Unpacking and Inspection
A A
H
A. Top Lid
B. Controller Lid
C. Control Panel
D. Circuit Breaker
E. Customer Connection Box
F. Main AC/Control Wiring Hole
for 3/4 in. Conduit
8
B
C
D
E
F
G
Figure 2-2. Features and Components
G. Auxiliary Engine Shutdown
Switch
H. Fuel Connection Hole
J. Data Label
K. Battery Access Panel
L. Oil Drain Hose
M. Oil Fill / Dipstick
J
K
L
M
P
O
N.
O.
P.
Q.
R.
S.
Installation Guidelines for 60 Hz PowerPact™
N
Q
R
S
005568
Front Panel (not shown)
Air Box
Spark Plug
Exhaust Enclosure
Alternator
Starter Motor
