Whittington Desk & Hutch
Assembly Difficulty
easy -
medium
- hard
two-person job
Thank you for shopping with GLTC, we hope you enjoy having
this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail through
the whole process. But if it all feels a bit too much like hard work, then
we do have an assembly company we can recommend: the Flatpack
Construction Company offers a nationwide service and can be
contacted on 0843 289 4951 or www.flatpackconstruction.co.uk.
A few important pointers before you start:
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
It's a good idea to build the unit in the room where you are going to be
using it, to avoid the need to move it after it's been assembled.
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts and hardware.
V4
29/04/2020
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Whittington L4981 and is the answer not in the manual?

Questions and answers

Summary of Contents for Great Little Trading Whittington L4981

  • Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling www.gltc.co.uk this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail through the whole process.
  • Page 2: Customer Service

    Safety Warnings: Customer Service: • If you find that any components are missing or damaged, please do • Adult assembly required. not begin assembly and do not use the item. Please contact GLTC • Unassembled product contains small parts which may present a Customer Services on 0344 848 6000 immediately.
  • Page 3: Component Checklist

    Component Check List 4x Desk Legs 1x Desk Top 1x Hutch: Side Panel 1x Hutch: Vertical Divider 1x Drawer Back 1x Hutch: Top Shelf 1x Drawer Front 1x Hutch: Small Shelf 1x Drawer Base 2x Drawer Sides 1x Hutch: Back Panel 1x Hutch: Side Panel...
  • Page 4 Component Check List Component Check List 13x Cam Dowel 13x Cam Lock 2x L-Shaped Runner 2x Flat Runner 20x Wooden Dowel 8x Bolt (57mm) 1x Drawer Handle Your will need a Phillips Screwdriver 7x Wood Screw 12x Wood Screw (30mm) (14mm) 8x Flat Washer 8x Split Washer...
  • Page 5 STEP 2: STEP 1: Prepare the hardware to attach the legs by taking 1x bolt (#4), thread on 1x Position the desk top on a protective surface like a rug or carpet as shown. split washer (#8) followed by 1x flat washer (#7). Prepare all remaining bolts. Attach the 2x flat runners (#9) to the inside of the desk.
  • Page 6 STEP 3: STEP 4: Hardware for Step 3: Take both of the drawer side panels (E) and position Slide drawer base panel F into the grooves. with drawer back panel (D) so that the grooves on the panels are all facing inwards and aligning. The small drill holes along the edges of the panels E should be visible and facing up.
  • Page 7 Using Cam Locks: STEP 5: Hardware for Step 5: When inserting into the panel, ensure that Take the drawer front panel C and insert 2x cam each cam lock’s arrow is pointing towards the dowels (#1) into the 2 smaller holes on the ends drill hole on the side edge of the panel &...
  • Page 8 STEP 7: STEP 8: Hardware for Step 7: Turn the drawer over so the small holes on Carefully stand the desk up on its legs and insert the the edges of the side panels are visible. drawer. Position 2x L-Shaped drawer runners (#10) on each side ensuring the wheel is at the back of the drawer.
  • Page 9 STEP 9: Hardware for Step 9: Prepare both hutch side panels (H & I) and insert the cam dowel and wooden dowel hardware into the pre-drilled holes as shown. 7x #1 Cam Dowels Cam dowels to go in the smaller holes, wooden dowels in the larger holes.
  • Page 10 STEP 12: Hardware for Step 11: STEP 11: Hardware for Step 12: Take vertical divider panel (J) and insert 2x Take the upper shelf panel (L) and insert 2x wooden dowels (#3) and 1x cam dowel (#1) into wooden dowels (#3) and 1x cam dowel (#1) the holes shown.
  • Page 11 STEP 13: Hardware for Step 13: STEP 14: Hardware for Step 14: Take shelf panel K and push onto the hardware Take hutch side panel (I) and push onto the end on panel J. Ensure the large drill holes are of the unit as shown.
  • Page 12 STEP 15: Hardware for Step 15: Your hutch unit is now complete. Carefully stand the hutch unit up and insert 2x cam locks (#2) into the holes on the side of the back panel and turn clockwise to secure. 2x #2 Cam Lock...
  • Page 13 STEP 17: Hardware for Step 17: With the help of a second person, carefully position the hutch onto the desktop - aligning Hardware for Step 16: STEP 16: the hardware on the desktop with the holes on Return to the Desk and insert 2x cam dowels the underside of the hutch.
  • Page 14 Finally, insert 2x cam locks (#2) into the remaining holes on the back of the hutch. Turn clockwise to secure. 2x #2 Cam Locks Copyright© 2012 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
