Installation Drawing 10000022108-A, page 2 of 2
MINIMUM OPEN AREA
RIGHT SIDE VIEW
42
457.2
[18.0]
MINIMUM OPEN AREA
AIR INLET
914 [36.0]
ALL DIMENSIONS IN:
MILLIMETERS [INCHES]
SH REV
2/2
AIR INLET
914 [36.0]
MINIMUM OPEN AREA
REAR VIEW
TITLE
INSTALLATION DRAWING
PPACT W/ AUX SW
SIZE CAGE NO DWG NO
A
N/A
NTS
SCALE WT-KG
Installation Guidelines for 60 Hz PowerPact™
WINDCHILL VERSION
A
914 [36.0]
MINIMUM OPEN AREA
AIR OUTLET
AUXILIARY SHUTDOWN SWITCH & DECAL
FUEL INLET (3/4" NPT)
REQUIRED FUEL PRESSURE:
NATURAL GAS : 9-13mm HG
[5-7" WATER COLUMN]
LIQUID PROPANE (VAPOR) : 19-22mm HG
[10-12" WATER COLUMN]
209.2
[8.2]
130
[5.12]
10000022108
2 of 2
N/A SHEET
A.7
REV
A
