Control Door Assembly For Models Mfd. Prior To July 20, 2002 - ADC AD-81 Parts Manual

Illus. No. Part No.
1 882052
870011
2 881045*
881046
3 117604
4 150300
5 102600
6 102601
7 102502
8 160005
* Specify color when ordering.
450452 - 4
Qty. Description
1 ADC Metal Logo ONLY (with double adhesive tape)
1 Logo Double Adhesive Tape Kit ONLY
1 Control Door
(includes illus. nos. 2 and 3)
1 Stainless Steel Control Door
(includes illus. nos. 2 and 3)
4 Neoprene Sponge Tape (sold by the foot)
4 #10-16 x 1/2" Hex Washer TEK Screw
1 Control Door Rod Support Catch
1 Control Door Retainer Clip
1 Control Door Rod
2 Turn Latch
For Models Mfd. prior to July 20, 2002
www.amdry.com
Control Door Assembly
5
