- Page 1 UHB EN 1919-2 USER MANUAL 231985 Hot water heat pump NIBE F130...
- Page 2 Quick guide Navigation Ok button (confirm/select) Up/down buttons (move/increase/reduce) Back button (back/undo/exit) A detailed explanation of the button functions can be found on page How to scroll through menus and make different settings is described on page Increase hot water volume true To temporarily increase the amount of hot water, first press the down button to mark menu 2 (water droplet) and then press the OK button twice.
-
Page 3: Table Of Contents
F130 – An excellent choice 2 The heating installation – the heart of the house Heat pump function Contact with F130 Maintenance of F130 3 F130 – at your service Set the ventilation Set the hot water capacity Get information Adjust the heat pump... -
Page 4: Important Information
Water heater VPD sp. exhaust air, normal) Serial number must always be given Certification that the installation is carried out according to instructions in the accompanying installer manual and applicable regulations. Date __________________ Signed _________________________ Chapter 1 | Important information NIBE F130... -
Page 5: Safety Information
Rights to make any design or technical modifications are reserved. ©NIBE 2019. If the supply cable is damaged, only NIBE, its service representative or similar authorised person may replace it to prevent any danger and damage. SYMBOLS NOTE This symbol indicates danger to person or machine . -
Page 6: Serial Number
F130 – An excellent choice F130 is part of a new generation of heat pumps that have been introduced to supply your home with inexpensive and environmentally friendly hot water. Hot water production is safe and economical with an external water heater and integrated control system. - Page 7 F130 consumes approximately 1/4 of the power of a corresponding conventional electrical water heater. This gives great savings and F130 therefore pays for itself quickly. • Scheduling hot water and ventilation Hot water and ventilation can be scheduled for each day of the week or for longer periods (vacation).
-
Page 8: The Heating Installation - The Heart Of The House
22 °C -3 °C 0 °C 0 °C 22 °C Värmekälla The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heating installation – the heart of the house NIBE F130... -
Page 9: Heat Pump Function
The temperatures are only examples and may vary between different installations and time of year. NIBE F130 Chapter 2 | The heating installation – the heart of the house... -
Page 10: Contact With F130
Contact with F130 DISPLAY UNIT B C D E There is a display unit on F130, which is used to communicate with F130. Here you: • set the hot water and ventilation, if any, as well as adjust the heat pump to your needs. - Page 11 With the up and down buttons you can: • scroll in menus and between options. • increase and decrease the values. MENU SYSTEM When F130 is started you come to the information menu. Basic inform- ation about the heat pump status is shown here. Date Clock Status icons Hot water temp.
- Page 12 Symbol Description This symbol is displayed when the compressor is operating. This symbol appears when the speed of the fan is changed from its normal setting. Chapter 2 | The heating installation – the heart of the house NIBE F130...
- Page 13 Selecting menu To advance in the menu system select a sub-menu by marking it by using the up and down buttons and then pressing the OK button. NIBE F130 Chapter 2 | The heating installation – the heart of the house...
- Page 14 Press the OK button to confirm the value you have set. To undo and return to the original value, press the back button. Chapter 2 | The heating installation – the heart of the house NIBE F130...
- Page 15 Mark, using the up and down keys, one of the arrows in the top left corner (at the page number). Press the OK button to scroll between the windows in the start guide. NIBE F130 Chapter 2 | The heating installation – the heart of the house...
-
Page 16: Maintenance Of F130
Maintenance of F130 REGULAR CHECKS Your heat pump requires minimal maintenance after commissioning. On the other hand, it is recommended that you check your installation regu- larly. If something unusual occurs, messages about the malfunction appear in the display in the form of different alarm texts. See alarm management... - Page 17 Water or other liquids must not be used for cleaning. Filter EMPTYING If F130 is drained because the house will not be used for some time for example, the heat pump must be filled again before restarting to avoid damage to the constituent components.
-
Page 18: F130 - At Your Service
If longer time changes are required use the holiday function. Caution The heat pump requires a minimum ventilation flow in order to work properly. An insufficient ventilation flow can result in an alarm and blocking of compressor operation. Chapter 3 | F130 – at your service NIBE F130... -
Page 19: Set The Hot Water Capacity
12 hrs When hot water requirement has temporarily increased this menu can be used to select an increase in the hot water temperature to lux mode for a selectable time. NIBE F130 Chapter 3 | F130 – at your service... - Page 20 The function is activated immediately when a time period is selected and con- firmed using the OK button. The remaining time for the selected setting is shown to the right. When the time has run out F130 returns to the mode set in menu 2.2. Select “off" to switch off temporary lux...
