- Page 1 Installer manual NIBE™ F135 Exhaust air module IHB GB 1540-3 331432...
-
Page 3: Table Of Contents
Removing the covers 7 Control - Introduction 3 The exhaust air module design 8 Disturbances in comfort Info menu indoor module 4 Pipe and air connections Manage alarm (NIBE Indoor module) General pipe connections Troubleshooting Dimensions and pipe connections Mounting 9 Accessories... -
Page 4: Important Information
Marking F135 is CE marked and fulfils IP21. The CE marking means that NIBE ensures that the product meets all regulations that are placed on it based on relevant EU directives. The CE mark is obligat- ory for most products sold in the EU, regardless where they are made. - Page 5 Setting the ventilation flow Exhaust air filter Heating medium (page 20) System flushed System vented Circulation pump setting Setting heating medium flow Boiler pressure Electricity (page 18) Supply connected 230 V Circuit fuses NIBE™ F135 Chapter 1 | Important information...
- Page 6 NIBE Energy Systems France Sarl, Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 Fax : 04 74 00 42 00 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk www.nibe.co.uk...
-
Page 7: Delivery And Handling
Noise from the circulation pump, 10-25 fan and compressor can be transferred to the brack- ets or the surface that F135 is placed on. Use the product's adjustable feet to obtain a horizontal and stable set-up. 10-50*... -
Page 8: Supplied Components
The kit of supplied items is placed on top of the product. Air connection Silencer Filter cartridge 4-pin terminal block 2 x bracket Drain hose Ø 20 mm 6 x screws L=2200 mm 6 x nuts 4 x washers Chapter 2 | Delivery and handling NIBE™ F135... -
Page 9: Removing The Covers
3. Pull the hatch towards yourself. NOTE A ground cable is installed in the hatch, it can therefore only be lifted out 0.35 m. If the hatch needs to be removed completely, the cable must be detached. NIBE™ F135 Chapter 2 | Delivery and handling... -
Page 10: The Exhaust Air Module Design
3 The exhaust air module design XL43 BT77 XL44 BT12 QM25 GQ10 EB10 BT76 GP12 BT16 QN20 BT13 Chapter 3 | The exhaust air module design NIBE™ F135... - Page 11 Temperature sensor, defrosting BT77 Temperature sensor, incoming air Miscellaneous Rating plate Serial number plate Not visible in the image Designations in component locations according to standard IEC 81346-1 and 81346-2. NIBE™ F135 Chapter 3 | The exhaust air module design...
-
Page 12: Pipe And Air Connections
The refrigerant has now completed its circulation and returns to the evaporator. To make the installation economical, NIBE recommends that all pipes between F135 and the water heater are insulated. The insulation should be at least 12 mm thick. NOTE... -
Page 13: Dimensions And Pipe Connections
Pipe dimensions Dimensions and pipe connec- tions Connection XL8 Heating medium out ext Ø (mm) XL9 Heating medium in ext Ø (mm) WM2 Overflow water discharge int Ø (mm) NIBE™ F135 Chapter 4 | Pipe and air connections... -
Page 14: Mounting
2. Drill holes in the wall as illustrated. placed on a suitable flat surface. 3. Fit the brackets on the wall. 4. Screw F135 into place in the brackets using the M5 NOTE screws and nuts supplied. Check that the mountings are located in the intended grooves on the exhaust air module. -
Page 15: Connecting To Indoor Module And Air-Water Heat Pump
More information about the options is available at the indoor module and the air-water heat pump. The www.nibe.eu. particle filter must be installed before F135 to prevent Installation must be carried out in accordance with dirt being deposited in F135. Install the shut-off valves current standards and directives. - Page 16 Docking NIBE air-water heat pump The demand on F135 is controlled by the indoor mod- ule in the system. The pump and fan speed are also controlled from the menu in the indoor module. Chapter 4 | Pipe and air connections...
- Page 17 4-pipe cooling must, in this instance, be connected between the outdoor air heat pump and F135. When there is also a pool, the F135 must be connected between 4-pipe cooling and the pool. The demand on F135 is controlled by the indoor module in the system.
