MULTIPLEX MONITOR WITH HARTING CONNECTORS

See Part 1-4
1. 32-way (1-16 female, 17-32 male) signal; supply to multi-way Junction Box
2. 4-way female shut/slowdown output open or relay - see Part 2-21
3. 10-way female alarm output
4. 4-way male mains input
5. 16-way female data logger output (optional)
MATING CONNECTORS FOR THE ABOVE
32-way (1-16 male, 17-32 female) - max. overall dimension of
1
cable 30mm
4-way male - maximum overall dimension of cable
2
12mm
10-way male - maximum overall dimension of cable
3
20mm
4 4-way female - maximum overall dimension of cable 12mm
16-way male - maximum overall dimension of cable
5
20mm
EM6/March 2015
EMAIL qmi@oilmist.com WEBSITE www.oilmist.com 4 East Barnet Road, London, EN4 8RW, UK. TEL +44 (0)20 7328 3121
Engine Oil Mist Detection System
MULTIPLEX
Connectors Part No.
Q01H1
Q01H2
Q01H3
Q01H4
Q01H5
Installation Part2-11
