110/240V POWER SUPPLY WIRING
1.
The 110/240VAC power supplies the Control Monitor Unit (CMU)
2.
Below shows the wiring for 110/240 VAC Power Supply
3.
The cable used should be of minimum 3 cores and can range from a minimum thickness
of 0.25mm
up to 2.5mm
2
4.
Do not use twisted cables
Harting Pin No
Installation
Part2-24
EMAIL qmi@oilmist.com WEBSITE www.oilmist.com 4 East Barnet Road, London, EN4 8RW, UK. TEL +44 (0)20 7328 3121
Engine Oil Mist Detection System
MULTIPLEX
maximum
2
1
2
3
4
Function
Live
Neutral
No connection
Earth
EM6/March 2015