- Page 21 Scheduling always starts on the date that the start time is set for. If time periods overlap each other at midnight, the time period that starts after midnight is prioritised. NIBE F130 Chapter 3 | F130 – at your service...
- Page 22 The length of time between increases can be selected here. The time can be set between 1 and 90 days. Factory setting is 14 days. Tick/untick "activated" to start/switch off the function. Chapter 3 | F130 – at your service NIBE F130...
-
Page 23: Get Information
Symbols in this menu: Compressor Ventilation (only shown with Periodic increase or lux exhaust air installation) mode for hot water Scheduling Holiday setting NIBE F130 Chapter 3 | F130 – at your service... - Page 24 To view the run status in the event of an alarm, mark the alarm and press the OK button. alarm log 3.4 alarm 158 Information about an alarm. Chapter 3 | F130 – at your service NIBE F130...
-
Page 25: Adjust The Heat Pump
Alarms can be reset here. advanced Resetting all settings to factory default values. TIME & DATE Menu Set time and date and display mode here. time & date 4.4 12/24hrs month year NIBE F130 Chapter 3 | F130 – at your service... - Page 26 ALARM Menu This menu is only available if an alarm has occurred. alarm 291 Here you can reset any alarms that have charge pump occurred in F130. reset alarm Chapter 3 | F130 – at your service NIBE F130...
- Page 27 All settings that are available to the user factory setting4.9.4 (including advanced menus) can be reset to default values here. factory setting Caution After factory settings, user settings must be reset. NIBE F130 Chapter 3 | F130 – at your service...
-
Page 28: Disturbances In Comfort
In the event of an alarm, a malfunction has occurred, which is indicated by an alarm symbol in the display. ALARM In the event of an alarm, a malfunction has occurred that F130 cannot rectify itself. The display shows what type of alarm it is and lets you reset the alarm. - Page 29 The sensor has lost contact with the accessory card or is broken. The alarm resets automatically after correct connection. • Contact your installer! Communication alarm, display The display has lost contact with the base card. • Contact your installer! NIBE F130 Chapter 4 | Disturbances in comfort...
- Page 30 BASIC ACTIONS Start by checking the following items: • That the feed cable is connected to F130. • Group and main fuses of the accommodation. • The property's earth circuit breaker. LOW HOT WATER TEMPERATURE OR A LACK OF HOT WATER •...
- Page 31 – Enter menu 1 and select "normal". GURGLING SOUND • Not enough water in the water seal. – Refill the water seal with water. • Choked water seal. – Check and adjust the condensation water hose. NIBE F130 Chapter 4 | Disturbances in comfort...
-
Page 32: Technical Data
5 Technical data Detailed technical specifications for this product can be found in the in- stallation manual (nibe.eu). Chapter 5 | Technical data NIBE F130... -
Page 33: Glossary
Valve that reduces the pressure of the refrigerant, whereupon the tem- perature of the refrigerant drops. HEAT EXCHANGER Device that transfers heat energy from one medium to another without mixing mediums. Examples of different heat exchangers include evapor- ators and condensers. NIBE F130 Chapter 6 | Glossary... - Page 34 SUPPLY TEMPERATURE The temperature of the heated water that the heat pump sends out to the heating system. The colder the outdoor temperature, the higher the supply line temperature becomes. Chapter 6 | Glossary NIBE F130...
-
Page 35: Item Register
Manage alarm, 28 Troubleshooting, 30 Serial number, 6 Set the hot water capacity, 19 Set the indoor climate, 18 F130 – An excellent choice, 6 F130 – at your service, 18 Adjust the heat pump, 25 Technical data, 32 Get information, 23 The heating installation –... -
Page 39: Contact Information
NIBE Energy Systems OY, Juurakkotie 3, 01510 Vantaa Tel: +358 (0)9-274 6970 E-mail: info@nibe.fi www.nibe.fi NIBE Energy Systems France Sarl,Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 E-mail: info@nibe.fr www.nibe.fr... - Page 40 WS release date: 2019-05-09 16:33 Publish date: 2019-07-01 15:31 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publica- tion’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.
