drawer with Cloth Lint Screen / Lint Drawer Switch Assemblies Illus. No. Part No. Qty. Description 883503* Lint Drawer Assembly (includes illus. nos. 1 and 2) 881464 Stainless Steel Lint Drawer Assembly (includes illus. nos. 1 and 2) 117605 Gasket (sold by the foot) 802205 Lint Screen Assembly...

  • Page 13: Lint Drawer With Stainless Steel Lint Screen / Lint Drawer Switch Assemblies

    Lint Drawer with Stainless Steel Lint Screen / Lint Drawer Switch Assemblies Illus. No. Part No. Qty. Description 882871 White Lint Drawer with Stainless Steel Screen 117605 Gasket (sold by the foot) 122116 Lint Drawer Switch 122605 4-Pin Socket Connector 122701 Socket Terminal ONLY 122801...

  • Page 14: Sensor Bracket Assembly

    Sensor Bracket Assembly Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 through 4) 122605 4-Pin Socket Connector 122701 Socket Terminal ONLY 154007 1/4” Tinnerman Push-On Fastener 150000 #6-32 x 1/4” Round Head Machine Screw 802174 Sensor Bracket Assembly Complete (includes illus.

  • Page 15: Tumbler / Support Assembly

    Illus. No. Part No. Qty. Description 880818 Tumbler ONLY without Felt Collar (includes illus. nos. 1 through 3) 880827 Reversing Tumbler and Support Assembly Complete (includes illus. nos. 1 through 11) 154210 5/32” x 3/16” Pop Rivet 301308 Tumbler Rib ONLY 150407 5/16-18 x 3/4”...

  • Page 16: Tumbler Bearing Assembly

    Tumbler Bearing Assembly American Dryer Corporation 450452 - 4...
  • Page 17 Illus. No. Part No. Qty. Description 880220 1-3/4” Flange Bearing 153025 9/16” Lock Washer 152050 9/16-12 Hex Nut 882545 Pillow Block Bearing Assembly Complete with Rotational Sensor (includes illus. nos. 4 through 18) 882543 Pillow Block Bearing Platform ONLY 880779 1-3/8”...

  • Page 18: Reversing T.e.f.c. Motor Mount Assembly

    Reversing T.E.F.C. Motor Mount Assembly American Dryer Corporation 450452 - 4...
  • Page 19 Illus. No. Part No. Qty. Description 100109 4L-630 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101130 5/8” x 2-1/2” Motor Pulley (60 Hz Only) 101139 5/8” x 2-3/4” Motor Pulley (50 Hz Only) 120200 3/8” x 90° Connector 181003* 1/2 hp 208/230/380/460v 3ø...

  • Page 20: Burner Assembly Ii

    Burner Assembly II American Dryer Corporation 450452 - 4...
  • Page 21 Illus. No. Part No. Qty. Description 802237 Burner Box ONLY 881258* Natural Gas Burner Assembly II Complete Less Orifice (includes illus. nos. 1 through 9 and 11 through 32) 881257* Liquid Propane Burner Assembly II Complete Less Orifice (includes illus. nos. 1 through 9 and 11 through 32) 802240 Burner Shield 150309...

  • Page 22: Idler Bearing Assembly

    Idler Bearing Assembly Illus. No. Part No. Qty. Description 100106 5L-690 V-Belt 101140 14” x 3” Compound Pulley 100109 4L-650 V-Belt (idler to motor) 154301 5/16-18 x 1” Allen Setscrew 100705 3/16” x 3/16” x 1-3/8” Key 882576 Idler Bearing Assembly Complete (includes illus.

  • Page 23: Reversing Rear Control Box Assembly

    Illus. No. Part No. Qty. Description 323743 Relay Panel ONLY 137013 Nylon Standoff 137060 Arc Suppressor Board 132445 3 hp Contactor 150103 #8-32 x 3/4” Phillips Pan Head Machine Screw 132467 Blower Overload (for 208 volt and 230 volt models Only) 132468 Blower Overload (for 380 volt and 600 volt models Only) 152004...

  • Page 24: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 105500 Sail Switch Actuator Rod 319202 Sail Switch Damper (flat) 154002 1/8” Push-On Fastener 802800 Sail Switch Box with Cover and Bracket ONLY (includes illus. nos. 4, 8, and 9) 802801 Sail Switch Box Assembly Complete (includes illus.

  • Page 25: Step Down Transformer Usage Listing

    Step Down Transformer Usage Listing Heat Voltage Gas / Steam 460/480 NOTE: Step Down Transformer used on models mfd. for 380 volts or higher. 450452 - 4 Step Down Transformer Usage Listing (Reversing Relay Box) Transformer Part Number Wire Service Microprocessor Models 3 or 4 3 or 4...

  • Page 26: Air-Operated Steam Damper Assembly

    Air-Operated Steam Damper Assembly American Dryer Corporation 450452 - 4...
  • Page 27 Illus. No. Part No. Qty. Description 165009 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 803415 Steam Damper Assembly (includes illus. nos. 7, 10, and 11) 153007 1/4”...

  • Page 28: Outer Top / Back Guard Assemblies

    Outer Top / Back Guard Assemblies Illus. No. Part No. Qty. Description 312527 Outer Top Assembly (for gas models Only) 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 323759 Top Back Guard Assembly (26-7/8” x 13-15/16”) 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 323749 Rear Electrical Box Cover (10-13/16”...

  • Page 29: Additional Parts Available

    Part No. Description 112280 “Clean Lint Screen” Label 112534 “Phase 5 OPL Program Location Summary” Label 122804 Manometer (hydro gauge) for Measuring Gas Pressure 114001 “CAUTION – Exhaust / Lint Screen” Label 114006 “WARNING – Fire Hazards” Label 120100 3/8” Straight (BX) Connector 120300 3/8”...
  • Page 30 ADC Part No. 450452 4 - 02/01/08 - 0...
