Quality Monitoring Instruments QMI MULTIPLEX Manual page 44

GRAPHS TO SHOW RELATIONSHIP BETWEEN MG/L,
DIGITAL READOUT OF PERCENTAGE OF ALARM LEVEL
AND THE PERCENTAGE OF LEL
Calibration Graph for 1.30 mg/L Relationship to % of LEL
Calibration Graph for 2.00 mg/L Relationship to % of LEL
Installation Part2-30
EMAIL qmi@oilmist.com WEBSITE www.oilmist.com 4 East Barnet Road, London, EN4 8RW, UK. TEL +44 (0)20 7328 3121
MULTIPLEX
1.50
MAXIMUM ALLOWABLE DENSITY BEFORE ALARM (1.30 mg/L)
1.25
1.00
0.75
0.50
0.25
0
10 20 30
DIGITAL READING
% OF ALARM WITH 1.30 mg/L PROGRAMME
2.00
MAXIMUM ALLOWABLE DENSITY BEFORE ALARM (2.00 mg/L)
1.80
1.60
1.40
1.20
1.00
0.80
0.60
0.40
0.20
0
10 20 30
DIGITAL READING
% OF ALARM WITH 2.00 mg/L PROGRAMME
Engine Oil Mist Detection System
SHUT/SLOW DOWN RELAY
EARLY WARNING RELAY
FLASHING
GREEN
YELLOW
40 50 60 70 80
SHUT/SLOW DOWN RELAY
EARLY WARNING RELAY
FLASHING
GREEN
YELLOW
40 50 60 70 80
FLASHING
RED
2.00
1.00
0.50
100
90
FULL ALARM LEVEL
FLASHING
RED
4.00%
3.00%
2.00%
1.00%
100
90
FULL ALARM LEVEL
EM6/March 2015
