- Page 1 Библиотека СОК User manual NIBE™ F130 Hot water heat pump UHB GB 1433-1 231985...
- Page 2 Quick guide Navigation Ok button (confirm/select) Up/down buttons (move/increase/reduce) Back button (back/undo/exit) A detailed explanation of the button functions can be found on page How to scroll through menus and make different settings is described on page 13. Increase hot water volume true To temporarily increase the amount of hot water, first press the down button to mark menu 2 (water droplet) and then press the OK button...
-
Page 3: Table Of Contents
F130 – An excellent choice 2 The heating installation – the heart of the house Heat pump function Contact with F130 Maintenance of F130 3 F130 – at your service Set the ventilation Set the hot water capacity Get information Adjust the heat pump... -
Page 4: Important Information
Fan (fan speed, normal mode) Exhaust air fan in- stallation Serial number must always be given Certification that the installation is carried out according to instructions in NIBE's installer manual and applicable regulations. Date __________________ Signed _________________________ Chapter 1 | Important information NIBE™... -
Page 5: Safety Information
Rights to make any design or technical modifications are reserved. ©NIBE 2014. NOTE If the supply cable is damaged, only NIBE, its service representative or similar authorised person may re- place it to prevent any danger and damage. Symbols NOTE This symbol indicates danger to machine or person. -
Page 6: Serial Number
Marking F130 is CE marked and fulfils IP21. The CE marking means that NIBE ensures that the product meets all regu- lations that are placed on it based on relevant EU directives. The CE mark is obligatory for most products sold in the EU, regardless where they are made. -
Page 7: Contact Information
Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: info@nibe.fi www.nibe.fi NIBE Energy Systems France Sarl, Zone industrielle RD 28, 01600 Reyrieux Tel : 03 88 06 24 10 Fax : 03 88 06 24 11 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk... - Page 8 NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 Markaryd Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: info@nibe.se www.nibe.se For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information. Chapter 1 | Important information...
-
Page 9: F130 - An Excellent Choice
F130 – An excellent choice F130 is part of a new generation of heat pumps that have been introduced to supply your home with inexpensive and environmentally friendly hot water. Hot water production is safe and economical with an external water heater and integrated control system. -
Page 10: The Heating Installation - The Heart Of The House
22 °C -3 °C 0 °C 0 °C 22 °C Värmekälla The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heating installation – the heart of the house NIBE™ F130... -
Page 11: Heat Pump Function
The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heating installation – the heart of the house NIBE™ F130... -
Page 12: Contact With F130
Contact with F130 Display unit B C D E There is a display unit on F130, which is used to communicate with F130. Here you: set the hot water and ventilation, if any, as well as adjust the heat pump ■... - Page 13 ■ scroll in menus and between options. ■ increase and decrease the values. Menu system When F130 is started you come to the information menu. Basic information about the heat pump status is shown here. Date Clock Status icons Hot water temp.
- Page 14 This symbol appears when the speed of the fan is changed from its normal setting. This symbol appears if lux mode for the hot water is activated. Chapter 2 | The heating installation – the heart of the house NIBE™ F130...
- Page 15 Selecting menu To advance in the menu system select a sub-menu by marking it by using the up and down buttons and then pressing the OK button. Chapter 2 | The heating installation – the heart of the house NIBE™ F130...
- Page 16 Press the OK button to confirm the value you have set. To undo and return to the original value, press the back button. Chapter 2 | The heating installation – the heart of the house NIBE™ F130...
- Page 17 1. Mark, using the up and down keys, one of the arrows in the top left corner (at the page number). 2. Press the OK button to scroll between the windows in the start guide. Chapter 2 | The heating installation – the heart of the house NIBE™ F130...
-
Page 18: Maintenance Of F130
Maintenance of F130 Regular checks Your heat pump requires minimal maintenance after commissioning. On the other hand, it is recommended that you check your installation regu- larly. If something unusual occurs, messages about the malfunction appear in the display in the form of different alarm texts. See alarm management on page 28. - Page 19 Clean the F130's air filter regularly, how often depends on the amount of dust in the ventilation air. 1. Switch off the fan in F130 by holding the standby button for 3 seconds. (Display turns off.) 2. Pull out the filter cassette.
