220W MULTI FUNCTION TOOL
EN
RS4401K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Shop Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Rockwell Shop Series

  • Page 1 220W MULTI FUNCTION TOOL RS4401K...
  • Page 3 RS4401K...
  • Page 4 RS4401K...
  • Page 5: Component List

    MULTI FUNCTION TOOL COMPONENT LIST ON/OFF SWITCH VARIABLE SPEED CONTROL VENTING SLOTS BOLT FLANGE HEX KEY SANDING SHEET SANDING PAD END CUT BLADE HSS SEMICIRCLE SAW BLADE ACCESSORIES GENERAL POWER TOOL SAFETY WARNINGS Hex key End cut blade WARNING Read all safety warnings and all Hss semicircle saw blade instructions.
  • Page 6: Electrical Safety

    MULTI FUNCTION TOOL accidents. 2. ELECTRICAL SAFETY d) Remove any adjusting key or wrench before a) Power tool plugs must match the outlet. Never turning the power tool on. A wrench or a key left modify the plug in any way. Do not use any attached to a rotating part of the power tool may adapter plugs with earthed (grounded) power result in personal injury.
  • Page 7 MULTI FUNCTION TOOL the cutting tool may contact hidden wiring or control. its own cord. Cutting accessory contacting a g) Use the power tool, accessories and tool bits ”live” wire may make exposed metal parts of the etc. in accordance with these instructions, power tool “live”...
  • Page 8: Technical Data

    MULTI FUNCTION TOOL SYMBOLS TECHNICAL DATA Voltage 230-240V~50Hz To reduce the risk of injury, user must read Power input 220W instruction manual No-load speed 11000-19000/min Oscillation angle Protection class Warning Machine weight 1.2kg Wear ear protection OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully.
  • Page 9: Working Hints For Your Tool

    MULTI FUNCTION TOOL application. Reposition the flange (5) and tighten the bolt (4) using the supplied hex key(6). The workpiece must be inserted firmly or clamped tightly before it is cut. Typical application: wood,plaster board and soft 2. MOUNTING / CHANGING THE SANDING SHEET plastics.
  • Page 10 MULTI FUNCTION TOOL a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free of dust. Occasionally you may see sparks through the ventilation slots. This is normal and will not damage your power tool. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 12 MADE IN PRC...
