Quality Monitoring Instruments QMI MULTIPLEX Manual page 70

CODES AND DESCRIPTION FOR REPLACEMENT PARTS
AND SPARES
MULTIPLEX MONITOR
Code QMI Product
Q01H QMI MULTIPLEX Monitor
Q01H1 Monitor connector
Q01H2 Monitor connector
Q01H3 Monitor connector
Q01H4 Monitor connector
Q01H5 Monitor connector
QMI Monitor Security Keys
Q0103
(Pack of 2)
MP12 PCB v 3.2 Processing
Q0104A
Board
Q0106 Switch mode power supply
Q0109 Magnetic Pen
Q0111 TR1 Transistor
Q0112 Anti-surge Fuse 400mA
Q0113 M4 Hex Allen Key
1.25A fuse for FS1 on Power
Q0114
Supplu Board
3.15A fuse for FS3 on side
Q0115
of Monitor
ENGINE DETECTOR
Code QMI Product
Q02L QMI Engine Oil Mist Detector with lead, fitted Bulgin plug and 50%filter
Engine Detector 12V
Auxilliary
Fan Unit
Detector Back Plate complete
Q0202
with filter and gasket
Spares Part6-2
EMAIL qmi@oilmist.com WEBSITE www.oilmist.com 4 East Barnet Road, London, EN4 8RW, UK. TEL +44 (0)20 7328 3121
Engine Oil Mist Detection System
MULTIPLEX
Description
With Harting Connectors
Harting 32-Way Mating Connector 1
(To MULTIPLEX Junction Box)
Harting 4-Way Plug Mating Connector 2
(To Shutdown Output)
Harting 10-Way Plug Mating Connector 3
(To Alarm Output)
Harting 4-Way Socket Mating Connector
4 (To Power Input)
Harting 16-Way Plug Mating Connector 5
(To Datalogger Output)
Monitor Security Switch to change
settings (Pack of 2)
For Monitor Flash Memory Chip
No case, for Power Supply Unit for
Monitor
To activate displays on Monitor
Power Supply Board
For FS2 on Power Supply Board
(Pack of 5)
To open Q01 Monitor lid
For FS1 on Power Supply Board
(Pack of 5)
For FS3 on side of Monitor
(Pack of 5)
Description
with lead, plug, baffle and 12V
Auxiliary Fan Unit (Q04)
Back Plate complete with filter and gasket
EM6/March 2015
