Quality Monitoring Instruments QMI MULTIPLEX Manual page 71

Code QMI Product
QMI Detector Head Gasket
Q0203
Back Plate
Q0204 QMI Detector Head Filters
Q0205 QMI Detector Head Filters
Q0206 Small particle baffle
Q0207 Large particle baffle
QMI Detector Head 6-pin
Q0208
socket
QMI Detector Head 6-pin
Q0209
plug
Q0211 M3 Hexagonal Allen Key
Code QMI Product
Q0212 Cleaning Brush
Q0213 Cotton Cleaning Buds
Q0214 Cleaning Fluid
Q0215 Maintenance Kit
Q0216 Manual
FAN
Code QMI Product
QMI Fan type VBM3 c/w
Q0301
Rotation Sensor
QMI Fan Failure Rotation
Q0302
Sensor - With Top Hat
QMI Fan Type VBM3 c/w Fan
Q03FH1 Fail
housing and sensor
Q03FH2 QMI Fan Fail housing sensor
QMI MULTIPLEX JUNCTION BOX
Code QMI Product
QMI MULTIPLEX Junction
Q06
Box
EM6/March 2015
EMAIL qmi@oilmist.com WEBSITE www.oilmist.com 4 East Barnet Road, London, EN4 8RW, UK. TEL +44 (0)20 7328 3121
Engine Oil Mist Detection System
MULTIPLEX
Description
Back Plate Gasket
40% Free Volume
50% Free Volume
Small particle baffle. ¾" BSP screw fitting
Large particle baffle. ¾" BSP screw fitting
Bulgin 6 Pin in line SOCKET
Bulgin 6 Pin in line PLUG
For Detector Head Screws
Description
"Clean All" 200ml
Description
with Rotation sensor (Top Hat)
with Fan Fail Housing and Sensor. No
longer supplied. Use Q03FH
Description
for ENGINE Detectors
Spares Part6-3