-
Page 20: F130 - At Your Service
3 F130 – at your service Set the ventilation ventilation Menu 1 This menu is only shown with ex- ventilation 1 haust air installation. Setting range: normal and speed normal (70%) fan speed 1 (30%) Default value: normal fan speed 2 (50%) -
Page 21: Set The Hot Water Capacity
12 hrs When hot water requirement has temporarily increased this menu can be used to select an increase in the hot water temperature to lux mode for a selectable time. Chapter 3 | F130 – at your service NIBE™ F130... - Page 22 The function is activated immediately when a time period is selected and confirmed using the OK button. The remaining time for the selected setting is shown to the right. When the time has run out F130 returns to the mode set in menu 2.2. Select “off" to switch off temporary lux...
- Page 23 Scheduling always starts on the date that the start time is set for. If time periods overlap each other at midnight, the time period that starts after midnight is prioritised. Chapter 3 | F130 – at your service NIBE™ F130...
- Page 24 The length of time between increases can be selected here. The time can be set between 1 and 90 days. Factory setting is 14 days. Untick "activated" to switch off the function. Chapter 3 | F130 – at your service NIBE™ F130...
-
Page 25: Get Information
Symbols in this menu: Compressor Ventilation (only shown Lux mode for hot water with exhaust air installa- tion) Scheduling Holiday setting Chapter 3 | F130 – at your service NIBE™ F130... - Page 26 To view the run status in the event of an alarm, mark the alarm and press alarm 12 the OK button. alarm 158 alarm log 3.4 alarm 158 Information about an alarm. Chapter 3 | F130 – at your service NIBE™ F130...
-
Page 27: Adjust The Heat Pump
Alarms can be reset here. advanced Resetting all settings to factory default values. time & date Menu time & date 4.4 Set time and date and display mode here. 12/24 hrs month year Chapter 3 | F130 – at your service NIBE™ F130... - Page 28 If you choose to switch off hot water production during the vacation “periodic increase" (preventing bacterial growth) are blocked during this time. "periodic increase" started in conjunction with the vacation setting being completed. Chapter 3 | F130 – at your service NIBE™ F130...
- Page 29 All settings that are available to the 4.9.4 user (including advanced menus) can be reset to default values here. factory setting Caution After factory settings, user settings must be reset. Chapter 3 | F130 – at your service NIBE™ F130...
-
Page 30: Disturbances In Comfort
In the event of an alarm, a malfunction has occurred, which is indicated by an alarm symbol in the display. Alarm In the event of an alarm, a malfunction has occurred that F130 cannot rectify itself. The display shows what type of alarm it is and lets you reset the alarm. - Page 31 The sensor has lost contact with the accessory card or is broken. The alarm resets automatically after correct connection. Contact your installer! ■ Communication alarm display The display has lost contact with the base card. ■ Contact your installer! Chapter 4 | Disturbances in comfort NIBE™ F130...
-
Page 32: Troubleshooting
If the operational interference is not shown in the display the following tips can be used. Basic actions Start by checking the following possible fault sources: That the display is lit or that the supply cable to F130 is connected. ■ ■ Group and main fuses of the accommodation. - Page 33 Gurgling sound Not enough water in the water seal. ■ Refill the water seal with water. ■ Choked water seal. ■ Check and adjust the condensation water hose. ■ Chapter 4 | Disturbances in comfort NIBE™ F130...
-
Page 34: Technical Data
5 Technical data Detailed technical specifications for this product can be found in the in- stallation manual (www.nibe.eu). Chapter 5 | Technical data NIBE™ F130... -
Page 35: Glossary
A valve that mixes the cold water with the hot water leaving the heater. Refrigerant Substance that circulates around a closed circuit in the heat pump and that, through pressure changes, evaporates and condenses. During evap- Chapter 6 | Glossary NIBE™ F130... - Page 36 Supply temperature The temperature of the heated water that the heat pump sends out to the heating system. The colder the outdoor temperature, the higher the supply line temperature becomes. Chapter 6 | Glossary NIBE™ F130...
-
Page 37: Index
Item register Adjust the heat pump, 25 Important information, 2 Contact information, 5 Contact information, 5 F130 – An excellent choice, 7 Contact with F130, 10 Installation data, 2 Menu system, 11 Serial number, 4 Room unit, 10 Installation data, 2... - Page 40 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 231985...