-
Page 18: General Air Connections
B. If there is a high hot water demand and incoming air to F135 contains a lot of particles, the heat pump module must be equipped with an air filter (HQ12) (enclosed). -
Page 19: Exhaust Air Duct /Kitchen Fan
A duct in a masonry chimney stack must not be used for extract air. Ventilation flow (exhaust air) Connect F135 so that all exhaust air except exhaust air duct air (kitchen fan) passes the heat exchanger (EP1) in the exhaust air module. Lowest ventilation flow must comply with applicable standards. -
Page 20: Electrical Connections
20 cm from high voltage cables. F135 is connected to an earthed socket with the factory installed power cord, which is supplied with connection plug. Chapter 5 | Electrical connections NIBE™... -
Page 21: Optional Connections
AUX2 (X13:3 och X13:4) (compressor). A closed contact results in the electrical output being disconnected. AA2-X13 External F135 AUX2 AUX1 AA2-X13 1 2 3 4 5 6 7 8 9 10 11 12 NIBE™ F135 Chapter 5 | Electrical connections... -
Page 22: Commissioning And Adjusting
1. Check that the externally mounted shut-off valves for the heating system are open. 2. Open the vent valve (QM25). 3. Open the externally mounted filler valves. F135 and the rest of the climate system are filled with water. 4. When the water that exits the vent valve (QM25) is not mixed with air, close the valve. -
Page 23: Start-Up And Inspection
" ". 1. Start F135 by connecting the supply cable. 2. Set the indoor module's switch to " ". 3. Follow the instructions in the start guide in the in- door module display. - Page 24 Setting ventilation (exhaust air) Ventilation must be set according to applicable stand- ards. If F135 is connected to an indoor module, the setting is made in menu 5.1.5. Otherwise the ventilation capacity is set via potentiometer (AA5-SF3). Even if ventilation is roughly set at installation it is im- portant that a ventilation adjustment is ordered and permitted.
-
Page 25: Control - Introduction
Looking through the values in this menu can often If the malfunction does not appear in the display, or simplify finding the source of the fault. F135 is not connected to the indoor module, the fol- lowing tips can be used: Manage alarm (NIBE Indoor... - Page 26 Gurgling sound Not enough water in the water seal. ■ Refill the water seal with water. ■ Choked water seal. ■ Check and adjust the condensation water hose. ■ Chapter 8 | Disturbances in comfort NIBE™ F135...
-
Page 27: Accessories
9 Accessories Top cabinet Top cabinet for concealing the ventilation ducts. 245 mm Part no. 089 756 345 mm Part no. 089 757 395-645 mm Part no. 089 758 NIBE™ F135 Chapter 9 | Accessories... -
Page 28: Technical Data
10 Technical data Dimensions and setting-out coordinates Chapter 10 | Technical data NIBE™ F135... -
Page 29: Technical Specifications
A20(12)W55, exhaust air flow 180 m /h (50 l/s) excl. driving power for fan The value varies with the selected fan speed. Visit www.nibe.eu for more detailed sound data, including sound to channels. The value may vary with the room's damping capacity. These values apply with a damping of 4 dB. - Page 30 Miscellaneous Dimensions and weight Width Depth Height (excluding connectors) 490 - 515 Weight Part No. 066 075 Chapter 10 | Technical data NIBE™ F135...
-
Page 31: Energy Labelling
Annual energy consumption space heating, warm cli- 587 / 731 mate Seasonal space heating energy efficiency, cold climate 147 / 117 Seasonal space heating energy efficiency, warm cli- 136 / 110 mate Sound power level L outdoors NIBE™ F135 Chapter 10 | Technical data... - Page 32 Crankcase heater mode 0.01 Other items Capacity control Fixed Rated airflow (air-water) Sound power level, indoors/outdoors 47 / - Nominal heating medium flow 0.13 Annual energy consumption 1,087 Brine flow brine-water or water-water heat pumps Chapter 10 | Technical data NIBE™ F135...
-
Page 33: Electrical Circuit Diagram
Electrical circuit diagram NIBE™ F135 Chapter 10 | Technical data... -
Page 34: Index
Control, 23 Start-up and inspection, 21 Control - Introduction, 23 Setting the ventilation, 22 Control - Introduction, 23 Start-up with NIBE Indoor module, 21 Supplied components, 6 Switch for external blocking of compressor, 19 Delivery and handling, 5 Symbol key, 10... - Page 35 Återvinning Lämna avfallshanteringen av emballaget till den installatör som installerade produkten eller till särskilda avfallsstationer. När produkten är uttjänt får den inte slängas bland vanligt hushållsavfall. Den ska lämnas in till särskilda avfallsstationer eller till återförsäljare som tillhandahåller denna typ av service. Felaktig avfallshantering av produkten från användarens sida gör att administrativa påföljder tillämpas i enlighet med gällande lagstiftning.
- Page 36 WS name: -Gemensamt WS version: a83 (working edition) Publish date: 2015-09-18 07:48 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 331432...
